4.
Align the seat with your toilet pan by
rotating and sliding the Flexi Fix brackets.
If required, lift the seat off the pillars to help
with the adjustment.
fig. 9
BRACKETS SHOULD BE SYMMETRICAL
6.
Carefully remove the seat
firmly secure the hinge brackets.
BOTTOM FIX INSTALLATION
(Fig. 11)
7.
Remove the spacer (K) from the Flexi Fix
Bracket. (See Fig. 13)
fig. 13
9.
Attach the seat onto the hinges to
complete the installation. You should hear
a click to confirm it is engaged.
fig. 15
(See Fig. 9)
without disturbing the bracket positions
(See Fig. 11 and 12). Do not to over-tighten.
HEX KEY (I)
FULLY TIGHTEN.
NUT KEY (H)
(See Fig. 15)
5.
Once you are confident with the position of
your seat, apply pressure on each Flexi Fix
bracket and collapse the supports.
Hold down for 20 seconds. (See Fig. 10)
fig. 10
and fully tighten the screws (J) to
TOP FIX INSTALLATION
OR
8.
Place the chrome caps (A) onto the
brackets.(See Fig. 14)
fig. 14
10.
To activate the quick release function,
press and hold the button, then lift the
seat away. (See Fig. 16)
fig. 16
Note:
For Constance seat, button located at the front.
For Michigan seat, button located at the back.
4
20s
(Fig. 12)
HEX KEY (I)
FULLY TIGHTEN.
TS 074 R04
