Please follow all assembly and product care instructions to ensure that your product
is assembled safely and retains it's high quality finish.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
SAFETY & PRODUCT CARE
1.
To retain the best quality finish, clean product with a soft cloth and a mild soap solution.
DO NOT
2.
use abrasive or chemical cleaners as they may damage the surface of the toilet seat or hinges.
3.
Spray any cleaning liquids onto the cloth and not directly onto the product.
DO NOT
4.
force the seat down as this can cause damage to the product and its function.
5.
Take care when cleaning the toilet pan with chemical cleaners. Avoid contact of the chemical cleaners
with the toilet seat or hinges. Immediately rinse off any splashes to avoid damage or discolouration to the
surface of the toilet seat and hinge parts.
A
x2
CHROME CAP
x2
B
FLEXI FIT BRACKET
K
SPACER
SOFT CLOSE, QUICK
RELEASE TOILET SEAT
(J-X49 HINGE BARREL)
CONTACT DETAILS
SUPPLIED WITH INDIVIDUAL PRODUCTS MAY
x2
C
SUPPORT COVER
x2
D
RUBBER PLUG
I
Croydex
Central Way
Andover
Hampshire
SP10 5AW
UK
ALL PRODUCT DIMENSIONS DETAILED IN
THIS INSTALLATION AND MAINTENANCE
MANUAL ARE APPROXIMATE
ALL ILLUSTRATIONS OF THE PRODUCT ARE
FOR REFERENCE ONLY. COMPONENTS
DIFFER
H
NUT KEY
CONICAL
x2
E
WASHER
x2
F
WASHER
G x2
NUT
Tel: +44 (0)1264 365881
Email: info@croydex.co.uk
www.croydex.com
J x2
BOLT
I
HEX KEY
TS 073 R03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Croydex Ontario WL602086H
Summary of Contents for Croydex Ontario WL602086H
- Page 1 (J-X49 HINGE BARREL) CONTACT DETAILS Croydex Tel: +44 (0)1264 365881 Central Way Andover Hampshire Email: info@croydex.co.uk SP10 5AW www.croydex.com ALL PRODUCT DIMENSIONS DETAILED IN THIS INSTALLATION AND MAINTENANCE MANUAL ARE APPROXIMATE ALL ILLUSTRATIONS OF THE PRODUCT ARE FOR REFERENCE ONLY. COMPONENTS...
- Page 2 WHAT TO KNOW BEFORE INSTALLING... When positioning the seat onto the pan ensure that the lid and ring can be lifted and remain (See Fig. 1) upright on the pan. Before activating the grip pad technology, ensure the toilet seat is in a perfect position as it can be difficult to reposition when attached.
- Page 3 INSTALLATION Identify your toilet pan style. Loosely intall the Flexi Fit bracket through the mounting holes using either bottom installation (See Fig. 2) or top installation (See Fig. 3). DO NOT COLLAPSE THE SUPPORTS. CHOOSE BETWEEN BOTTOM FIX INSTALLATION TOP FIX INSTALLATION This installation is designed to be used on ‘standard’...
- Page 4 Carefully remove the seat, avoid disturbing the bracket positions and fully tighten the bolts to firmly secure the Flexi Fit brackets. (See Fig. 8 and 9). Be careful not to over-tighten. BOTTOM INSTALLATION TOP INSTALLATION (Fig. 8) (Fig. 9) Remove the spacer from the Flexi Fit Bracket. Place the chrome caps onto the brackets.
