NOTICE
*
*
*
*
email
PREPARATION
*
*
*
*
CARE AND MAINTENANCE
Part List and Hardware List
DESCRIPTION
PIECE
A
Left Leg Chair
B
Right Leg Chair
C
Back Bench Frame
D
Seat Bench Frame
E
Back Chair Frame
F
Seat Chair Frame
G
Support Bench Frame
H
Support Chair Frame
I
Top Table
J
Leg Table
CSH1
Seat Bench Cushion
CSH2
Seat Chair Cushion
CSH3
Back Cushion
Screw: M8 x 0.5 x 70 mm
HW1
HW2
Screw: M6 x 0.5 x 35 mm
HW3
Allen Bolt: M6 x 0.5 x 50 mm
PICTURE QUANTITY
3X
3X
1X
1X
2X
2X
2X
4X
1X
4X
1X
2X
4X
PIECE
24X
HW4
Flat washer: M6 x 1 mm
HW5
14X
Allen Key
8X
Model# PAT7731 -1/1
Product Dimensions
35.43"x19.68"x15.95"H (Table)
48.82"x26.38"x25.39"H (Bench)
26.38"x26.38"x25.39"H (Chair)
DESCRIPTION
PICTURE QUANTITY
Weight Capacity : 176 lbs ( Table)
352 lbs (Single seat )
705 lbs (Two person seat )
22X
Warning : Do not stand on Table/Bench
2X
Warning : Do not over torque bolts/screws
1-5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Safavieh Wilson PAT7731
Summary of Contents for Safavieh Wilson PAT7731
- Page 1 NOTICE email Model# PAT7731 -1/1 PREPARATION Product Dimensions 35.43"x19.68"x15.95"H (Table) 48.82"x26.38"x25.39"H (Bench) 26.38"x26.38"x25.39"H (Chair) CARE AND MAINTENANCE Part List and Hardware List DESCRIPTION PIECE PICTURE QUANTITY Left Leg Chair Right Leg Chair Back Bench Frame Seat Bench Frame Back Chair Frame Seat Chair Frame Support Bench Frame Support Chair Frame...
- Page 2 PART LIST: Left Leg Chair (3 pcs) Back Bench Frame (1 pc) Right Leg Chair (3 pcs) Seat Bench Frame (1 pc) Back Chair Frame (2 pcs) Seat Chair Frame (2 pcs) Support Bench Frame (2 pcs) Support Chair Frame (4 pcs) CSH1 CSH2 CSH3...
- Page 3 PREPARATION x6 Screw STEP 1: Connect Left Leg Chair (A), Right Leg Chair (B),Back Bench Frame (C) & STEP 2: Connect the part from Step 1 & Seat Bench Frame (D) by Hand. Support Bench Frame (G) by tighten Screw (HW1) with Allen Key (HW5). x6 Screw 100% STEP 3: Connect the part from Step 1 &...
- Page 4 PREPARATION x6 Screw STEP 5: Connect Left Leg Chair (A), Right Leg Chair (B),Back Chair Frame (E) & STEP 6: Connect the part from Step 5 & Seat Chair Frame (F) by Hand. Support Chair Frame (H) by tighten Screw (HW1) with Allen Key (HW5). x4 Screw 100% STEP 7: Connect the part from Step 5 &...
- Page 5 PREPARATION X8 Bolt STEP 9: Connect Top Table (I) & Leg Table (J) by tighten Bolt (HW3), Flat washer (HW4) with Allen Key (HW5). 100% STEP 10: Finish Table...
