Summary of Contents for Vox MINI3
-
Page 2: Power Supply
Keep this manual After reading this manual, please keep it for later reference. Keeping foreign matter out of your equipment Never set any container with liquid in it near this equipment. If liquid gets into the equipment, it could cause a breakdown, fire, or electrical shock. Be careful not to let metal objects get into the equipment. If some- thing does slip into the equipment, unplug the AC adapter from the wall outlet. Then contact your nearest VOX dealer or the store where the equipment was purchased. * All product names and company names are the trademarks or registered trademarks of their respective owners. THE FCC REGULATION WARNING (for USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses, and can radiate radio... -
Page 3: Table Of Contents
Setup -------------------------------------------- 5 Installing Batteries -------------------------------------5 The Guitarist’s Guided Panel Tour ---- 6 Top Panel-------------------------------------------------6 Rear Panel -----------------------------------------------8 Using the Tuner ------------------------------ 9 Amp Models and Effects ----------------10 AMP model -------------------------------------------- 10 Effects --------------------------------------------------- 11 Delay/Reverb ------------------------------------------ 12 Troubleshooting ----------------------------13 Specifications -------------------------------14... -
Page 4: Introduction
Introduction Welcome aboard! Thanks for choosing the VOX MINI3. To ensure a long and trouble-free relationship with your new amp, please read this manual carefully, use the amp as directed and keep the manual for future reference. We hope you enjoy the great sound of the VOX MINI3! Main features l The compact MINI3 features three watts (3W) producing stellar tones inherited from the VOX Valvetronix series (VT15, VT30, VT50, VT100). l This portable amplifier is powered by six AA-size alka- line batteries or the included AC adapter, enabling you to play anywhere. During battery operation, you can play for up to 10 hours. l In addition to four high-quality, all-time favorite effects, the amplifier features four delay and reverb effects that simulate acoustic reverb. The amplifier also features a user-friendly interface, enabling you to adjust the tone via a single knob. l The TAP button enables you to easily set the delay time in sync with the tempo. l The built-in tuner function enables you to tune a guitar connected to the INPUT jack. l Inputs include an AUX IN jack, for connecting an external audio device (CD, MP3 player, etc.), and a MIC IN jack, to which you can connect a microphone. You can play along with recorded music or accompany your vocals on guitar. -
Page 5: Setup
Setup This section describes the basic setup of your amplifier. NOTE: This manual also describes safety precautions and functions. Be sure to read the entire manual. 1. Turn the MASTER volume on the amp all the way down. 2. Install batteries in the amplifier. Alternatively, you can connect the included AC adapter to the DC12V jack on the rear panel, then plug the adapter into an AC outlet. 3. Plug your guitar into the INPUT jack on the top panel. If you also plan to use a CD or MP3 player, or a microphone, connect the player to the AUX IN jack or the microphone to the MIC IN jack on the top panel. 4. Turn on the STANDBY switch. 5. Slowly raise the MASTER volume to a desired level. Installing Batteries Remove the battery compartment cover located on the bot- tom of the unit by pulling the ribbon. Insert six AA-size alkaline batteries as shown in the figure. Be sure to observe the correct polarity. NOTE: Batteries are not included. You will need to purchase them separately. Never use any type of battery other than alkaline batteries. -
Page 6: The Guitarist's Guided Panel Tour
1. INPUT jack This is where you plug in your guitar. 2. MIC IN jack Connect a microphone here. 3. TRIM knob Enables you to adjust the volume level of the microphone input. 4. DLY/REV SEND knob Enables you to adjust the send level from the microphone input to the delay/reverb effects. AMP section This section enables you to make various amplifier set- tings. 5. AMP selector This selector enables you to select an amp model. The gain circuit, tone control characteristics, and circuit layout will be set automatically in accordance with the selected amp model. For more information on each amp model, please refer to "Amp Model" on page 10. 6. GAIN knob This knob enables you to adjust the pre amp gain for the selected amp model. - Page 7 EFFECTS section Here you can adjust settings for the effects. For details on each effect, refer to “Effects” (page 12). 9. EFFECTS knob This knob enables you to select the effect type and set the intensity of the effect. To bypass the effects, rotate the knob all the way to the left. 10. D ELAY/REVERB knob This knob enables you to select a delay/reverb-type effect and set the intensity of the effect. To apply an effect (selected via this knob) to the micro- phone input, use the DLY/REVERB SEND knob to set the intensity of the effect. To turn off the delay/reverb effect applied to the guitar input, rotate this knob all the way to the left or set the knob to the minimum position of the "swoosh" of the corresponding effect type. 11. TAP switch, LED/TUNER LED indicator This switch enables you to set the time of the DELAY and REVERB effects. Tap this switch twice to set the time. The duration between two taps will be used as the time value. The indicator will flash in sync with the time. HINT: To set the time to exactly match the tempo of a song, press the TAP button several times along with the song. NOTE: If you turn off the power to the unit, the value set by the TAP button will be reset to its initial value.
-
Page 8: Rear Panel
STANDBY/AUX IN/PHONES Section 12. S TANDBY switch When the power is on, the indicator located upper left the switch will be lit. 13. A UX IN jack Connect an external audio device to this jack. This en- ables you to conveniently connect a CD or MP3 player and play your guitar along with the player’s output. 14. P HONES jack Use this jack if you’re plugging directly in to a mixer, re- cording device, or if you’re using headphones. The output signal from this jack is taken before the power amp, and the character of the guitar amp cabinet is applied to it. NOTE: Connecting headphones to this jack will mute the in- ternal speaker. NOTE: Be sure to make a stereo connection at the PHONES jack. With a monaural connection, no sound will be output. Rear Panel 1. DC 12V jack Connect this jack to the included AC adapter. -
Page 9: Using The Tuner
All effects are bypassed. (No valid signal is being input.) 2. Play the open 6th string. NOTE: Be careful not to touch any other strings. 3. Tune the guitar so that only the center green LED indica- tor lights up, as shown on the right. TIP: The MINI3 recognizes pitch E in any octave. This is useful if you want to tune to harmonics or tune other musical instruments, such as a bass gui- tar. 4. To exit the tuner function, press the TAP switch. The effect bypass will be canceled. TIP: Once you tune the 6th string using the tuner func- tion, tune the other strings in reference to the 6th string. -
Page 10: Amp Models And Effects
BTQ CLEAN This models the clean channel of a high-quality amp that was produced only on special order, and was known as the overdrive special. With a beautifully rounded low range, a sharp midrange attack, and a sweet treble register, this is ideal for single coil pickups. BLACK 2x12 This models a black-faced 2x12" combo amp that has become an indispensible item for country and blues players. Its tight and clean sound provides deep piano-like bass tones, and will deliver the classic Chicago blues tone particularly when used with single coil pickups. TWEED 4x10 This models a 4x10" combo amp from 1959 that was original- ly designed for bass guitar. Its smooth and crisp overdrive sound will respond sensitively to your picking dynamics and to the volume of your guitar. AC15 This models channel 2 of the VOX AC15 (1x12", 15W), which was manufactured in 1962 and was a big hit for its compact cabinet, power, and great tone – along with then-popular British bands. AC30TB This models an AC30 amp with the “top boost” circuit that was included as standard starting with units produced in 1964. It delivers a smooth and refined top end, majestically deep overdrive, and a rich and brilliant clean sound. UK '70S This models the high treble channel of a hand-wired amp head made in England during the early 60’s. Raising the volume of this 50W output amp all the way produces the crunch that will forever be the sound of rock ‘n’ roll. UK '80S This models a UK-manufactured 100W single-channel head with master volume made in 1983. Turn the GAIN control all the way up to get that thick, snarling hard rock and heavy metal sound that dominated the 80’s. -
Page 11: Effects
CALI METAL This models the modern high-gain channel from a wild beast of a high-gain amp. Its deep and loose low-end, spar- kling highs, and monstrous gain are ideal for guitars tuned as low as possible, or for metal acts wielding seven-string guitars. US HIGAIN This models the overdrive channel of a snakeskin-covered 100W amp head made in 1991. With an open low-end and a compressed mid/high range, its powerful and heavy sound delivers a forceful tone that will not break down even with the most extreme gain settings. LINE This model features two-band tone controls that create a pure clean tone with no distortion. Use the GAIN knob to adjust the volume level for the low range, and the TONE knob for the high range. Effects COMP This models a compressor that features a clean, percussive, and mellow sustain. Suitable for pop or funk rhythms. Use the knob to adjust the amount of sustain. CHORUS This models a standard analog chorus that adds a rich spa- ciousness to the sound. Use the knob to adjust the modulation speed. FLANGER This models an analog flanger that creates a sound with a peculiar swooshing effect like a jet engine. Use the knob to adjust the modulation speed. -
Page 12: Delay/Reverb
Use the knob to adjust the mix amount of the delay sound. Use the TAP switch to set the delay time. The longest pos- sible delay time is 1,486ms. TAPE ECHO This models a popular analog tape echo. Tape echo was originally created by using a playback head, and the delay time was adjusted by modifying the motor speed. The knob and switch functionality is the same as that for the ANALOG model. SPRING This models a spring reverb inside a guitar amp. Use the knob to adjust the mix amount of the reverb sound. Use the TAP switch to set the reverb time. ROOM This is a standard room reverb that contains a lot of initial reflection. The knob and switch functionality are the same as the SPRING model. -
Page 13: Troubleshooting
• Make sure sound is coming from the amp. You’ll need to unplug your headphones or cable from the PHONES jack to do this, since plugging something into this jack automatically mutes the amp’s speakers. If there’s still no sound from the amp, go to “There’s no sound coming from the amp.” If you do hear sound, check the headphones or cable you are hooking up to this jack. The effects cannot be applied to the sound. • Is the tuner function turned on? If the tuner function is turned on, the effects will be bypassed. Press the TAP switch to cancel the bypassing... -
Page 14: Specifications
Speaker: 5 inch 4 ohms Signal processing A/D conversion: 24-bit D/A conversion: 24-bit Sampling frequency: 44.1 kHz Tuner range: E1–E6 (41.2 Hz–1318.5 Hz) Six AA/LR6 alkaline batteries Power supply: or the included AC adapter Battery life: Maximum 10 hours 175 mA Current consumption: Dimensions (W x D x H): 262 x 174 x 223 mm 10.31 x 6.85 x 8.78 inches Weigh: 2.8 kg/6.17 lbs. Included items: AC adapter (DC 12V * Appearance and specifications of this product are subject to change without notice. For more information on Vox products, please visit our website at www.voxamps.com... -
Page 15: Program Sheet
Program Sheet Copy the following blank program sheet, and record your favorite sound settings. PROGRAM NAME: NOTE:... - Page 16 WARNING: Use of this product in any country other than that for which it is intended could be dangerous and could invalidate the manufacturer's or distributor's warranty. Please also retain your receipt as proof of purchase otherwise your product may be disqualified from the manufacturer's or distributor's warranty. 2010 VOX AMPLIFICATION LTD.
