Vulcan-Hart 2G4BDF Specifications

2G4BDF Solid State Control Behind the Door Shown
SPECIFICATIONS:
Patented Built-in filter system, Vulcan-Hart Model No. 2GBDF (lb.
capacity - 45, 65 or 85) Solid state knob control, F (add suffix-F
to fryer battery model No., i.e. 2G4BDF). Filter sytem accommo-
dates minimum of two, maximum of four cabinets for each size
fry tank. Filter vessel constructed of 18 gauge #301 series
stainless steel. The 2G4BDF filter pan weighs only 12.2 lbs. and
the filter pan for the 2G6 & 8BDF weighs only 20.5 lbs.
motor/ pump circulates hot frying compound at the rate of 8
gallons per minute, activated by a patented solenoid push button
switch. Patented System provided standard with paperless
stainless steel mesh filter screen. A complimentary package of
KleenScreen PLUS® Fabric Envelopes is also included. Stan-
dard equipment comes on casters, a primary crumb catch basket,
tank brush, scoop and clean-out rod. Hands free oil return line
connection. Drain valve interlock switch turns fryer's burners off
when drain valve is opened. Requires 120 volt, 60 Hz, 1 phase
power supply.
CSA design certified. NSF Listed.
SPECIFY TYPE OF GAS: NATURAL OR PROPANE
SPECIFY ALTITUDE: NATURAL GAS ABOVE 2,000 FT.
PROPANE GAS ABOVE 3,500 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32938 (5-08)
GBDF KLEENSCREEN PLUS®
FILTRATION SYSTEM
BUILT-IN FILTER SYSTEM FOR GBDF SERIES FRYERS
/ H.P.
1
3
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
STANDARD FEATURES
Filter system accommodates minimum of two, maximum of
four fryer cabinets for each size fry tank.
Solid State knob controls located behind the door. Maintains
+/- 2° F yield quick recovery.
Two melt modes - Liquid and Solid
Boil Out ByPass™ removes water or discard oil .
Drain valve interlock switch.
6" Casters adjustable - 2 locking, 2 non-locking.
Electronic ignition.
Drawn (seamless) 18 gauge, #301 stainless steel filter
pan. 70 lbs. frying compound capacity on G4BDF, 110 lbs.
capacity on G6BDF & G8BDF.
Paperless stainless steel filter screen filters from 2
sides filter area = 270 sq. inches.
Fabric Envelope filter area = 350 square inches.
/ H.P. motor and pump circulates frying compound at a rate
1
3
of 8.0 gallons per minute.
Patented solenoid activated one touch push button switch to
engage pump and motor.
6' High Temperature Discard Hose
Large primary crumb catch basket.
Tank brush, stainless steel crumb scoop and clean-out rod.
120 volt, 60 Hz, 1 phase.
One year limited parts and labor warranty.
12 year fry tank replacement part warranty.
ACCESSORIES
Stainless steel tank cover.
Micro-Filtration Fabric Envelopes - 6 filters/per package
"Add-On" Frymate - VX15, VX21, VX21S.
Rear oil reclamation discard connection.
Prison Security Package
Flexible gas hose with quick disconnect.
OPTIONS
Second year extended limited parts and labor warranty.
REFERENCE MATERIALS
See 1G4BD Spec Sheet F-32935
See 1G6BD Spec Sheet F-32936
See 1G8BD Spec Sheet F-32937
C.S.I. Section 11420
Mircro Filtartion
