  • Page 1 ASSEMBLY INSTRUCTION MANUAL Loader MTZ 952/1220 Hose Kit “A” X3944 Instructions 042013 P4731...
  • Page 3 Only qualified personnel should perform these CAUTION procedures. Damage to the hydraulic system may occur unless properly installed. WARNING Read the following safety information Hydraulic Safety Escaping fluid under pressure can have sufficient force to penetrate the skin, causing seroius personal injury. Before repairing, adjusting, or disconnecting lines, be sure to relieve all pressure.
  • Page 4 Instructions If the right and left hand brackets (13 & 14) weren’t placed on the axle mounts when the mount kit was installed, do so now. See Graphics 1 & 2. 2. Assemble the bulkhead plate (1) to the plate on the RH mount as shown in Graphic 3, using the M10 nuts and bolts provided (2 &...
  • Page 5 5. Place two 90° elbows (5) in the two inside quick connectors. For a 952, place two more 90° elbows on the outside quick connectors also. For a 1220, place the two 45° elbows (20) on the outside two quick couplers.
  • Page 6 22. Connect the quick couplers at this time. On the 1220 the quick couplers for the lift cylinders are on the left hand side. On the 952 they are on the right hand side. Move the quick couplers (either at the bulkhead plate or at the tractor quick couplers) up or down to get the correct loader operation.
  • Page 7 X3944 Parts List Item # Part Number Description Quantity 816603 Plate Bulkhead 00043435 Nut Hex Flg Usr M10 (Pl) 812734 Elbow 90 7/8 Mjic x 7/8 Orb 09840672 Bolt Hex Flg M10 x 30 8.8 (Pl) 811416 Elbow 90 7/8 Morb x 3/4 Mjic 812924 Snap Ring N1400 0150 86018680 813308...
  • Page 8 Bolt Torque Chart Standard Bolt Size Grade 2 Grade 5 Grade 8 (in) Torque Torque Torque ft-lb ft-lb ft-lb 0.25 0.313 0.375 0.438 0.563 0.625 0.75 0.875 1232 1.125 1077 1288 1745 1.25 1120 1518 1817 2462 1.375 1470 1992 2382 3228 1179...
  • Page 10 3-1136 Centre St., Ste. 124, 36 Renaissance Crt. Thornhill, Ontario, Thornhill, Ontario L4J 3M8 Canada Canada, L4J 7W4 Tel: 1-855-246-4689 | Fax: 1-647-933-9066 Ph.: 1.855.246.4689 | Fax: 1.647.933.9066 www.mtzequipment.com www.mtzequipment.com Equipment shown is subject to change without notice. ©2013 MTZ Equipment Ltd.
