Gunter & Hauer EOK 20 BL Instruction Manual

Built-in microwave oven
Hide thumbs Also See for EOK 20 BL:
Table of Contents

Advertisement

Quick Links

Download this manual
Günter & Hauer
EN
Instruction manual
BUILT-IN MICROWAVE OVEN
EOK
20 BL / 20 X
28 X
25 WH / 25 IVR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOK 20 BL and is the answer not in the manual?

Questions and answers

Related Manuals for Gunter & Hauer EOK 20 BL

Summary of Contents for Gunter & Hauer EOK 20 BL

  • Page 1 Günter & Hauer Instruction manual BUILT-IN MICROWAVE OVEN 20 BL / 20 X 28 X 25 WH / 25 IVR...
  • Page 2 Thank you for your trust and choosing GÜNTER & HAUER products! This manual was developed to facilitate the use of the product. It will help you familiarize yourself with new appliance quickly. Make sure you have received the product without any damage. If damage is detected, please contact the purchasing organization where you have bought appliance.

  • Page 3: Table Of Contents

    3) Cleaning................9 4) Microwave oven installation..........11 6) Assembly instructions............13 7) Instructions for choosing cookware........17 8) Operation instructions: Model EOK 25 WH / 25 IVR..........21 Model EOK 28 X..............27 Model EOK 20 BL / 20 X..........33 9) Troubleshooting..............38 10) Specifications..............40...

  • Page 4: Precautions

    PRECAUTIONS Please read carefully and SAFETY INSTRUCTIONS keep for future use! To avoid fire, electric shock, To prevent the possible impact injury or exposure to of electromagnetic radiation: electromagnetic radiation, follow the basic safety requirements 1) Do not turn on the described below when using the microwave oven when the door appliance:...
  • Page 5 3) This appliance can be used by 9) Do not allow food to overheat. children aged 8 and over and This is especially relevant when adults with physical disabilities, heating a small amount of food. sensory or cognitive impairments, 10) Do not use the microwave or lack of experience and cavity for storage.
  • Page 6 - in the kitchen for staff in 19) Do not leave the cable hanging stores, offices and other over the edge of a table or a working spaces; countertop. - for guests in hotels, motels, 20) If the microwave is not kept and other residential spaces;...
  • Page 7 WARNING! Packaging 25) The appliance must not be materials (polyethylene bags, cleaned with a steam cleaner. pieces of foam, etc.) during the 26) Use only the temperature unpacking process must be sensor recommended for this inaccessible to children. microwave oven (the appliance is For more detailed information equipped with a temperature on the recycling of this product,...

  • Page 8: Important Safety Instructions

    Electrical and electronic This product is equipped with products are potentially a cable that has a ground wire dangerous for the environment and a suitable plug. and human health due to the The plug must be connected to a presence of hazardous properly installed, grounded substances.

  • Page 9: Cleaning

    If an extension cord is used: 1) Remove all splashes and stains 1) The nominal electrical data on from the interior surfaces or the the extension cord must turntable ring using a soapy water correspond (be of the same value) and a cloth.
  • Page 10 PRODUCT OVERVIEW EOK 25 WH EOK 25 IVR EOK 28 X EOK 20 BL EOK 20 X...

  • Page 11: Microwave Oven Installation

    MICROWAVE OVEN INSTALLATION Your microwave comes with the following accessories: Control panel E) Observation window Turntable shaft F) Door Turntable ring assembly G) Safety interlock system Glass tray WARNING: The grill rack should only be used when using the «GRILL» function by placing it on the glass tray.
  • Page 12 TURNTABLE INSTALLATION 5. The appliance is fitted with a plug and must only be connected 1. Never place the glass tray upside to a properly installed grounded down. socket. 2. Glass tray and turntable ring 6. The mains voltage must assembly must always be used correspond to the voltage specified during cooking.

  • Page 13: Assembly Instructions

    Dimensions may vary. Check the manufacturer's official website for up-to- date information. EOK 28 X EOK 20 X EOK 20 BL...
  • Page 14 В. PREPARE THE CABINET Mounting plate. 成品尺寸：303*427mm 内容 1. Read the instructions on the " " " a microwave bottom template (hereafter «TEMPLATE»). Put the «TEMPLATE» on the bottom plane of cabinet, taking into account all gaps. PN:261800316968 2. Make marks on the bottom plane of cabinet according to marks «A»...
  • Page 15 3. Remove the bottom cabinet SCREW «А» template and fix the mounting plate with screw «A». MOUNTING PLATE С. INSTALL THE MICROWAVE OVEN 4. Install the microwave to the cabinet. - Make sure the back of the appliance is locked by mounting plate. - Do not pinch the power cable.
  • Page 16 5. Open the door, fix the microwave to the cabinet with Screw «B», at the installation hole. SCREW «B» INSTALLATION HOLE...

  • Page 17: Instructions For Choosing Cookware

    INSTRUCTIONS FOR CHOOSING COOKWARE TYPE OF SUITABILITY REMARKS COOKWARE FOR MWO Aluminum foil It can be used in small quantities to protect certain areas of food from burning. Placing the foil close to the ✓Х microwave walls or using a large amount of foil can cause an electrical arcing.
  • Page 18 Packaging of quick- cooking products: Polystyrene cups Can be used to heat up food. • ✓Х and containers Polystyrene can melt when it is overheated. Paper bags or • Х Ignition hazard. newspapers Recycled paper • Х May cause an electrical arcing. or cookware with metal finish Glassware:...
  • Page 19 Metal: • Cookware Х May cause arcing or ignition. • Freezer bags with metallic twist tie Plastic: In particular, heat-resistant ✓Х • Containers thermoplastic. Some other types of plastic can deform or discolor at high temperatures. Do not use melamine plastic. Can be used to preserve moisture.
  • Page 20 Paper and wood For cooking for a short time and • Plates, cups, ✓ warming up. For absorption of napkins made of excess moisture. textiles or paper May cause electrical arcing. • Recycled ✓Х paper The wood will constantly lose ✓Х...

  • Page 21: Model Eok 25 Wh / 25 Ivr

    OPERATION INSTRUCTIONS PAY ATTENTION:  Model EOK 25 WH / 25 IVR 1) If the clock has not been set, it will not work. This microwave oven is equipped 2) If you touch “STOP/Clear” with a modern electronic control button during time setting, the system for adjusting the parameters microwave will automatically return of cooking or heating food, which...
  • Page 22 After that, tap “START/+30Sec/ NOTE! The step quantities for Confirm” to confirm your choice and the adjustment time are as follow: set the cooking time from 0:05 to 0---1 min: 95:00. 5 sec 1---5 min: 10 sec Tap “START/+30Sec/Confirm” to 5---10 min: 30 sec 10---30 min:...
  • Page 23 Ratio of microwave power to grill 4. DEFROST BY WEIGHT power of the «Combi» function: 1) Tap the button “Weight/Time Defrost” once, the symbol “dEF1” will appear on the display. SYMBOL ON С-1 С-2 2) Use « » and « » buttons to THE DISPLAY select the weight of products from MICROWAVE...
  • Page 24 the instructions above, and then set NOTE: The «Auto Menu» function the desired start time. cannot be selected as one of the stages in multi-stage heating. EXAMPLE: If you want to defrost a EXAMPLE: If you want to heat a dish dish for 5 minutes and then reheat it using 80% microwave power for 7 using 80% microwave power for 7...
  • Page 25 8. «AUTO MENU» 1) In microwave standby mode, tap « » to select from «A-1» to «A-8» mode. 2) Tap “START/+30Sec/Confirm” to confirm the menu settings. 3) Use « » and « » to set food weight. 4) Tap “START/+30Sec/Confirm” to start the cooking process. 5) When cooking is complete, the microwave oven will beep 5 times.
  • Page 26 11. INFORMATION FUNCTIONS 2) When cooking in “microwave”, “grill”, “combined” or «Defrost by 1) When cooking in “microwave”, time» mode, tap “START/+30Sec/ “grill”, “combined” modes, tap Confirm” to increase the heating “Micro./Grill/Combi” – the current time. cooking power will be shown on the display for 3 seconds.

  • Page 27: Model Eok 28 X

    2. COOKING PROCESS OPERATION INSTRUCTIONS MODEL EOK 28 Х Your microwave oven has 3 cooking modes: 1. TIME SETTING. 1) Microwave (MWO) When the microwave is on, the 2) Grill display will show and a 3) Combined mode buzzer will sound. 2.1. «MWO»...
  • Page 28 2.3. «Combined» mode NOTE! The step quantities for the adjustment time are as follow: 0---1 min: 5 sec 1) Tap “Microwave/Grill/Combi.” once. “P100” will appear on the 1---5 min: 10 sec 5---10 min: 30 sec display. 10---30 min: 1 min 2) Turn or tap “Microwave/Grill/ 30---95 min: 5 min...
  • Page 29 Table of cooking modes and power levels Order of Symbol on Microwave Grill power functions the display power P100 100% 100% ATTENTION: When half of the set time in «Grill» mode has passed, the microwave will stop and beep. To continue, just tap “START/+30SEC./ CONFIRM”.
  • Page 30 4. EXPRESS COOKING 5. DEFROST BY WEIGHT 1) Tap “WEIGHT/TIME DEFROST”. In standby mode, tap “START/ “dEF1” will appear on the display. +30SEC./CONFIRM” to start cooking at 100% power for 30 seconds. 2) Use the knob to set the weight of the products. Defrosting weight If the time remaining until the end range: 100-2000 g.
  • Page 31 10. MULTI-STAGE HEATING 6) Use the knob to set the cooking time to 7 minutes. This microwave allows you to set up multi-stage heating of food. A 7) Tap “START/+30SEC./ maximum of 2 power levels can be CONFIRM” to start cooking. set.
  • Page 32 13. AUTO MENU Table of parameters of automatic cooking modes 1) In standby mode, turn the knob to the right to select one of the 8 automatic cooking modes («A-1» - WEIGHT MENU «A-8»). 200 g А-1.  2) Tap “START/+30SEC./CONFIRM” 400 g PREHEATING to confirm the selected mode.

  • Page 33: Model Eok 20 Bl / 20 X

    OPERATION INSTRUCTIONS 2. COOKING PROCESS Your microwave oven has 3 MODEL EOK 20 BL / 20 X cooking modes: 1) Microwave (MWO) 1. TIME SETTING. 2) Grill When the microwave oven is on, 3) Combined mode the display will show 0:00 and the buzzer will sound.
  • Page 34 2.2. «Grill» mode 4) Turn the knob to set the desired cooking time. 1) Tap . “P100” will appear on 5) Tap to confirm the time and the display. start the cooking process. 2) Turn until the symbol « » appears on the display. 3.
  • Page 35 4. DEFROST BY WEIGHT NOTE: The «Auto Menu» function cannot be selected as one of the    1) Tap button. “dEF1” will stages in multi-stage heating. appear on the display. 2) Use the knob to set the EXAMPLE: If you need to defrost a products weight.
  • Page 36 7. AUTO MENU Table of parameters of automatic cooking modes 1) In standby mode, turn the knob to the right to select one of the 8 WEIGHT MENU automatic cooking modes («A-1» - 200 g А-1.  «A-8»). 400 g 250 g 2) Tap to confirm the selected А-2. ...
  • Page 37 8. TIMER (ALARM) 10. INFORMATION REQUEST During cooking: 1) Tap once. - tap to find out the current 2) Use the knob to set the cooking power. desired timer time (max. 95 min). 3) Tap to confirm settings. - tap to find out the current time.

  • Page 38: Troubleshooting

    TROUBLESHOOTING POSSIBLE PROBLEM REMEDY CAUSE  Radio broadcasting and television images may be disturbed during operation of the microwave oven. Such The microwave oven disturbances can also occur disrupts the during the operation of small- television image. sized electrical equipment, for example, a mixer, a vacuum cleaner, and an electric fan.
  • Page 39 The cable is not Pull out the plug and properly connected to turn it on again after 10 the electrical socket. seconds. The fuse has blown or Change the fuse or turn The microwave oven the safety fuse has on the circuit breaker. does not turn on.

  • Page 40: Specifications

    SPECIFICATIONS 25 WH / 25 IVR 28 X 20 BL / 20 X Current voltage 230 V ~ 50 Hz Power 1250 W 1450 W 800 W Microwave wattage 900 W Grill wattage 1000 W 1100 W 1000 W Volume of the 25 liters 28 liters 20 liters microwave Diameter of the 245 mm...
  • Page 41 This appliance complies with EC Directive 2002/96/CE. This symbol on the product or on the accompanying documents of the product indicates that it must be disposed of separately from household waste. You will help to avoid negative consequences for the environment and people's health, which can be caused by improper recycling after the end of use of the appliance.
  • Page 42 Günter & Hauer www.gunter-hauer.eu info@gunter-hauer.de...
