Meat Grinders
Models:
#177MG12R
#12 • 110V • 1 HP
#177MG22R
#22 • 110V • 1 1/2 HP
Warning:
Improper installation, adjustment, alteration, service, or
maintenance can cause property damage, injury, or death.
Read the installation, operating, and maintenance instructions
thoroughly before installing or servicing this equipment.
www.AvantcoEquipment.com
User Manual
For Your Safety:
Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
Note:
Please read and keep these instructions. Indoor use only.
11/2023
Advertisement
Table of Contents
Related Manuals for Avantco Equipment 177MG12R
Summary of Contents for Avantco Equipment 177MG12R
- Page 1 User Manual 11/2023 Meat Grinders Models: #177MG12R #12 • 110V • 1 HP #177MG22R #22 • 110V • 1 1/2 HP Warning: For Your Safety: Improper installation, adjustment, alteration, service, or Do not store or use gasoline or other flammable vapors or maintenance can cause property damage, injury, or death.
-
Page 2: Table Of Contents
User Manual Meat Grinders Table of Contents Safety Precautions .............................3 Parts Identification .............................4 Assembly ..............................5 Sausage Stuffing Assembly ........................5 Operation ..............................6 Cleaning & Maintenance ..........................6 Troubleshooting ............................6 NEMA 5017210 5017210 5-15P CONFORMS TO NSF STD NSF-8 CONFORMS TO UL STD UL-763 www.AvantcoEquipment.com... -
Page 3: Safety Precautions
User Manual Meat Grinders Safety Precautions WARNING FIRE, ELECTRICAL SHOCK, OR SERIOUS INJURY CAN OCCUR The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product, but must be supplied by the operator. -
Page 4: Parts Identification
User Manual Meat Grinders CAUTION • DO NOT disassemble the grinder during operation. • Avoid contact with moving parts. Never feed meat by hand. Always use the meat stomper. • DO NOT use the grinder if the power cord is broken. Please return the unit to the place of purchase or contact customer service. -
Page 5: Assembly
User Manual Meat Grinders Assembly Make sure power cord is disconnected. 2. Place housing into enclosure and make sure pin is aligned with hole in enclosure. 3. Hand tighten the thumbscrew to hold housing in place. 4. Place white washer onto back of auger. 5. -
Page 6: Operation
User Manual Meat Grinders Operation Place grinder on a stable and secure surface. 2. Install the sausage stuffing assembly (optional). NOTE: It is recommended that 2 people perform sausage stuffing. 3. Plug the unit into an appropriate electrical socket (110V/60Hz). 4. - Page 7 User Manual Meat Grinders Issue Possible Problem Solution Turn off grinder and unplug the unit. Find the Locking Bolt (or button) on grinder neck and disengage it, press the grinder Grinder head isn't head firm and reinsert the Locking Bolt (or button) until it is securely attached.
