Module Event Log - ProSoft PLX51-DF1-MSG User Manual

PLX51-DF1-MSG
DF1 Messenger

Module Event Log

5.4
The PLX51-DF1-MSG module logs various diagnostic records to an internal event log.
These logs are stored in non-volatile memory and can be displayed using the PLX50
Configuration Utility or via the web interface. To view the logs in the PLX50
Configuration Utility, select the E
The Event Viewer dialog opens and automatically reads all the events from the module.
The log entries are displayed with the latest record at the top. Custom sorting is
achieved by double-clicking on the column headings.
The log can also be stored to a file for future analysis, by selecting the S
the tool menu.
To view previously saved files, use the E
ProSoft Technology, Inc.
V option in the Project Explorer tree.
VENT IEWER
Figure 5.11 – Selecting the module Event Log
Figure 5.12 – Module Event Log
L
VENT
V option under the Tools menu.
OG IEWER
Diagnostics
