Summary of Contents for PORODO PD-GAIFTGR-WH
- Page 1 Gimbal With AI Face tracking Gesture Recognition With Remote Controller SKU: PD-GAIFTGR-WH...
- Page 2 Table of Content...
- Page 3 Schematic View of Porodo Gimbal A: Smartphone Holder B: Bluetooth Indicator C: Battery Level Indicator D: Camera E: Tracking Indicator F: Power Button G: Gesture Indicator Bluetooth Indicator 3. Indicator light is solid (on): Bluetooth is connected. Note:The Bluetooth indicator is paired with the remote in case the remote is connecte to the Gimbal.
- Page 4 Switch for rotation of holder from landscape to portrait position and vice versa. Tilt Angle Adjustment Input/ Output : Type-C USB port Base Clip Base Screw (Thread: 1/4") Base Note: To remove the device from the base, press the base clip and rotate the Gimbal.
-
Page 5: Getting Started
Getting Started 1.Installing the Smartphone Install the smartphone securely, as illustrated by the picture. It might be necessary to remove the phone casing beforehand. 2.Power Button Use the power button to turn the device ON/OFF. The function of the power button includes as follows: 1. - Page 6 3.AI Gesture Recognition To turn ON the face tracking feature: Perform an "OK" gesture before the camera. To turn OFF the face tracking feature: Make the "Palm" gesture before the camera. Tips: 1. To start tracking no Bluetooth connection or installation of App is required. 2.
- Page 7 Net Weight 269 gr Material ABS+PC Dimensions (Gimbal) 58.5×58.8×188 mm Dimension (Base) 100 mm Payload 500 gr Battery capacity 4000 mAh Charging input Type-C cable (5V/2A) Diagonal: 180 mm Compatible smartphone Width: 5 to 90 mm range Thickness: 9.5 mm Device Bluetooth name "Z9_XXXX"...
- Page 8 Bluetooth/Power Indicator Red light: Change the battery. Flashing blue light: The remote is not connected to the Gimbal. Flashing twice in blue light: The Remote is paired with the Gimbal. Solid blue light: The remote is successfully connected to the Gimbal. Note: The remote is connected to the Gimbal via Bluetooth connection.
- Page 9 Steps to pairing the remote 1. Pairing the remote to the Gimbal With the assumption that both the remote and Gimbal are powered off, proceed with the following steps: 1.1 Start the remote and the Gimbal at the same time. 1.2 Keep pressing the power button for 5 seconds until the Bluetooth indicator light is solid and blue-colored.
-
Page 10: Storage And Maintenance
4. Avoid overcharging or completely discharging the battery, as it could result in damage. 5. Do not operate the product in extremely high or low temperatures. Warranty When you buy Porodo products from any of our approved sellers, you only get... - Page 11 Don't forget to upload a picture of the product too. After we've checked and warranty has been extended. For more info, please check: porodo.net/warranty Contact Us If you have any questions about this Privacy Policy, please contact us at: info@porodo.net Website: porodo.net Service Support: support@porodo.net Instagram: porodo...
