Verilux CleanWave VH03 - UVC Sanitizing Travel Wand with CleanWave Technology Manual

Features

Your new Verilux^® CleanWave^® Portable Sanitizing Wand kills up to 99.9% of germs and odor-causing bacteria on household surfaces.^†

Laboratory proven to eliminate up to 98% of germs and bacteria in just 1 second^†
Kills germs on keyboards, remote controls and electronics in seconds without residue^§
Sanitizes bathroom surfaces quickly and easily without chemicals or irritants^§
Fits easily in your purse or luggage

† Kills up to 99.9% of germs, viruses and other micro-organisms on solid, non-porous surfaces. Sanitizing times and effectiveness for porous surfaces will vary.
‡ Based on exposure of UV-C light to test organisms in laboratory on non-porous hard surface, under controlled conditions.
§ When used as directed.

Safety Feature

After 10 minutes of continuous operation the unit will shut down — simply restart Wand if additional use is required.
An internal safety switch will automatically turn the system off if the light source is turned upward in order to protect eyes from exposure.

warning NOTE: The safety mechanism includes a switch that will make a rattling sound — this is a normal function.

Initial Set-up

Open battery compartment located on the underside of the handle area.
Insert four AA alkaline batteries as indicated in battery cavity (batteries are not included).
Carefully replace cover making sure to slide it completely closed.

Operation

To operate your Verilux^® CleanWave^® Portable Sanitizing Wand:

While holding the Wand with bulb facing down and away from skin or eyes, press the large blue button for 3 seconds (green light will flash).
Begin sanitizing by holding the Wand as close as possible and no more than one-half inch above the surface and move Wand slowly side to side in a 12" (1 foot) area. UV-C effectiveness depends on direct exposure, duration and intensity. Place the wand as close to the object as possible, preferably within 1/2 inch. (see illustration below).
To turn the Wand off, press the blue button until the green light goes out.
Remove batteries when not in use to extend battery life.

warning Note: A safety switch will automatically turn off the Wand if the light source is turned upward (it will go back on when the light source is once again turned downward).

After 10 minutes of continuous operation the unit will shut down — simply restart Wand if additional use is required.

Low Battery Indication

When the battery is low and needs replacing, the Wand will beep 10 times and the LED will flash 10 times.

*Calculation based on eliminating 99.9% of Influenza A on standardized size items.

Guidelines for Use

The CleanWave^® Portable Sanitizing Wand kills up to 99.9% of germs and odor-causing bacteria on hard surfaces^‡ while at home or away, such as:

Remote controls
Computer keyboards
Baby changing stations
Toys
Faucets
Telephone handsets
Doorknobs
Light switches
Steering wheels
Shopping cart handles
Airplane and train headrests^†
Alarm clocks
Cell phones
Music players

† Sanitizing times and effectiveness for porous surfaces will vary.
‡ Based on exposure of UV-C light to test organisms in laboratory on non-porous hard surface, under controlled conditions.
§ When used as directed.

Sanitizing Wand Troubleshooting

The Wand Will Not Turn On

Be sure the Wand is horizontal, with the bulb facing downward.
Open battery compartment and remove batteries. Wait at least two seconds. Replace batteries. Try again.

If you continue to have trouble, please call our Customer Service line at 1-800-786-6850.

This product should never be handled or used by children to prevent accidental exposure to UV-C rays.

Technical Specifications

Environment
Operating Temperature: 15°C to 35°C (59°F to 95°F)
Storage Temperature: 0°C to 40°C (32°F to 104°F)
Relative Humidity: 5% to 95% non-condensing

UV-C Bulb
3 Watt UV-C bulb; non-replaceable

Battery
4 standard AA batteries (not included)

One Year Limited Warranty

Many questions may be answered by visiting www.verilux.com, or you may call our Customer Service Department at 1-800-786-6850
Representatives are available Monday — Friday, 9am — 5pm EST
This limited warranty is provided by: Verilux, Inc., 340 Mad River Park, Waitsfield, VT 05673

Return Authorization is required for all returns. To obtain a Return Authorization, please contact the Verilux Customer Service Department at 1-800-786-6850, or http://www.verilux.com/customer-service-form.

If, during the first year of ownership, this product fails to operate properly, it should be returned as specified at www.verilux.com/warrantyreplacement or as instructed by a Verilux customer service representative at 1-800-786-6850.

Important Safeguards

READ ALL INSTRUCTIONS BEFORE USING

To prevent fire or shock hazard, do not expose this product to rain or excessive moisture.
Always direct the UV-C light AWAY from the eyes and skin. Direct prolonged exposure of eyes or skin to the UV-C light bulb can cause serious skin burn and eye inflammation from short wave ultraviolet radiation. Radiation from these lamps is harmful to the eyes and skin.
Application of UV-C light to existing mold growth can cause respiratory irritation and allergic symptoms. Do not use UV-C light where active mold growth exists. Remove active mold growth from surface prior to exposure. Ultraviolet (UV-C) Radiation Hazard.

This this product should not be handled or used by children to prevent accidental exposure to UV-C rays.
Never use this product on pets or people.
This bulb contains a trace amount of mercury. For safe handling, cleanup, disposal and recycling in accordance with applicable laws in US see www.epa.gov/cfl and in Canada, please visit www.ec.gc.ca/mercure-mercury/ and www.lightrecycle.ca
This product contains mercury, a chemical known to the State of California to cause birth defects or other reproductive harm.
Leakage of battery may cause damage to the wand. If the battery is found to be leaking do not use the product. Avoid direct skin or eye contact with the material leaking from the battery. Dispose of batteries per local regulations

Do not leave product unattended while on.
No serviceable parts. Refer all servicing to qualified service personnel. Servicing is required when the product is damaged in any way, for example, the product has been exposed to liquid or moisture and does not operate normally, or has been dropped and does not operate normally.
Care should be taken to prevent bulb breakage.
The product should not be exposed to dripping or splashing. No objects filled with liquids, such as vases, should be placed on or near the product.
Not intended for use on food.
With prolonged or overexposure, UV-C light may degrade, discolor and/or bleach fabrics, plastic and rubber. Do not hold product static over any surface for more than 1 minute.
Remove batteries when not in use.
Changes or modifications to this product not expressly approved by the party responsible for compliance could void the user's authority to operate the product.

SAVE THESE INSTRUCTIONS
