MTZ Kirovets K-744 2020 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operator Manual
Kirovets K-744
©
If this product contains a gasoline engine
CALIFORNIA
WARNING
Proposition 65 Warning
Diesel engine exhaust and some of its constituents
The engine exhaust from this product contains
are known to the State of California to cause
chemicals known to the State of California to cause
cancer, birth defects and other reproductive harm
cancer, birth defects and other reproductive harm
The State of California requires the above two warnings. Additional Proposition 65 Warnings can be found in the manual
®
P/N MTZOMK-744
