- Page 1 Rudder kit installation guide...
- Page 2 5mm Screw for deckfitting 4. 2mm Rudderline with kevlar core 2x5m 5. Mini Line Lockers The following tools are needed to install the Rudder kit: Unscrew the foot rests from the outside and replace ø5mm drill them with the Rudder pedals which use the same Phillips bit / screw driver screws.
- Page 3 Take the rudder line and push it through the rudder line On each side, inside the cockpit, attach the mini-line tubes at the back of the kayak, until they emerge in the lockers as shown in th eimages 6-8. cockpit beside the seat. 1.
- Page 4 Attach the rudder by turning it all the way to starboard Lock the rudder in place by turning it as shown above. as shown above. The flat area at the end of the rudder pin should face backwards. Insert it all the way down into the rudder sleeve.
- Page 5 Line with cord locker Make knot at the end of this line Pull up line attached to rudder Finally, install the pull up line for the rudder, by first fas- Attach the deck fitting with the screwdriver and socket tening the deck fitting included in the pull up package wrench.
