Page 1: Owner's Manual
OWNER’S MANUAL PHOTOMETRIC SENSOR Model SE-100 Rev: 31-Aug-2022 APOGEE INSTRUMENTS, INC. | 721 WEST 1800 NORTH, LOGAN, UTAH 84321, USA TEL: (435) 792-4700 | FAX: (435) 787-8268 | WEB: APOGEEINSTRUMENTS.COM Copyright © 2022 Apogee Instruments, Inc. -
Page 2: Table Of Contents
TABLE OF CONTENTS Owner’s Manual ....................................1 Certificates of Compliance ............................... 3 Introduction ..................................... 5 Sensor Models ..................................6 Specifications ................................... 7 Deployment and Installation ..............................10 Cable Connectors ................................... 11 Operation and Measurement ..............................12 Maintenance and Recalibration ............................. 15 Troubleshooting and Customer Support .......................... -
Page 3: Certificates Of Compliance
RoHS 3 compliant using exemption 6c. Further note that Apogee Instruments does not specifically run any analysis on our raw materials or end products for the presence of these substances, but we rely on the information provided to us by our material suppliers. - Page 4 RoHS 3 compliant using exemption 6c. Further note that Apogee Instruments does not specifically run any analysis on our raw materials or end products for the presence of these substances, but we rely on the information provided to us by our material suppliers.
-
Page 5: Introduction
Apogee Instruments SE series photometric sensors consist of a cast acrylic diffuser, optical filter, photodiode, and signal processing circuitry mounted in an anodized aluminum housing, and a cable to connect the sensor to a measurement device. -
Page 6: Sensor Models
SENSOR MODELS This manual covers the unamplified model SE-100 (in bold below). Additional models are covered in their respective manuals. Model Signal Measurement Range SE-100 Self-powered 0-150000 lux SE-202 0-2.5 V 0-5000 lux SE-205 0-5 V 0-5000 lux SE-212 0-2.5 V... -
Page 7: Specifications
Apogee SE series photometric sensors are calibrated through side-by-side comparison to the mean of four transfer standard SE-100 photometric sensors under a reference lamp. The transfer standard photometric sensors are calibrated through side-by-side comparison to the mean of at least two reference photometric sensors under a reference lamp. - Page 8 Spectral Response The mean relative spectral response of four SE-100 photometric radiometers (green) compared to CIE- 1931 curve (dotted).
- Page 9 Apogee SE series photometric sensors is approximately ± 2 % and ± 5 % at solar zenith angles of 45° and 75°, respectively. Cosine response measurements were made by direct side-by- side comparison to the mean of four reference SE-100 photometric sensors.
-
Page 10: Deployment And Installation
AL-100 Leveling Plate is recommended to level the sensor when used on a flat surface or being mounted to surfaces such as wood. To facilitate mounting on a mast or pipe, the Apogee Instruments model AL-120 Solar Mounting Bracket with Leveling Plate is recommended. -
Page 11: Cable Connectors
CABLE CONNECTORS Apogee sensors offer cable connectors to simplify the process of removing sensors from weather stations for calibration (the entire cable does not have to be removed from the station and shipped with the sensor). The ruggedized M8 connectors are rated IP68, made of corrosion-resistant marine-grade stainless-steel, and designed for extended use in harsh environmental conditions. -
Page 12: Operation And Measurement
DO NOT connect the sensor to a power source. The sensor is self-powered and applying voltage will damage the sensor. Wiring for SE-100 White: Output Signal Black: Ground... - Page 13 Sensor Calibration The Apogee unamplified photometric sensor model SE-100 has a standard illuminance (lux) calibration factor of exactly: 1000 lux per mV Multiply this calibration factor by the measured mV signal to convert sensor output to illuminance in units of lux:...
- Page 14 Spectral Errors for Apogee SE-100 Series Photometric Radiometers Radiation Source (Error Calculated Relative to Sun, Clear Sky) Error [%] Sun (Clear Sky) -2.2 Sun (Overcast) -2.4 Cool White Fluorescent T12 -0.9 Cool White Fluorescent T5 -0.8 Metal Halide -1.2 Ceramic Metal Halide...
-
Page 15: Maintenance And Recalibration
3. Salt deposit accumulation from evaporation of sea spray or sprinkler irrigation water. Apogee Instruments upward-looking sensors have a domed diffuser and housing for improved self-cleaning from rainfall but active cleaning may be necessary. Dust or organic deposits are best removed using water, or window cleaner, and a soft cloth or cotton swab. -
Page 16: Troubleshooting And Customer Support
Compatible Measurement Devices (Dataloggers/Controllers/Meters) SE-100 series photometric sensors are calibrated with a standard calibration factor of 1000 lux per mV, yielding a sensitivity of 0.001 mV per lux. Thus, a compatible measurement device (e.g., datalogger or controller) should have resolution of at least 0.001 mV in order to provide illuminance resolution of 1 lux. -
Page 17: Return And Warranty Policy
RETURN AND WARRANTY POLICY RETURN POLICY Apogee Instruments will accept returns within 30 days of purchase as long as the product is in new condition (to be determined by Apogee). Returns are subject to a 10 % restocking fee. WARRANTY POLICY... - Page 18 84321, USA 5. Upon receipt, Apogee Instruments will determine the cause of failure. If the product is found to be defective in terms of operation to the published specifications due to a failure of product materials or craftsmanship, Apogee Instruments will repair or replace the items free of charge.
