John Lewis 85330112 Pre-Assembly Preparation

John Lewis 85330112 Pre-Assembly Preparation

6 burner hybrid bbq
Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for purchasing this barbecue. Please read the instructions carefully before use to ensure
safe and satisfactory operation of this product. Please keep these instructions for future reference.
Pre-assembly preparation
WARNING! FOR OUTDOOR USE ONLY
Please read these instructions carefully and ensure that your barbecue is properly installed, assembled,
maintained and serviced in accordance with these instructions.
Failure to follow these instructions may result in serious injury and/or damage to property.
If you have any questions concerning the assembly or operation of this barbecue, please contact your local John Lewis
store. Before using your BBQ please test for any gas leaks following the guidance given in this instruction manual
Necessary
Tools
This product takes approximately 90 MINUTES to assemble with
2 PEOPLE. The fittings pack contains SMALL ITEMS which should
be KEPT AWAY FROM YOUNG CHILDREN. Please check the
pack contents before attempting to assemble this product. A full
checklist of components is given on this leaflet. If any components
are missing, please contact the retailer from whom you bought this
product. Read this leaflet in full before commencing assembly.
6 Burner Hybrid BBQ
Stock Number: 85330112
YOU MUST CHECK FOR GAS LEAKS
BEFORE USING YOUR BARBECUE.
SEE PAGE 2 AND/OR PAGE 34
Carbon Monoxide Hazard
Using a barbecue inside can kill you,
it gives off Carbon Monoxide, which has no odour.
Never use a barbecue in enclosed spaces such as
a tent, home/building, vehicle or garage.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 85330112 and is the answer not in the manual?

Questions and answers

Related Manuals for John Lewis 85330112

Summary of Contents for John Lewis 85330112

  • Page 1 Failure to follow these instructions may result in serious injury and/or damage to property. If you have any questions concerning the assembly or operation of this barbecue, please contact your local John Lewis store. Before using your BBQ please test for any gas leaks following the guidance given in this instruction manual...

  • Page 2: Important - Please Read

    IMPORTANT - PLEASE READ Testing for leaks - do this before using your BBQ. Note - Do not test for gas leaks with an open flame. If you smell gas, turn off at the source. Before first use, at the beginning of each new season, or whenever a gas cylinder is changed, you must check for gas leaks.
  • Page 3 IMPORTANT - PLEASE READ Warnings Improper assembly of the grill may be dangerous. Please follow the Danger assembly instructions carefully. Do not use this grill unless all parts are in place. The grill must be properly assembled according to the assembly instructions. Failure to follow the DANGERS, WARNINGS and This barbecue is only to be used outdoors.
  • Page 4 Location of your BBQ IMPORTANT - BBQS MUST BE INSTALLED IN ACCORDANCE WITH THE MANUFACTURER’S INSTALLATION INSTRUCTIONS, LOCAL GAS FITTING REGULATIONS AND MUNICIPAL BUILDING CODES. Think carefully when deciding on a location where you are to use your BBQ. The BBQ must not be installed under or on any combustible material and must be a level surface.
  • Page 5 Securing the hose and regulator assembly Type A) Screw on hose connection (Fig. 4) - The BBQ’s manifold connection is 1/4” Male Thread BSP - The connection between the hose and regulator and the BBQ should be tightened with a spanner. Take care not to over tighten the joints Testing for leaks - do this before using your BBQ NOTE - DO NOT test for gas leaks with an open flame.
  • Page 6 Maintenance of your BBQ Cleaning the BBQ body The body of the BBQ should be cleaned regularly dependant on the use and type of food cooked. Use warm soapy solution. Protection Keep your BBQ beneath a weather cover and out of the rain. Proper care and Cleaning the drip tray/fat collection cup maintenance will keep your BBQ in top operating condition and prolong its life.
  • Page 7 Grillstream Hybrid System Once you have finished cooking and have allowed adequate time for the Barbecue to completely cool down, you should carefully dispose of the Ash that will have collected in the Charcoal Trays and the Grease Tray. This ash This Grillstream Barbecue comes equipped with the revolutionary should be emptied after every use.

  • Page 8: Troubleshooting

    TROUBLESHOOTING A note on fire prevention: Most fires in outdoor BBQs are caused by a build up of greases and fat, or gas connections which have not been secured properly. Remember IF BBQ FAILS TO OPERATE PROPERLY - Stop, turn off gas at its source and turn all burner controls to • off to follow the manufacturer’s instructions on proper cleaning and - Do not smoke connection procedures.

  • Page 9: Exploded Diagram

    6 Burner Hybrid BBQ 85330112 Exploded Diagram Description Code Hood Grease Cup Thermometer Side Burner Side Shelf Hood Handle Flame Tamer Cooking Frame Fat Channel Castor Grillstream Fat Cup Cabinet Base Panel Bottle Opener Cabinet Side Panel - Left Control Knob...

  • Page 10: Parts List

    Parts List Fixing elements Description Quantity Door Handle Spacer M6 x 12 Bolt Door Spindle Washer M4 x 12 Bolt Self-tapping Bolt M4 x 12 Bolt SS Self-tapping Screw Mounting steps Make sure your grill is assembled properly. Detailed assembly instructions are packed with each grill giving specific assembly procedures for each model.
  • Page 11 Step 1 Parts and fittings Push each of the Castors (5) into indicated holes in underside of Cabinet Base Panel (6) until you hear a click. Page 11...
  • Page 12 Step 2 Parts, fittings and tools Part unscrew the bolts indicated from Cabinet Base Panel (6), slot the Cabinet Side Panels (7 & 8) into place and re-tighten bolts. Page 12...
  • Page 13 Step 3 Parts and fittings Insert and part tighten bolts (B) into Cabinet Side Panels (7 & 8). Slot Cabinet Rear Panel (9) into place and secure to Cabinet Base Panel (6) with Bolts (B). Now fully tighten bolts into Cabinet Side Panels.
  • Page 14 Step 4 Parts, fittings and tools Part unscrew bolts indicated from Cabinet Side Panels (7 & 8) and Cabinet Base Panel (6). Slot Corner Support Brackets (10) in place and re-tighten bolts. iiii Page 14...
  • Page 15 Step 5 Parts and fittings Insert Front Support Bar (11), ensuring magnet is positioned towards bottom of support bar, and secure with Bolts (E). Page 15...
  • Page 16 Step 6 Parts and fittings Unscrew and remove Wing nut and Washer from Thermometer (2). Thread Thermometer Spindle through hole indicated on Hood (1). Replace Washer and Wing nut. Push Control Knobs (23) onto spindles indicated. Carefully lower cooking frame onto cabinet, ensuring fixing lugs are on the outside and that no wires or hoses are trapped between...
  • Page 17 Step 7 Parts, fittings and tools Secure cooking frame to side panels (7 & 8) using Bolts (B). Page 17...
  • Page 18 Step 8 Parts, fittings and tools Part unscrew bolts indicated, slot Side Shelf (12) in place and re-tighten bolts to secure. Further secure Side Shelf - Right using Bolt (B). Page 18...
  • Page 19 Step 9 Parts and fittings Further secure Side Shelf (12) in place from inside the cooking frame using Bolts (B) and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the cooking frame. Page 19...
  • Page 20 Step 10 Parts, fittings and tools Part unscrew bolts indicated, slot Ceramic Side Burner Shelf (18) in place and re- tighten bolts to secure. Further secure Side Shelf - Right using Bolt (B). Page 20...
  • Page 21 Step 11 Parts and fittings Further secure Ceramic Side Burner Shelf (18) in place from inside the cooking frame using Bolts (B) and Washers (D). Note: Washers (D) are domed and bottom of dome should be facing the cooking frame. Page 21...
  • Page 22 Step 12 Parts and fittings Remove Ceramic Side Burner Lid from Ceramic Side Burner Shelf (18) by pushing the Lid Axle left towards its spring and then lift right side of axle out first. Now insert Ceramic Side Burner (28) into Ceramic Side Burner Shelf from below, ensuring holes line up, and secure in place using 4 x Self-tapping Screw (H).
  • Page 23 Step 13 Parts and fittings Unscrew Ignition Button from Side Burner Ignition and insert 1 x AA battery (not supplied) noting correct polarity. Now attach the three ignition wires to the back of the Side Burner Ignition as shown. Page 23...
  • Page 24 Step 14 Parts, fittings and tools Unscrew the pre-installed bolts and feed the Side Burner Hose into opening on the Ceramic Side Burner Assembly, line up holes and re-install the bolts. Now connect the two ends of the Ceramic Side Burner Ignition Wire together.
  • Page 25 Step 15 Parts, fittings and tools Attach Gas Connection Bracket to Side Panel (8) using Bolt (E). Now tighten the nut above the Gas Connection Bracket. Note: The Gas Connection Bracket and Hose will be attached behind the Control Panel via cable tie, please cut the cable tie carefully to avoid damaging the components behind the Control Panel.
  • Page 26 Step 16 Parts and fittings Insert Door Spindles (C) into Cabinet Base Panel (6). Page 26...
  • Page 27 Step 17 Parts and fittings Push Door Handle Spacers (A) into holes shown on rear of Cabinet Doors (13). Pass Self- Tapping Screws (F) through spacers and screw into Cabinet Door Handles (14). To fit Cabinet Doors (13) in place, first slide the hole on bottom of door over Door Spindle (C), depress spring-loaded catch on...
  • Page 28 Step 18 Parts, fittings and tools Attach Grease Cup Bracket (16) to underside of Grease Tray (15) using Bolts (E). Place Grease Cup (17) inside Grease Cup Bracket and then slide underneath Cooking Frame ensuring it is level and on top of runners. Now slide Ceramic Side Burner Driptray (30) underneath the Ceramic Side Burner (28) ensuring it is level and...
  • Page 29 Step 19 Parts and fittings Insert 4 x AA Batteries (not supplied) into Battery Box (31). Connect Battery Box to LED Light Wire. Peel off plastic backing from sticky pad on the rear of the Battery Box and affix to inside of Side Panel (8). Page 29...
  • Page 30 Step 20 Parts and fittings Attach Bottle Opener (22) to side of Control Panel using Bolts (G). Page 30...
  • Page 31 Step 21 Parts and fittings Hook Grillstream Fat Cup (21) over holes in Side Panel (8). This should be located directly below the spout of Fat Channel (20) to catch fat and meat juices channelled from the Grillstream system. Page 31...
  • Page 32 Step 22 Parts and fittings Insert Fat Channel (20) into Cooking Frame by first sliding thin end through right-hand side of Cooking Frame and then slotting front lip in groove between Cooking Frame and Control Panel. Place Flame Tamer (19) and Hybrid Flame Tamers (25) on locating shelves. Flame Tamers should sit directly above Tube Burners.
  • Page 33 6 Burner Hybrid BBQ 85330112 Step 23 Parts and fittings Attach Tool Hooks (32) through holes indicated on underside of Side Shelf (12). Page 33...
  • Page 34 Step 23 Parts and fitting Your barbecue is now fully assembled, and you are ready to connect the Gas Cylinder (see page 4 for more information). Please ensure you perform the gas leak check before operating. Page 34...
  • Page 35 IMPORTANT - PLEASE READ Testing for leaks - do this before using your BBQ. Note - Do not test for gas leaks with an open flame. If you smell gas, turn off at the source. Before first use, at the beginning of each new season, or whenever a gas cylinder is changed, you must check for gas leaks.
