Model: RRT5212
operating instructions
CAPACITY
Rivnuts: M5 - M6 - M8 - M10 - M12 - Standard
Rivstuds: M5 - M6 - M8 - Optional
Rivnuts: UNC - 10.24, 1/4.20, 5/16.18, 3/8.16 , 1/2.13 - Optional
Unscrew anvil and
locknut
IMPORTANT - MAINTENANCE TIP
APPLY GREASE TO THE LOAD TRANSFER THREAD.
THIS IS DONE BY WINDING THE TOOL APART, CLEANING AND
GREASING THE THREAD.
MAINTENANCE TIME APPROX 5 MINUTES.
Dafra Products - 1/7 Jarrah Drive Braeside, VIC, 3195
160mm
Pull mandrel to remove
from tool body.
IMPORTANT
ALWAYS TEST SET RIVNUTS INTO SCRAP MATERIAL.
ONLY A SMALL AMOUNT OF FORCE IS REQUIRED TO
SET THESE RIVNUTS.
UNNECESSARY OVER TIGHTENING MAY RESULT IN
DAMAGE TO THE TOOL MANDREL OR RIVNUT THREADS.
210mm
- WHEN USING M5 AND M6 RIVNUTS,
I dafra.com.au I 03 9555 6872
