- Page 1 PRO 3000G User Manual...
- Page 2 PRO 3000G Law Enforcement Audio&Video Recorder...
-
Page 3: Table Of Contents
Content Preface……………………………………..……03 Structure and diagram………………………..….04 Button instruction ……………………………….05 Main specification …………………………….. .06 Quick use………………………………...….. 07-13 Trouble shooting………………………….….…..14 Warranty statement………..………………..….15 Warranty card………………………………..…...16 ========================================... -
Page 4: Preface
PREFACE We sincerely thank you for using our company’s new product---police mobile camera .This manual is the introduction of this product which briefly introduces its functions、features、 performance 、external structure、operation and caution items as a reference for users’ convenience. Before using the camera, please read the user manual carefully and keep properly. -
Page 5: Structure And Diagram
Structure and diagram >>> ………………………………………………………………………....1power light 9 USB 18 Menu/confirm 2work light 10 microphone 19 up 3 IR LED 11 white light 20 ESC 4 laser 13 camera 21 down 5 expansion 14 reset button 23 video 6 photo 15 speaker 24 IR 7power on /off 16 clip... -
Page 6: Button Instruction
Button instruction>> Button name Function Power indicator Charging in red,standby in green light Work indicator Recording flashing in red light External Plug in mini camera expansion 【 】button photo 【 】button Turn on/off /sleep 【 】button Audio USB port Charge and data transmission 【reset】button Factory setting 【... -
Page 7: Main Specification
Main specification>>> 2304X1296-30P 1920X1080P-30P Video pixel 1280X720-60P 1280X720-30P watermark support（user ID、date、time） Camera pixel 34M(7696X4329 16:9) Work time 10-12hours Memory card option 16G 32G 64G 128G Camera lens 170° Night vision Battery Type Built in 3000-3600mAH battery Charge time 3hours Other ID number 5 digits device ID and 6 digits polce ID Encryption... -
Page 8: Quick Use
Quick Use>>> 1.Power on/off 1）Shortly press the power button of camera ,the device will be turned on and enter the standby mode. Under any circumstance, press the power button for 3 seconds,the equipment will be powered off. 2. Sleep screen mode After turned on, in the mode of preview/recording, short press the button to enter into save-power screen mode, the device still working ,just the screen in black to save power. - Page 9 IR Night vision function *Manual IR function 1)Shortly press the IR button, you can manually turn on / off infrared light when in ambient low outside light situations,the video will be in black and white colour . *Auto IR function 2)If set the IR autimactically,the infrared light will automatically turn on when in low-light environments.
- Page 10 Under the power-off state, press the button for 3seconds, the equipment will be turned on automatically and start the video-recording function, at this time, if needing to end and save the video, methods are same as above. In case of shooting at dark night, press the IR button, then the IR light will be turned on and enter the night shooting mode, pictures shot at night are black and white video pixel...
- Page 11 After turned on, in the mode of preview, press the button to enter into the interface of parameters setting and select the option of “motion detect” ,press to setting. 7. Sound recording After turned on, the equipment will directly enter the camera preview mode, press directly the button to record sound, the prompt that there is a picture under the sound-recording state...
- Page 12 icon in green colour,the GPS location is ok now ,you will see the longitude and latitude in the preview screen . GPS icon 11.External mini camera（option） 1) Plug the mini camera into AV IN port ,support use the mini camera recording . 12.Charging methods 1)Connected the DVR with the adaptor and charging .
- Page 15 13. Management After turn on the camera ,connect it to the computer ,enter the password 000000 into the device screen ,same as below picture . Enter U DISK mode directly ,find the camera disk in your PC and read all the video files .
-
Page 16: Troubleshooting
Troubleshooting>>> Trouble Possible causes Solution Battery is empty Charge 3.5hours Mainboard Press 【reset】button automatic Connect the camera with Can’t power protection computer ,insertion and extraction the camera repeatedly Charge the camera more than Working undercharge 3.5hours time short Data Power of front transmission panel is not Use the USB port of back panel... -
Page 17: Warranty Statement
Warranty statement>>> 1.Any one of the following user will not be able to enjoy the commitment of the company's warranty policy * Product was non-normal use *Non-normal storage conditions, exposed to the humid environment * Exposed to the temperature too high or too low temperature *Unauthorized repair, misuse, negligence, abuse,accident, alteration * Damage caused by force majeure (fire, accidents, etc.)
