User Manual
Section 1
This Quick Installation Guide only provides basic instructions for installing the
product. For detailed information on using this product, please refer to the
Installing the Software in Windows XP/2000/ME
Note:
Do not
connect the USB Bluetooth Adapter to your computer before you
install the provided software. You will be prompted to plug the device during the
installation.
Step 1
Insert the Bluetooth software installation CD into your CD-ROM drive.
When the auto-run screen appears, select Install Utility and Driver for
XP/2K/ME
Quick Installation Guide
Bluetooth® 2.0 USB Adapter
Model # ABT-U200
User's Manual on the supplied CD.
Package Content:
•
Bluetooth® 2.0 USB
Adapter
•
Driver & Utility CD
•
Quick Installation Guide
Ver. 1A
Advertisement
Related Manuals for Airlink101 ABT-U200
Summary of Contents for Airlink101 ABT-U200
-
Page 1: Quick Installation Guide
Insert the Bluetooth software installation CD into your CD-ROM drive. When the auto-run screen appears, select Install Utility and Driver for XP/2K/ME Bluetooth® 2.0 USB Adapter Model # ABT-U200 Package Content: User’s Manual on the supplied CD. • Bluetooth® 2.0 USB Adapter •... - Page 2 Note: If the auto-run window does not appear automatically, go to Start -> Run and type D:\Utility\XP_2K_ME\Setup.exe (where D is the letter of your CD- ROM drive) then click OK. Step 2 When the welcome screen appears, click Next. Then click Next on the two screens that follow, then click Install.
- Page 3 Windows XP/2000 Users: appears, click OK. Step 3 When prompted, plug your Bluetooth USB adapter into an available USB port on your computer and click OK. Please wait while the software installs all the supported services. This may take several minutes. Windows 2000/ME Users: You may be prompted to restart your computer a few times during the installation.
- Page 4 Windows 2000/ME Users: At the end of the installation, you will be prompted to restart your computer. Click OK to restart. The Initial Bluetooth Configuration Wizard will automatically launch to guide you through the initial configuration. Step 5 Click Next at the Initial Bluetooth Configuration Wizard screen. Step 6 Enter a unique name to identify your computer and select a computer type, then click Next.
- Page 5 Step 7 Click Next at the following screen Step 8 This screen allows you select the services you want to provide to other Bluetooth devices. If you wish to have all services available, make sure that they are all checked and click Next.
- Page 6 Step 9 Click Skip at the following screen. Step 10 Click Finish. Your device is now installed and ready to use. Please refer to the manual located on the CD for detailed instructions on configuring and using the Bluetooth USB adapter.
- Page 7 Section 2 Installing the Software in Windows Vista Note: Do not connect the USB Bluetooth Adapter to your computer before you install the provided software. You will be prompted to plug the device during the installation. Step 1 Insert the Bluetooth software installation CD into your CD-ROM drive. When the auto-run screen appears, select Install Utility and Driver for Vista Note: If the auto-run window does not appear automatically, go to Start ->...
- Page 8 Step 2 If the following warning window appears, click Allow to continue with the installation. Step 3 When the following screen appears, connect the Bluetooth USB adapter to an available USB port on your computer.
- Page 9 Step 4 At the welcome screen, click Next. Then click Next on the two screens that follow until you get to the Install Screen. Step 5 Click Install to install the Bluetooth software. Please wait while the software installs all the supported services. This may take several minutes.
- Page 10 Step 6 The following Windows Security alert may appear a few times during the installation. Click Install this driver software anyway to continue installing the software. Step 7 At the end, click Finish. Your device is now installed and ready to use. Please refer to Section 3 in the manual located on the CD for detailed instructions on configuring and using the Bluetooth USB adapter.
-
Page 11: Technical Support
Environmental factors will adversely affect wireless signal range. Specifications are subject to change without notice. All products and trademarks are the property of their respective owners. Copyright ©2007 Airlink101®...
