- Page 1 User Manual User Manual Electric Meat Tenderizer Models: 177MT64, 177MT64KT12, 177MT64KT316, 177MT64KT34, 177MT64KT38 09/2020 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Important Safety Information
User Manual INTRODUCTION 1. We advise you to carefully read the instructions contained in this package. 2. To best use the meat tenderizer, you must be thoroughly familiar with its performance and operating features. 3. Maintenance requires just a few simple steps. 4. -
Page 3: Specifications
Attachment 3/8" Accessory Item Number Description 177MT64RB Meat Tenderizer Replacement Blade for 177MT64 177MT64SA12 Meat Tenderizer Stripper Attachment 1/2" for 177MT64 177MT64SA316 Meat Tenderizer Stripper Attachment 3/16" for 177MT64 177MT64SA34 Meat Tenderizer Stripper Attachment 3/4" for 177MT64 177MT64SA38 Meat Tenderizer Stripper Attachment 3/8" for 177MT64... - Page 4 User Manual Assembly Instructions Note: Always unplug the appliance from the electrical 4. Turn the wrench tool to adjust the power outlet before assembling or disassembling. shafts of blades into firing position. 1. Switch off the machine. Make sure machine is unplugged 5.
- Page 5 User Manual Operating Instructions CAUTION: Before connecting your units to the power supply, be sure the machine’s electrical specifications, printed in the unit’s serial plate, match those of your local power. Be sure to follow the operating instructions and safety guidelines for the motor unit onto which you install the meat tenderizer attachment.
- Page 6 User Manual Disassembly Instructions 1. Switch off the machine. Make sure machine is 4. Remove the blade attachment. Wear unplugged cut-resistant gloves since the blades are sharp. 2. Lift up the shield by pulling up the knob. 5. Disassembling complete. 3.
- Page 7 User Manual Cleaning Note: Always unplug the appliance from the electrical power outlet and let it cool down completely before cleaning & storage. 1. Wash all parts thoroughly with warm, soapy water NOTE: A long bristle brush is recommended for cleaning (sold seperately) 2.
-
Page 8: Troubleshooting
User Manual Troubleshooting If meat gets jammed in blades, turn the motor to the "OFF" position and disconnect from the power source. Lift stainless steel shield, clear the jam using steel tongs. If meat is not cutting through cleanly, check to make sure that the knives on both sides are aligned so the blades are overlapping and make contact with the blades on the other rack. - Page 9 User Manual Parts Diagram Part No. Part Name Part No. Part Name Part No. Part Name Screw Electric Box 6202 Bearing Front Plate Over-Current Swith Microswitch Shaft Protector A Capacitor Fixed Plate Rotating Shaft Clamp of Capacitor (#177PMT64SHFT) Lock Smooth Blade (MSA) Power Cord (#177PMT64LOCK) Serrated Blade...
-
Page 10: Circuit Diagram
User Manual Circuit Diagram www.AvantcoEquipment.com... - Page 11 Avantco reserves the right to approve or deny the repair or replacement of any part or repair request. The warranty is not transferable. Avantco Equipment installed in/on a food truck or trailer will be limited to a period of 30 days from the original date of purchase.
