Dear VIZIO Customer,
Congratulations on your new VIZIO High Definition Sound Bar System
purchase. Thank you for your support. For maximum benefit, please read
these instructions before making any adjustments, and retain them for
future reference. We hope you will experience many years of enjoyment
from your new VIZIO HD Sound Bar System.
For assistance, please call (877) 668-8462 or visit us at www.vizio.com
To purchase or inquire about accessories and installation services for your
Sound Bar, please visit our website at www.vizio.com or call toll free at
(888) 849-4623.
We recommend you register your Sound Bar at our website
www.VIZIO.com or fill in your registration card and mail it in. For peace of
mind and to protect your investment beyond the standard warranty, VIZIO
offers extended warranty service plans. These plans give additional
coverage during the standard warranty period. Visit our website or call us
to purchase a plan.
Write down the serial number located on the back of your Sound Bar.
__ __ __ __ __ __ __ __ __ __ __ __ __
Purchase Date _____________________
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
and
StudioSoundHD and TruVolume technologies are incorporated under license from SRS Labs, Inc.
iPhone, iPod, iPod Classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other
countries.
© 2010. All rights reserved. The V, VIZIO, VIZIO XVT, VIZIO VIA, TruLED, 240Hz SPS, Slim Line, Smooth Motion, Where Vision
Meets Value names, phrase and symbols are trademarks or registered trademarks of VIZIO, Inc. All other trademarks are of their
respective owners. Contents subject to change without notice.
Version 5/2/2010
are trademarks of SRS Labs, Inc.
1
www.VIZIO.com
VIZIO VHT210 User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VHT210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vizio VHT210

  • Page 1 © 2010. All rights reserved. The V, VIZIO, VIZIO XVT, VIZIO VIA, TruLED, 240Hz SPS, Slim Line, Smooth Motion, Where Vision Meets Value names, phrase and symbols are trademarks or registered trademarks of VIZIO, Inc. All other trademarks are of their respective owners.
  • Page 2: Important Safety Instructions

    VIZIO VHT210 User Manual Important Safety Instructions The Sound Bar is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent the Sound Bar from being damaged, the following rules should be observed for its installation, use, and maintenance. Please read the following safety instructions before operating the Sound Bar.
  • Page 3 Liquid sprays or any object drops into your Sound Bar.  Sound Bar is exposed to rain or other moisture.  Sound Bar is dropped or damaged in any way.  The performance of the Sound Bar changes substantially. Version 5/2/2010 www.VIZIO.com VIZIO VHT210 User Manual...
  • Page 4: Table Of Contents

    Top Panel Buttons ... 8 Chapter 3 Connecting Equipment ... 9 Digital Connection... 9 Analog Connection... 9 Wired Connection to an iPod Dock (not supplied by VIZIO)... 10 Sub-Woofer Placement... 10 Chapter 4 VIZIO Remote Control ... 11 Remote Control Buttons ... 11 Remote Control Range...
  • Page 5: Chapter 1 Introduction

    Sound Bar is in good condition and that all of the contents are included. IMPORTANT: Save the carton and packing material for future shipping. Package Contents  VIZIO High Definition Sound Bar  Wireless Subwoofer  Power adapter for Sound Bar ...
  • Page 6: Wall Mounting The Sound Bar

    VIZIO VHT210 User Manual Wall Mounting the Sound Bar The Sound Bar can either be kept on the stand or mounted on the wall. If you choose to mount the Sound Bar on the wall, follow the instructions below for removing the stand.
  • Page 7: Chapter 2 Basic Controls And Connections

    3. SWITCH—Set your Sound bar into Hub or Client mode. Leave the switch in Hub mode unless you have more than one product with VIZIO HD Wireless Audio technology. See Sound Bar Modes on page 14 for more information about Sound Bar modes.
  • Page 8: Top Panel Buttons

    Input  Press repeatedly to step through the input sources in the following sequence: IN (Analog In), Optical In, or iPod, if a VIZIO wireless iPod dock is paired with the Sound Bar. Go to www.vizio.com more information.  Press and hold for 3 seconds to put the Sound Bar into pairing mode. See Pairing on page 15 for more information on pairing.
  • Page 9: Chapter 3 Connecting Equipment

    4. Turn on power to the Sound Bar and the device. 5. Select the associated input by pressing INPUT on the top of the Sound Bar or pressing IN on the remote control. Version 5/2/2010 www.VIZIO.com VIZIO VHT210 User Manual...
  • Page 10: Wired Connection To An Ipod Dock (Not Supplied By Vizio)

    5. Select the associated input by pressing IN on the top of the Sound Bar. Notes:  The iPod and Play/Pause/Previous/Next buttons on the remote control only control a VIZIO-branded iPod dock and will not control a 3rd party iPod dock or MP3 player. ...
  • Page 11: Chapter 4 Vizio Remote Control

    Power ( )—Press to turn your Sound Bar on or off. VOL + / - —Press to turn the speaker system volume up or down. MUTE—Press to turn the sound on and off. Note: this will not mute any connected headphones.
  • Page 12: Replacing The Battery In The Remote Control

    Programming a Universal Remote If you own a VIZIO TV with a Universal Remote you can program a device button (such as AUX or AUDIO) to control the Sound Bar. If your remote uses a 5-digit programming code, use code 31517. If your remote uses a 4-digit code, use 1517.
  • Page 13: Chapter 5 Using Your Sound Bar

    LEDs are located in the LED window under the VIZIO logo. When you press a button on the remote control or on the top of the Sound Bar, the indicator and LED lights as described below.
  • Page 14: Sound Bar Modes

    Sound Bar Modes Your VIZIO Sound Bar has two modes: Hub Mode and Client Mode. Use the switch on the back of your Sound Bar to set the mode. See Sound Bar Connections on page 7 to see the location of the switch.
  • Page 15: Chapter 6 Maintenance And Troubleshooting

    Version 5/2/2010 Subwoofer Subwoofer Action Subwoofer starts pairing mode Subwoofer selects Sound Bar as fast audio source www.VIZIO.com VIZIO VHT210 User Manual Sound Bar Sound Bar Button Action Display Action Link Press INPUT for Sound Bar more than 3 is in pairing...
  • Page 16: Sound Bar Error Codes

    VIZIO VHT210 User Manual Sound Bar Error Codes If an unsupported rate or sample depth is detected via the Optical Input, or an overcurrent or thermal shutdown occurs, the LEDs flash error codes. One example is when AC3 (not PCM) from a DVD player is sent to the optical input.
  • Page 17: Troubleshooting Guide

    Remember to check the peripherals to pinpoint the source of the problem. If the Sound Bar still fails to perform as expected, contact the VIZIO for assistance by calling 1-877-MYVIZIO (1-877-698-4946) or e-mail us at techsupport@vizio.com.
  • Page 18: Telephone & Technical Support

    Tel: (877) 698-4946 Fax: (949) 585-9563 Hours of operation: Monday - Friday: 6 am to 9 pm Saturday – Sunday: 8 am to 4 pm Please have your VIZIO model number, serial number, and date of purchase available before you call. VIZIO Address:...
  • Page 19: Chapter 7 Specifications

    1x Optical Digital Audio (S/PDIF) 1x Stereo Audio Features VIZIO HIGH DEFINITION 2.1 Surround Sound with Dolby Digital. Universal High Definition Sound Bar with elegant design for any HDTV. 2.1 solution with High Performance Sound Bar, Wireless Subwoofer and Master Remote Control. SRS TruSurround enables compelling Virtual Surround experience.
  • Page 20: Fcc Class B Radio Interference Statement

    VIZIO VHT210 User Manual Dimensions Subwoofer 11.18” W x 13” H x 11.86” D (284mm x 330.21mm x 301.31mm) Net Weight Sound Bar 4.6 lbs (2.1Kg) w/stand Net Weight Sound Bar 4.0 lbs (1.8Kg) w/out stand Net Weight Subwoofer 8.2 lbs (3.7Kg) Gross Weight 24 lbs (10.9Kg)
  • Page 21: One-Year Limited Warranty On Parts And Labor

    (90) days of commercial use. If a VIZIO product is defective within the warranty period, VIZIO will either repair or replace the unit at its sole option and discretion.
  • Page 22: Index

    Specifications ...19 SRS TruSurround HD LED ...14 SRS TruSurround WOW LED ...14 SRS TruVolume LED ...14 Subwoofer Connecting ...7 Error Codes...16 Pairing...15 Support Information...18 Troubleshooting ...17 Volume...8 LED ...13 Using Vizio TV Remote ...12 Wall Mounting ...6 Warranty ...21 www.VIZIO.com...
