4. Cabling the RX-PANEL
The figure below shows the RX-PANEL's connector ports.
Port
1
DC jack for 12V power adapter.
2
Reset (insert pin, unplug PoE, keep pin inserted, plug in PoE, keep pressing for 10 seconds).
3
Ethernet LAN/PoE GbE, RJ-45.
4
USB Type C connector (for maintenance purposes) (see the User's & Administrator's Manual).
5. Powering up
The RX-PANEL can be powered by connecting the RX-PANEL to the power adapter or connecting RX-PANEL
LAN/PoE to any PoE Ethernet switch.
6. Managing RX-PANEL
RX-PANEL is managed by AudioCodes' One Voice Operations Center | Device Manager. It can also be
managed by Microsoft Teams Admin Center (TAC). Management includes (but not limited to):
✓
Firmware management / upgrade
✓
Alarm management
✓
APK upgrade
4
1
2
3
Description
P a g e
| 3
