SERVICE MANUAL
W130C Tier 4
Wheel Loader
Print No. 47387716B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W130C Tier 4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for New Holland W130C Tier 4

Summary of Contents for New Holland W130C Tier 4

  • Page 1 SERVICE MANUAL W130C Tier 4 Wheel Loader Print No. 47387716B...
  • Page 2 W130C Wheel Loader 84488716B Use for Repair Manual Find manuals at https://best-manuals.com...
  • Page 3 Find manuals at https://best-manuals.com...
  • Page 4 W130C Wheel Loader Repair Manual 47387716B Table of Contents Description Section No. General Tab 1 Section Index - General Standard Torque Specifications 1001 Fluids and Lubricants 1002 Metric Conversion Chart 1003 Engines Tab 2 Section Index - Engines Engine and Radiator Removal and Installation 2000 Stall Tests 2002...
  • Page 5 W130C Wheel Loader Repair Manual 47387716B Table of Contents Description Section No. Steering Tab 5 Section Index - Steering Removal and Installation of Steering Components 5001 Steering Specifications, Pressure Checks, and Troubleshooting 5002 Steering Cylinders 5005 Center Pivot 5006 Auxiliary Steering Motor and Pump 5008 Power Train Tab 6...
  • Page 6 W130C Wheel Loader Repair Manual 47387716B Table of Contents Description Section No. Loader Control Valve 8005 Cylinders 8006 Coupler Solenoid Locking Valve 8007 Ride Control Accumulator 8013 Ride Control Valve 8014 Mounted Equipment Tab 9 Section Index - Mounted Equipment Air Conditioning Troubleshooting and System Checks 9002 Air Conditioner System Service...
  • Page 7 Find manuals at https://best-manuals.com...
  • Page 8 SECTION INDEX GENERAL Section Title Section Number Standard Torque Specifications............. .1001 Fluids and Lubricants .
  • Page 9 Find manuals at https://best-manuals.com...
  • Page 10 Section 1001 GENERAL TORQUE SPECIFICATIONS Find manuals at https://best-manuals.com...
  • Page 11 1001-2 TABLE OF CONTENTS TORQUE SPECIFICATIONS - DECIMAL HARDWARE ..........3 TORQUE SPECIFICATIONS - METRIC HARDWARE .
  • Page 12 1001-3 TORQUE SPECIFICATIONS - DECIMAL HARDWARE Use the torques in this chart when special torques Grade 8 Bolts, Nuts, and Studs are not given. These torques apply to fasteners with both UNC and UNF threads as received from suppliers dry, or when lubricated with engine oil. Not applicable if special graphities, Molydisulfide greases, or other extreme pressure lubricants are Pound-...
  • Page 13 1001-4 TORQUE SPECIFICATIONS - METRIC HARDWARE Use the following torques when specifications are not Grade 10.9 Bolts, Nuts, and Studs given. These values apply to fasteners with coarse threads 10.9 as received from supplier, plated or unplated, or when lubricated with engine oil. These values do not apply if graphite or Molydisulfide grease or oil is Pound- Newton...
  • Page 14 1001-5 TORQUE SPECIFICATIONS - STEEL HYDRAULIC FITTINGS 37 Degree Flare Fitting Straight Threads with O-ring Tube OD Thread Pound- Newton Tube OD Thread Pound- Newton Hose ID Size Inches metres Hose ID Size Inches metres 1/4 inch 7/16-20 72 to 144 8 to 16 1/4 inch 7/16-20...
  • Page 15 1001-6 TORQUE SPECIFICATIONS - STEEL HYDRAULIC FITTINGS O-ring Boss End O-ring Face Seal End Fitting or Lock Nut Nom. Dash Thread Pound- Newton Thread Pound- Newton Size Tube OD Size Inches metres Size Inches metres 1/4 inch 9/16-18 120 to 144 14 to 16 7/16-20 204 to 240...
  • Page 16 Section 1002 FLUIDS AND LUBRICANTS...

  • Page 17: Table Of Contents

    1002-2 TABLE OF CONTENTS CAPACITIES AND LUBRICANTS ............. 3 ENGINE OIL RECOMMENDATIONS .

  • Page 18: Capacities And Lubricants

    1002-3 CAPACITIES AND LUBRICANTS Engine Oil Capacity with Filter Change ..................13.25 liters (14 U.S. quarts) Total system capacity ....................15.1 liters (16 U.S. quarts) Type of oil ..AMBRA UNITEK CJ-4 ENGINE OIL (SAE 15W-40) - see engine oil recommendations on page 4 Engine Cooling System Capacity........................

  • Page 19: Engine Oil Recommendations

    1002-4 ENGINE OIL RECOMMENDATIONS AMBRA UNITEK CJ-4 ENGINE OIL (SAE 15W-40) e n g i n e o i l i s r e c o m m e n d e d fo r u s e i n yo u r engine.AMBRA UNITEK CJ-4 ENGINE OIL (SAE 15W-40) engine oil will lubr icate your engine correctly under all operating conditions.

  • Page 20: Transmission Temperature Chart

    1002-5 TRANSMISSION TEMPERATURE CHART WHL201212...

  • Page 21: Diesel Fuel System

    1002-6 DIESEL FUEL SYSTEM Fuel Storage Use No. 2 diesel fuel in the engine of this machine. The use of other fuels can cause the loss of engine If you keep fuel in storage for a period of time, you power and high fuel consumption.

  • Page 22: What Is Selective Catalytic Reduction (Scr)

    ² Significant loss of shelf life: check every batch Refer to the S HELF LIFE table below. In order for before use. See your New Holland dealer for more DEF/AdBlue® to remain in a usable condition, stor- information on testing. age requirements need to be met.
  • Page 23 1002-8 Glossary Acronym Definition NOTE: The main factors taken into account to define Diesel Exhaust Fluid the shelf life in the previous figures are the ambient storage temperature and the initial alkalinity of International Organization DEF/AdBlue®. The difference in evaporation for Standardization between vented and non-vented storage containers MSDS...

  • Page 24: Selective Catalytic Reduction (Scr) - Basic Instructions

    1002-9 SELECTIVE CATALYTIC REDUCTION (SCR) - BASIC INSTRUCTIONS Requirements • Impurities are not entering the DEF/AdBlue® tank. The standardized DEF/AdBlue® nozzle matches T h e o p e r a t o r m u s t m a i n t a i n a p p r o p r i a t e the filler neck diameter.

  • Page 25: Maintenance Schedule

    1002-10 MAINTENANCE SCHEDULE Model W130C FREQUENCY IN HOURS SERVICE INTERVAL SERVICE POINTS Daily inspection General Every 10 Hours Engine Oil Bucket/attachment grease fittings Grease machine and attachments Every 50 Hours Hydraulic oil level Transmission oil level Engine Coolant Wheel torque Replace hydraulic oil filters Initial 100 Hours Fuel prefilter...

  • Page 26: Maintenance Points

    1002-11 Battery service Battery electrolyte level Auxiliary battery connections Electrical Battery removal and installation System Fuses and relays Work lights Driving lights Additional features MAINTENANCE POINTS See your Operators manual for maintenance of If you operate the machine in severe conditions, safety related items and for detailed information of lubricate and service the machine more frequently.
  • Page 27 1002-12 NOTES...
  • Page 28 Section 1003 METRIC CONVERSION CHART...
  • Page 29 1003-2 TABLE OF CONTENTS CONVERSION FACTORS ..............3 Metric to U.S.
  • Page 30 1003-3 CONVERSION FACTORS Metric to U.S. MULTIPLY TO OBTAIN Area: sq. meter 10.763 91 square foot hectare 2.471 05 acre Force: newton 3.596 942 ounce force newton 0.224 809 pound force Length: millimeter 0.039 370 inch meter 3.280 840 foot kilometer 0.621 371 mile...
  • Page 31 1003-4 U.S. to Metric MULTIPLY TO OBTAIN Area: square foot 0.092 903 square meter acre 0.404 686 hectare Force: ounce force 0.278 014 newton pound force 4.448 222 newton Length: inch 25.4 * millimeter foot 0.304 8 * meter mile 1.609 344 * kilometer Mass:...
  • Page 32 SECTION INDEX ENGINES Section Title Section Number Engine and Radiator Removal and Installation ..........2000 Stall Tests .
  • Page 34 Section 2000 ENGINE AND RADIATOR REMOVAL AND INSTALLATION...
  • Page 35 2000-2 TABLE OF CONTENTS Engine ................. . 3 Removal .
  • Page 36 2000-3 ENGINE Removal STEP 5 STEP 1 BD02N160 Put a 28.4 liter (30.0 U.S. quart) container below radiator drain. Remove radiator cap. Remove cap BD03A040 and drain coolant into container. Install cap after Park machine on a level surface and lower bucket to coolant has drained.
  • Page 37 2000-4 STEP 8 STEP 11 BD03A230 BD03A227 Place a solid steel bar through the strap, raise the hood and release tension on the lifting motor. STEP 9 BD03A226 Remove mount bolt (1) and backup alarm wiring harness clamp from cooler housing. Have another person balance the hood and remove the hood hinge mounting bolts (2) from the cooler frame.
  • Page 38 2000-5 STEP 14 STEP 17 BD03A225 BD03A115 Loosen clamp on air cleaner intake hose and remove Loosen the clamp on the after cooler and remove the the crankcase ventilation hose. after cooler inlet hose from the machine. STEP 15 STEP 18 BD06F110 BD06F111 Loosen clamps on turbocharger and air cleaner,...
  • Page 39 2000-6 STEP 20 STEP 22 BD06F110 BD06F113 Loosen the exhaust clamp from the turbocharger. STEP 21 BD06F114 Remove the four mounting bolts from the belt cover, remove the cover. NOTE: After removing the belt cover remove the BD06F112 Remove the air cleaner and muffler from the bracket. cover mounting brackets from the machine frame.
  • Page 40 2000-7 STEP 24 STEP 27 BD06F116 BD06F119 Loosen clamps and remove lower cooler hose from Remove bolt securing wiring harness clamp to the engine. engine. STEP 25 STEP 28 BD06F117 BD06F120 If loader is equipped with air conditioning, identify, Remove bolt securing wiring harness clamp (1) to the tag, and disconnect the engine wiring harness engine.
  • Page 41 2000-8 STEP 30 STEP 33 BD06F146 BD03A142 Disconnect the engine coolant vent hose and root to Disconnect the wiring harness from the EDC 7 the rear of the engine. controller. NOTE: Lifting up on the lever will release the STEP 31 connector from the controller.
  • Page 42 2000-9 STEP 36 STEP 39 BD06F125 BD03A172 Remove bolt and clamp. Remove the drive shaft bolts from the flywheel. Move the drive shaft clear of the flywheel. STEP 37 STEP 40 Connect suitable lifting equipment to engine lifting brackets. Take up all slack in lifting equipment. Remove the engine mounting bolts and lift the engine enough to gain access to the drain hose, pull the drain hose with the engine.
  • Page 43 2000-10 Installation W130R0032 1. ENGINE MOUNT BOLT 3. INSOLATOR UPPER 5. WASHER 7. NUT 2. WASHER 4. INSOLATOR LOWER 6. WASHER 8. REMOTE OIL DRAIN HOSE STEP 42 STEP 47 If engine rubber isolators require replacement, remove and discard isolators (3 and 4). Install new rubber isolator (4), then rubber isolator (3).
  • Page 44 2000-11 STEP 48 STEP 51 BD06F127 BD06F124 Install the lower cover for the drive shaft. Remove cap from fitting and plug from the hose, connect fuel line (2). Connect fuel filter heater wires STEP 49 (1). Remove and discard tag. STEP 52 BD06F126 Connect and turn on vacuum pump to the hydraulic...
  • Page 45 2000-12 STEP 54 STEP 57 BD06F111 BD06F121 Connect grid heater cable to grid heater. Remove Install the wires to the starter solenoid (3), install the and discard tag. ground cable (2), and ground strap (1) to the starter. Remove and discard tags. STEP 55 STEP 58 BD06F122...
  • Page 46 2000-13 STEP 60 STEP 63 BD06F118 BD06F115 Connect the wiring to the alternator. Remove and Install the drive belt. discard tags. STEP 64 STEP 61 BD06F113 BD06F117 If loader is equipped with air conditioning, mount the compressor using the three mounting bolts (2), connect the engine wiring harness connectors to air compressor clutch connector (1).
  • Page 47 2000-14 STEP 65 STEP 68 BD06F112 BD06F111 Place the muffler and air cleaner on the bracket. Tighten the clamp on the intake manifold for the after Install mounting bolts in air cleaner and tighten, cooler output hose. install the mounting bolts in the muffler and leave loose at this time.
  • Page 48 2000-15 STEP 71 STEP 75 BD06F110 BD03A227 Install the intake hose and tighten the clamps on turbocharger and air cleaner. STEP 72 BD03A226 Have another person balance the hood, install the hood hinge mounting bolts (2) to the cooler frame. Install mount bolt (1) and backup alarm wiring harness clamp to cooler housing.
  • Page 49 2000-16 STEP 77 Hood Adjustment Table (MM) (MM) (MM) (MM) (MM) (MM) (MM) (MM) BD06F109 Connect hood wiring harness connector to rear chassis wiring harness connector. Remove and discard tag. STEP 78 STEP 79 BD03A221 NOTE: If hood strut is not adjusted properly the hood will be damaged.
  • Page 50 2000-17 STEP 81 STEP 85 If hydraulic reservoir was drained, fill reservoir with 9 0 . 8 l i t e r s ( 2 4 . 0 U. S . g a l l o n s ) o f A M B R A Hydrosystem 46HV®...
  • Page 51 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
