SBC sbc2652 User Manual

2.4ghz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury to persons, including
the following:
1.
Read and understand all instructions.
2.
Follow all warnings and instructions marked on the product.
3.
Unplug this product from the wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a damp cloth for cleaning.
4.
Do not use this product near water (for example, near a bath tub, kitchen
sink, or swimming pool).
5.
Do not place this product on an unstable cart, stand, or table. The product
may fall, causing serious damage to the product.
6.
Slots and openings in the cabinet and the back or bottom are provided
for ventilation. To protect it from overheating, these openings must not be
blocked by placing the product on a bed, sofa, rug, or other similar
surface. This product should never be placed near or over a radiator
or heat register. This product should not be placed in a built-in installation
where proper ventilation is not provided.
7.
This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your dealer or local power company.
8.
Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be abused by persons walking on it.
9.
Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could result
in a risk of fire or electric shock. Never spill liquid of any kind on the product.
10.
To reduce the risk of electric shock, do not disassemble this product, but
take it to an authorized service facility. Opening or removing cabinet parts
other than specified access doors may expose you to dangerous voltages
or other risks. Incorrect reassembling can cause electric shock when the
appliance is subsequently used.
11.
Do not overload wall outlets and extension cords as this can result in the
risk of fire or electric shock.

Important Safety Instructions

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the sbc2652 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SBC sbc2652

Summary of Contents for SBC sbc2652

  • Page 1: Important Safety Instructions

    When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product.

  • Page 2: Save These Instructions

    Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Do not use the telephone to report a gas leak in the vicinity of the leak. SAVE THESE INSTRUCTIONS...

  • Page 3: Introduction

    The 2652 is an advanced cordless telephone that operates in the 2.4GHz frequency range. Your 2652 is capable of supporting up to a maximum of 4 Handsets. Using additional Handsets, up to three people can be conferenced on a call (2 Handsets and the Base Speakerphone), or two extensions can be conferenced on a call, while two other extensions can be talking internally, using the Intercom feature.

  • Page 4: Parts Check List

    Base Unit Handset AC Power Adapter Telephone Cord Parts Check List Battery Pack Belt Clip User's Manual...

  • Page 5: The Handset Layout

    Antenna Message Waiting Indicator Earpiece Headset Jack (2.5mm) Scroll Keys On/Flash Dialing Key (0 - 9, *, #) Handsfree Speakerphone The Handset Layout LCD Display 10. Select 11. Off/Clear 12. Intercom 13. Billed Services 14. Microphone...

  • Page 6: The Base Unit Layout

    The Base Unit Layout...

  • Page 7: Setup

    Base Unit. Connecting to phone line Plug one end of the telephone line cord into the jack on the back of the Base Unit. Plug the other end of this cord into the wall jack.

  • Page 8: Installation Of Battery Pack In Handset

    Installation of Battery Pack in Handset The original Handset that is shipped with your 2652 system will be automatically registered to the Base. This Handset is HANDSET 1. As you register additional Handsets to the system, they will be assigned extension numbers in the following order: HANDSET 2, HANDSET 3, and finally HANDSET 4.

  • Page 9: Spare Battery Charger/Power Backup Function

    Spare Battery Charger/Power Backup Function The 2652 can use the spare battery in the Base Unit to provide operational backup in the event of a power failure. With a fully charged battery pack in the spare battery charger, you will still be able to place and receive calls from the Handset for up to 3 hours.

  • Page 10: Charging Of Handset Battery Pack

    The Handset of your 2652 cordless telephone is powered by a rechargeable battery pack. It charges automatically whenever the Handset is in the Base Unit. You should charge the battery pack for 12 hours when you first receive your phone. You'll know the battery pack needs charging when: •...

  • Page 11: Registration And Operation

    Registration and Operation of the 2603 Accessory Handset Your 2652 system can operate up to 4 Handsets. The accessory Handset consists of the following: Registration and Operation Setup of the 2603 Accessory Handset Plug the AC power adapter into an electrical outlet, then the DC connector into the bottom of the Charger Unit.
  • Page 12 Enter Base ID Code After charging the Handset, remove it from its Charge Cradle, the screen will display: Press NEW, then enter the 15 digit Base Unit ID code, located on the underside of the Base Unit. Press OK. The Handset will display: PLEASE WAIT!! Wait approximately 15 seconds.

  • Page 13: Handset And Base Indicators

    Handset Icons Description Icon Line In Use indicator On steady with no number next to it when a parallel set is in use. On steady with one or more numbers next to it, indicating which extensions are using the line. For example, that Handset 1 and Handset 2 are on an outside call.
  • Page 14 • Lights when line is being used by any Handset of the 2652 In Use system. • Flashes when another telephone on the same line (parallel extension) is in use. • Flashes following ringing cadence during ringing. • Lights whenever the Handset is placed in the Base Unit Charge charging cradle.

  • Page 15: Soft Menu Functions

    Example of the idle mode display: RDL (Redial) Press RDL to display the last 5 telephone numbers dialed. The number on top line is the most recent number dialed. • Use the •...

  • Page 16: Calls Log (Caller Id)

    NOTES ABOUT CALLER ID & CALL WAITING CALLER ID These are subscription services, provided by most regional telephone service providers. You must subscribe to these services to get the benefits of these features.

  • Page 17: Handset Settings

    From the Handset Settings menu you can select the following options to modify: • RINGER VOLUME Select this option to adjust the ringer volume. Use the to adjust the volume up or down. The Handset will display a graphic indicator of the selected volume setting. Press OK to confirm your selection and return to the Handset Settings menu.

  • Page 18: Range Extender

    Your 2652 has an enhanced feature that is designed to improve performance. This feature is useful if you are using your 2652 in an area with excessive interference or you require a moderate increase in operating range. the Range Extender feature can help to improve both the sound quality and range. Actual range will depend on your environment.
  • Page 19 The 2652 can store up to 50 numbers with names in memory. Each memory location can hold up to 32 digits for the number for the number and up to 16 characters for the name. When prompted to ENTER NAME, use the digit keys to 'spell' the name. Each press of a particular key causes characters to be displayed in the following order: Number Key MEM (Memory)

  • Page 20: Mem (Memory)

    To Store a Number/Name: • Starting from the idle screen, enter the number you want to store in memory. • Be sure to include long distance codes and pauses (using the Pause softkey) if necessary. Press OFF to correct if you make mistake.

  • Page 21: To Search For And Dial A Number/Name

    To Search For and Dial a Number/ Name: • Starting from the idle screen, press the MEM softkey to review memory contents. • Using softkeys scroll through the memory contents in alphabetical order. Or, you can press the FIND softkey, enter the first few chararcters of the name.

  • Page 22: To Edit A Name Or A Number

    • Press the DEL softkey. Handset will display: • To delete the displayed records, press THIS. To delete all records, press ALL. • If you press ALL, The screen will display: ARE YOU SURE? • To confirm the deletion of all records, press YES.

  • Page 23: Base Settings

    The 2652 Base Unit has several settings that can be adjusted according to your preference and system requirements. Select Base Ringer Melody: • The phone must be off. • Press the star key three times ( and the Power and In Use LEDs will flash rapidly. •...

  • Page 24: Select Base Ringer Volume And Off

    Select Base Ringer Volume and OFF: • The phone must be off. • Press the star key three times ( and the Power and In Use LEDs will flash rapidly. • Press the volume up and down keys ( volume. After each press of the volume keys, the Base will emit the selected Ringer and volume setting for one second.

  • Page 25: Handset And Base Operation

    Redial from Base Unit • Pressing REDIAL will immediately dial the last number in the Base Unit redial memory. • Hold down the REDIAL key for more than 2 seconds to erase the contents in redial memory. This is to prevent the accidental dialing of the number stored in redial memory.

  • Page 26: Mute Function

    Your 2652 is compatible with Call Waiting Deluxe. In order to use this feature you must subscribe to this service through your local telephone company. Your 2652 will automatically enter into Call Waiting Deluxe mode if you receive a call waiting signal. Upon receiving a call waiting signal, the caller ID information will be displayed for about 10 seconds.

  • Page 27: Volume Control

    Send a hold message to your waiting call Forward the waiting call to your Voicemail* * Voicemail service, provided by your local telephone company, is required. If you do not wish to disposition a call, simply press EXIT. Handset and Base Operation...

  • Page 28: Handsfree Speaker Operation

    • To end an intercom call, press OFF on the Handset or PAGE on the Base. From Base to a particular Handset: • Press the Base PAGE key, then press the number of the Handset you want to call (e.g. Handset 2). •...

  • Page 29: Line In Use Indication

    CALLS in HANDSET AND BASE OPERATION. Line in Use Indication On the Handset: When the telephone line is currently being used by a system Handset or the 2652 Base, a status message similar to this will display on idle Handset(s):...

  • Page 30: Conference Calling

    Conference Calling The 2652 is capable of supporting conference calls with up to two registered Handsets and the Base Unit. To enter a conference call, simply access the line with two or three extensions by pressing ON (or HANDSFREE) on the Handset or SPEAKER on the Base. The phone icon and two or three extension numbers will be displayed in the upper left corner of the Handset.

  • Page 31: Message Waiting

    Press EDIT. Enter the voicemail access number provided by your local telephone company. To enter pauses, or delete characters, use the MORE key. When done press SAVE.

  • Page 32: Using The Dedicated Play, Skip And Erase Keys

    Reprogramming PLAY The default PLAY access number is 1. If this does not match the number provided by your local telephone company, you will need to edit the number. Press EDIT. Enter the PLAY access number provided by your local telephone company.

  • Page 33: Skip Access Key

    Press EDIT. Enter the ERASE access number provided by your local telephone company. To enter pauses, or delete characters, use the MORE key. When done press SAVE.

  • Page 34: Name And Number Announce Caller Id

    Name and Number Announce Caller ID Name and Number Announce Caller ID is an advanced feature that enables your telephone to announce the name or telephone number of callers before you answer the call. Announcements are made from the Base Unit speaker. You must subscribe to Caller ID service in order to use this feature.

  • Page 35: Review, Play, Erase Or Re-Record A Name And Number Announcement

    Name and Number Announce Caller ID • Press the RECORD key. You will be prompted to RECORD AFTER TONE. into the handset microphone to record up to 3 seconds of audio. • You can press the STOP key when you are done, or simply wait for recording to automatically stop after 3 seconds.

  • Page 36: Custom Pay-Per-Use(Ppu) Features

    NOTE: For handset Pay-Per-Use, press handset BILLED SERVICES key. Then It is likely that your local telephone company will assess charges to use custom features.You should check with your local service provider regarding which custom services are available in your area, and the associated costs for the intentional or unintentional use of Pay Per Use services.

  • Page 37: Headset Operation

    Your 2652 cordless telephone is equipped with a 2.5mm Headset Jack for use with an optional accessory Headset for hands-free operation. To purchase a Headset, call 1-800-244-1111. Once you have a compatible 2.5mm Headset, locate the Headset Jack on the Handset.

  • Page 38: In Case Of Difficulty

    First check all the suggestions above. • If you still don't hear a dial tone, disconnect the Base Unit from the telephone jack and connect a different phone. If there is no dial tone on that phone either, the problem is in your wiring or local service. Contact your local telephone company.
  • Page 39 You Hear Noise In The Handset, And None Of The Keys Or Buttons Work • Make sure the power cord is plugged in. Common Cure For Electronic Equipment If the unit does not seem to be responding normally, then try putting the Handset in the cradle.

  • Page 40: Maintenance

    Avoid Water Your telephone can be damaged if it gets wet. Do not use the Handset outdoors in the rain, or handle it with wet hands. Do not install your Base Unit near a sink, bathtub or shower.

  • Page 41: Limited Warranty

    Limited Warranty The Supplier warrants, to the original purchaser only, the material and workmanship of this product for ONE YEAR from the date of purchase. We will repair or replace, at our option, this product without charge should it fail due to a defect in material or workmanship within that time period.

  • Page 42: Fcc And Acta Regulations

    • Consult the dealer or an experienced radio/TV technician for help. FCC and ACTA Information If this equipment was approved for connection to the telephone network prior to July 23, 2001, it complies with Part 68 of the Federal Communications Commission (FCC) rules.
  • Page 43 The REN is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. In most, but not all areas, the sum of all RENs should be five (5.0) or less. You may want to contact your local telephone company for more information.
  • Page 44 This feature is provided only as a convenience, and the manufacturer assumes no responsibility for customer reliance upon the memory feature. c. Testing the emergency telephone numbers you have stored is not recommended. However, if you do make a call to an emergency number: •...

  • Page 45: Technical Specifications

    FREQUENCY CONTROL Crystal controlled PLL synthesizer TRANSMIT FREQUENCY 2401.056-2482.272 MHz RECEIVE FREQUENCY 2401.056-2482.272 MHz CHANNELS 95 Channels NOMINAL EFFECTIVE RANGE Maximum power allowed by FCC. Actual operating range may vary according to environmental conditions at the time of use. SIZE Handset : 176mm x 51mm x 41mm Base : 178mm x 128mm x 68mm...

  • Page 46: Table Of Contents

    Table Of Contents 1. I m p o r t a n t Instructions 3. Introduction Parts Check List The Handset Layout The Base Unit Layout 7. Getting Started Setup Installation of Battery Pack in Handset Spare Battery Charger/Power Backup Function 10.
  • Page 47 91-005520-030-000 ISSUE 0...
