W130B
Workshop Manual
Workshop
Manual
Print No. 87634759 A - EU
English - Printed in Italy
W130B
P
R
O
V
E
N
P
E
R
F
O
R
M
A
N
C
E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W130B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for New Holland W130B

Summary of Contents for New Holland W130B

  • Page 1 W130B Workshop Manual Workshop Manual Print No. 87634759 A - EU English - Printed in Italy W130B...
  • Page 2 W130B Wheel Loader 87634759 A - EU Use for Service Manual Find manuals at https://best-manuals.com...
  • Page 3 Find manuals at https://best-manuals.com...
  • Page 4 W130B Wheel Loader Repair Manual 87634759 A - EU Table of Contents Description Section No. General Tab 1 Section Index - General Standard Torque Specifications 1001 Fluids and Lubricants 1002 Metric Conversion Chart 1003 Engines Tab 2 Section Index - Engines...
  • Page 5 W130B Wheel Loader Repair Manual 87634759 A - EU Table of Contents Description Section No. Steering Tab 5 Section Index - Steering Removal and Installation of Steering Components 5001 Steering Specifications, Pressure Checks, and Troubleshooting 5002 Steering Cylinders 5005 Center Pivot...
  • Page 6 W130B Wheel Loader Repair Manual 87634759 A - EU Table of Contents Description Section No. Cylinders 8006 Coupler Solenoid Locking Valve 8007 Load Travel Stabilization Accumulator 8013 Load Travel Stabilization Valve 8014 Mounted Equipment Tab 9 Section Index - Mounted Equipment...
  • Page 7 Find manuals at https://best-manuals.com...
  • Page 8 SECTION INDEX GENERAL Section Title Section Number Standard Torque Specifications .............1001 Fluids and Lubricants .
  • Page 9 Find manuals at https://best-manuals.com...
  • Page 10 Section 1001 GENERAL TORQUE SPECIFICATIONS Copyright © 2007 CNH Italia S.p.A. CNH Italia S.p.A. All rights reserved. Viale delle Nazioni, 55 Printed in E.C. 41100 Modena Issued October, 2007 87634759 A - EU Italia Find manuals at https://best-manuals.com...
  • Page 11 1001-2 TABLE OF CONTENTS TORQUE SPECIFICATIONS - DECIMAL HARDWARE ..........3 TORQUE SPECIFICATIONS - METRIC HARDWARE .
  • Page 12 1001-3 TORQUE SPECIFICATIONS - DECIMAL HARDWARE Use the torques in this chart when special torques Grade 8 Bolts, Nuts, and Studs are not given. These torques apply to fasteners with both UNC and UNF threads as received from suppliers dry, or when lubricated with engine oil. Not applicable if special graphities, Molydisulfide greases, or other extreme pressure lubricants are Pound-...
  • Page 13 1001-4 TORQUE SPECIFICATIONS - METRIC HARDWARE Use the following torques when specifications are not Grade 10.9 Bolts, Nuts, and Studs given. These values apply to fasteners with coarse threads as received from supplier, plated or unplated, or 10.9 when lubricated with engine oil. These values do not apply if graphite or Molydisulfide grease or oil is Pound- Newton...
  • Page 14 1001-5 TORQUE SPECIFICATIONS - STEEL HYDRAULIC FITTINGS 37 Degree Flare Fitting Straight Threads with O-ring Tube OD Thread Pound- Newton Tube OD Thread Pound- Newton Hose ID Size Inches metres Hose ID Size Inches metres 1/4 inch 7/16-20 72 to 144 8 to 16 1/4 inch 7/16-20...
  • Page 15 1001-6 TORQUE SPECIFICATIONS - STEEL HYDRAULIC FITTINGS O-ring Boss End O-ring Face Seal End Fitting or Lock Nut Nom. Dash Thread Pound- Newton Thread Pound- Newton Size Tube OD Size Inches metres Size Inches metres 1/4 inch 9/16-18 120 to 144 14 to 16 7/16-20 204 to 240...
  • Page 16 Section 1002 FLUIDS AND LUBRICANTS Copyright © 2007 CNH Italia S.p.A. CNH Italia S.p.A. All rights reserved. Viale delle Nazioni, 55 Printed in E.C. 41100 Modena Issued October, 2007 87634759 A - EU Italia...

  • Page 17: Table Of Contents

    Model W130B ........

  • Page 18: Capacities And Lubricants

    NOTE: DO NOT use an alternate oil in the axles. The brake components in the axles could be damaged as a result of using an alternate oil. Machines are shipped from the factory with break-in oil. Brake System Type of Fluid (Same as Hydraulic System) ............. New Holland AMBRA Master-Tran ENGINE OIL RECOMMENDATIONS New Holland AMBRA Engine oil is recommended S e e t h e c h a r t b e l o w f o r for use in your New Holland engine.

  • Page 19: Hydraulic Oil Temperature Chart

    1002-4 HYDRAULIC OIL TEMPERATURE CHART BC06B208 ENGINE OIL TEMPERATURE CHART BC06B150 TRANSMISSION OIL TEMPERATURE CHART BC06B209 87634759 A - EU Issued 10-07 Printed in E.C.

  • Page 20: Diesel Fuel System

    1002-5 DIESEL FUEL SYSTEM Fuel Storage Use No. 2 diesel fuel in the engine of this machine. The use of other fuels can cause the loss of engine If you keep fuel in storage for a period of time, you power and high fuel consumption.

  • Page 21: Maintenance Schedule

    1002-6 MAINTENANCE SCHEDULE Model W130B FREQUENCY IN HOURS SERVICE SERVICE POINTS INTERVAL Air cleaner Bleed Fuel Filter of Condensation Hydraulic Filter Variable Periodic Alternator, AC, Drive Belt ( * ) Radiator Coolant Level Fire extinguisher Tires Every 10 Hours Check Engine Oil Level...

  • Page 22: Maintenance Points

    1002-7 MAINTENANCE POINTS Model W130B 12 22 20 16 17 18 29 28 BS07E002 See your Operators manual for maintenance of If you operate the machine in severe conditions, safety related items and for detailed information of lubricate and service the machine more frequently.
  • Page 23 1002-8 NOTES 87634759 A - EU Issued 10-07 Printed in E.C.
  • Page 24 Section 1003 METRIC CONVERSION CHART Copyright © 2007 CNH Italia S.p.A. CNH Italia S.p.A. All rights reserved. Viale delle Nazioni, 55 Printed in E.C. 41100 Modena Issued October, 2007 87634759 A - EU Italia...
  • Page 25 1003-2 TABLE OF CONTENTS CONVERSION FACTORS ..............3 Metric to U.S.
  • Page 26 1003-3 CONVERSION FACTORS Metric to U.S. MULTIPLY TO OBTAIN Area: sq. meter 10.763 91 square foot hectare 2.471 05 acre Force: newton 3.596 942 ounce force newton 0.224 809 pound force Length: millimeter 0.039 370 inch meter 3.280 840 foot kilometer 0.621 371 mile...
  • Page 27 1003-4 U.S. to Metric MULTIPLY TO OBTAIN Area: square foot 0.092 903 square meter acre 0.404 686 hectare Force: ounce force 0.278 014 newton pound force 4.448 222 newton Length: inch 25.4 * millimeter foot 0.304 8 * meter mile 1.609 344 * kilometer Mass:...
  • Page 28 SECTION INDEX ENGINES Section Title Section Number Engine and Radiator Removal and Installation ..........2000 Stall Tests .
  • Page 30 Section 2000 ENGINE AND RADIATOR REMOVAL AND INSTALLATION Copyright © 2007 CNH Italia S.p.A. CNH Italia S.p.A. All rights reserved. Viale delle Nazioni, 55 Printed in E.C. 41100 Modena Issued October, 2007 87634759 A - EU Italia...
  • Page 31 2000-2 TABLE OF CONTENTS Engine ................. . 3 Removal .
  • Page 32 2000-3 ENGINE Removal STEP 6 STEP 1 BD06H047 Loosen clamps and remove air filter intake from air filter. BD03A040 Park machine on a level surface and lower bucket to STEP 7 ground. Put articulation lock in LOCKED position. STEP 2 Stop engine.
  • Page 33 2000-4 STEP 9 STEP 12 BD06H054 BD06H050 Carefully raise and remove hood from loader. Lower Remove the top two bolts from the hood and grill hood onto suitable platform and disconnect lifting mounting bracket at the rear of the frame. equipment.
  • Page 34 2000-5 STEP 15 STEP 18 BD06H060 BD06H055 Disconnect the engine coolant vent hose and root to Loosen clamp on air cleaner intake hose and remove the rear of the engine. the crankcase ventilation hose. STEP 19 STEP 16 BD06H058 BD06H056 Loosen the clamp on the turbocharger for the after Loosen clamps on turbocharger and air cleaner, cooler inlet hose.
  • Page 35 2000-6 STEP 21 STEP 23 BD06F111 BD06F113 Loosen the clamp on the intake manifold for the after cooler output hose. STEP 22 BD06F114 Remove the four mounting bolts from the belt cover, remove the cover. NOTE: After removing the belt cover remove the cover BD06H176 mounting brackets from the machine frame.
  • Page 36 2000-7 STEP 25 STEP 28 BD06F116 BD06F119 Loosen clamps and remove lower cooler hose from Remove bolt securing wiring harness clamp to the engine. engine. STEP 26 STEP 29 BD06F117 BD06F120 If loader is equipped with air conditioning, identify, Remove bolt securing wiring harness clamp (1) to the tag, and disconnect the engine wiring harness engine.
  • Page 37 2000-8 STEP 31 STEP 34 BD06F122 BD06F123 Remove the radiator hose (1) from the rear of the Remove the fuel line from the top of the EDC 7 engine, remove the heater hose from the rear of the controller, plug the line and cap the fitting. engine (2), remove the clamp bolts and clamps (3) STEP 35 from the bell housing.
  • Page 38 2000-9 STEP 37 STEP 39 BD06F126 BD03A172 Connect and turn on vacuum pump to hydraulic Remove the drive shaft bolts from the flywheel. Move reservoir. Tag and remove the hydraulic lines from the drive shaft clear of the flywheel. the brake system pump, plug the lines and cap the STEP 40 fittings.
  • Page 39 2000-10 Installation BS03B035 1. ENGINE MOUNT BOLT 3. INSOLATOR UPPER 5. WASHER 7. NUT 2. WASHER 4. INSOLATOR LOWER 6. WASHER 8. REMOTE OIL DRAIN HOSE STEP 42 STEP 47 Connect engine oil drain hose to frame bracket. If engine rubber isolators require replacement, remove and discard isolators (3 and 4).
  • Page 40 2000-11 STEP 49 STEP 52 BD06F127 BD06H065 Install the lower cover for the drive shaft. Remove cap from fitting and plug from the hose, connect fuel line (2). Connect fuel filter heater wires STEP 50 (1). Remove and discard tag. STEP 53 BD06F126 Connect and turn on vacuum pump to the hydraulic...
  • Page 41 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
