DESCRIPTION
M4*40
M4*12
M4 Nut
φ6*16 Washer
To attach the right-side shelf provided with your Revolution BBQ, refer to the steps outlined
below. If you've acquired a Coleman Revolution Sink Module, it's recommended to utilise part
G532Y20002 or G532Y10003 (front panel of the side shelf) included with the sink and storage with no
drawer modules
Installation guide 12
QTY
3
3
3
9
