MI vortex mixer
con pantalla digital LED
Safety Instructions
For your protection
• Read the operating instructions in full before starting up
and follow the safety instructions.
• Keep the operating instructions in a place where they can be
accessed by everyone.
• Ensure that only trained sta ffwork with the appliance.
• Follow the safety instructions, guidelines, occupational health
and safety and accident prevention regulations.
• Socket must be earthed (protective ground contact).
• Wear your personal protective equipment in accordance with
the hazard category of the media to be processed.
Otherwise there is a risk from:
- Splashing liquids
- Projectile parts
- Body parts ,hair ,clothing and jewellery getting caught.
• Keep hand/arm vibration to a minimum (Directive 2002/44/EC)
When operated manually:
- Keep the sample container as vertical as possible.
- Only exert the minimum pressure necessary for the mixing process.
- Use attachments for multiple samples when there is a large
number of samples.
• Set up the appliance in a spacious area on an even, stable,
clean, non-slip, dry and fireproof surface.
• The feet of the appliance must be clean and undamaged.
• Position the knob at the left stop before starting up.
Gradually Increase the speed.
• If the shaking movement of the appliance increases
(resonance), reduce the speed or pass through the critical
phase as quickly as possible.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Four E's Scientific MI0101002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gentech Four E's Scientific MI0101002

  • Page 1 MI vortex mixer con pantalla digital LED Safety Instructions For your protection • Read the operating instructions in full before starting up and follow the safety instructions. • Keep the operating instructions in a place where they can be accessed by everyone. •...
  • Page 2 MI vortex mixer con pantalla digital LED • Reduce the speed if - The medium splashes out of the vessel because the speed is too high - The appliance is not running smoothly - The container moves on the base plate •...
  • Page 3: Operator's Control

    MI vortex mixer con pantalla digital LED Operator’s Control ⑤ ① ⑥ ② ③ ⑦ ④ Item Description Function Speed Display Display the set speed Display the set time in the continuous working model. The continuous mode includes timed running and untimed running. When timed running, it shows the balance time “xx: xx”, when Time Display the time is 0, the machine stops running.
  • Page 4 MI vortex mixer con pantalla digital LED Item Description Function Press the knob, the speed display will flash and then set the speed in the range of 400-300rpm by horizontal rotation of the knob. Press the knob Time/Speed twice, the time display will flash, and then set the Setting time in the range of 0-99H59Min by horizontal rotation of the knob.
  • Page 5: Correct Use

    MI vortex mixer con pantalla digital LED Unpacking • Unpacking - Please unpack the device carefully - In the case of any damage a fact report must be set immediately (post, rail or forwarder) • Delivery scope - Vortex Mixer - Plug-in power supply - Operating instructions Correct Use...
  • Page 6: Maintenance

    MI vortex mixer con pantalla digital LED - Run the mixer by “Run/Stop” in the continuous mode. - Turn o ffthe mixer by putting the mode switch on middle gear. Maintenance The appliance is maintenance-free. Cleaning Only use cleansing agents which have been recommended by us. Use to remove Dyes isopropyl alcohol...
  • Page 7 MI vortex mixer con pantalla digital LED Accessories Item Part No. Product Photo Description Test Tube Attachment, MI0101002-31 54 x Φ6mm, used with MI0101002-14 Test Tube Attachment, MI0101002-32 18 x Φ10mm, used with MI0101002-14 Test Tube Attachment, 12 x Φ12mm,used with MI0101002-33 MI0101002-14 Test Tube Attachment,...
  • Page 8: Application Of Accessories

    MI vortex mixer con pantalla digital LED Item Part No. Product Photo Description Standard top <Φ30mm tubes and MI0101002-13 small vessels Erlenmeyer flask MI0101002-37 attachment 100-250ml, used with MI0101002-14 Application of Accessories Adjustable Speed Model 400-3000rpm Accessory Touch Mode Continuous Mode High Speed Low Speed High Speed...
  • Page 9: Warranty

    MI vortex mixer con pantalla digital LED Warranty In accordance with our warranty conditions, the warranty period is 24 months. For claims under the warranty please contact your local dealer. You may also send the machine directly to our factory, enclosing the delivery invoice and giving reasons for the claim.
