ICP Savannah S Addendum

ICP Savannah S Addendum

Tail dragger ultralight aircraft
Hide thumbs Also See for Savannah S:
Table of Contents

Advertisement

Quick Links

Download this manual
Serial number
Manufacturer:
Address:
S.p. 16 km 15,150
Castelnuovo Don Bosco (AT) ITALY
14022
The technical data and the information embodied therein are property of I.C.P. srl and shall not be disclosed
in whole or in part to third parties, without prior written permission of I.C.P. srl. The manual must remain with
the aircraft in case of sale.
Serial number
-
-54-
TM
Savannah
Ultralight Aircraft
POH Addendum
-
-54-
Year 20
ICP S.r.l.
Rev.02
-S Tail Dragger
.
Contacts:
Phone: +39 011 9927503
Fax:
Web:
Email:
ORIGINAL ISSUE DATE: 20.03.2013
REVISION DATE:
English version
Page:1/11
+39 011 9927266
www.icp.it
info@icp.it
16.10.2017

Advertisement

Table of Contents
loading

Related Manuals for ICP Savannah S

Summary of Contents for ICP Savannah S

  • Page 1 Savannah -S Tail Dragger English version Ultralight Aircraft Page:1/11 POH Addendum Serial number -54- Year 20 Manufacturer: ICP S.r.l. Address: Contacts: S.p. 16 km 15,150 Phone: +39 011 9927503 Castelnuovo Don Bosco (AT) ITALY Fax: +39 011 9927266 14022 Web: www.icp.it...

  • Page 2: Table Of Contents

    7.5 NORMAL TAKE-OFF CHECKLIST ................11 LIST OF REVISIONS ....................11 1 Introduction The Savannah S tail dragger version has the same weight of the standard version. The increase in weight due to the additional structural parts is balanced by the nose landing gear removal.

  • Page 3: Landing Gear

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:3/11 POH Addendum 2.5 Landing Gear The main landing gear is composed of a single-piece aluminium 7075 alloy spring; the spring is fixed to welded steel plates bolted to the fuselage. The tail wheel is a pivot small wheel connected to the rudder command.

  • Page 4: Aircraft Technical Specifications

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:4/11 POH Addendum 2.9 Aircraft Technical Specifications Serial number ORIGINAL ISSUE DATE: 20.03.2013 Rev.02 -54- REVISION DATE: 16.10.2017...

  • Page 5: Weight And Balance

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:5/11 POH Addendum 4 WEIGHT AND BALANCE The following paragraphs explain the procedure to calculate and verify the weight and balance of the aircraft. WARNING It is pilots responsibility to verify that take off and flight weight and balance conditions are within limits.

  • Page 6: Basic Empty Weight And Balance Determination

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:6/11 POH Addendum 4.2 BASIC EMPTY WEIGHT AND BALANCE DETERMINATION Forward C of G limit: 25% +/- 0.9 % (330 mm from L. E.) Rear C of G limit: 38.5%+/- 0.9 % (508 mm from L.E.) The aircraft is allowed to fly within a quite large weight and balance range thus easing the aircraft’s load and balance.

  • Page 7: Basic Empty Weight Table

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:7/11 POH Addendum 4.3 BASIC EMPTY WEIGHT TABLE Aircraft serial number Weight measuring equipment Location and date Certifying staff Weight [lbs] / [Kg] Arm [ft] / [m] Mom.[lbs x ft] / [kg x m] Rear landing gear...

  • Page 8: Weight And Balance Computing Table And Graph

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:8/11 POH Addendum 4.4 WEIGHT AND BALANCE COMPUTING TABLE AND GRAPH Before any flight, the pilot must check the weight and balance compiling the following table:  Compile the weight column with data from the empty weight table, crew weight, fuel weight, and baggage weight (if present).
  • Page 9 Savannah -S Tail Dragger English version Ultralight Aircraft Page:9/11 POH Addendum Serial number ORIGINAL ISSUE DATE: 20.03.2013 Rev.02 -54- REVISION DATE: 16.10.2017...
  • Page 10 Savannah -S Tail Dragger English version Ultralight Aircraft Page:10/11 POH Addendum 7.5 Normal takeoff 1. Wing flaps in the takeoff position (Flaps at 15°); 2. Air Box control set for cold air intake (if installed). 3. Engine at 5800 RPM (if installed a variable pitch propeller); 4.

  • Page 11: Normal Take-Off Checklist

    Savannah -S Tail Dragger English version Ultralight Aircraft Page:11/11 POH Addendum 7.5 NORMAL TAKE-OFF CHECKLIST 1. Set Flap 1/2; 2. Set Trim neutral; 3. Switch ON Electric Fuel Pump and EXT. LIGHTS; 4. Verify CARB HEAT not used; 5. Throttle advance to max power; 6.
