Summary of Contents for NDS 3LION
-
Page 2: Table Of Contents
SUMMARY SYSTEM COMPONENTS 3Lion + 3Link. SAFETY INTRODUCTION INSTALLATION 3Link INSTALLATION MOUNTING SCHEME DISPLAY INSTALLATION OPERATION 5.1 CHARGE 5.2 DISCHARGE OPERATION CHECK VERIFIABLE PROBLEMS TECHNICAL CHARACTERISTICS WARRANTY... -
Page 3: System Components 3Lion + 3Link
immediately flush skin with warm water and seek medical advice immediately. Be careful when installing, so that the two poles of the 3Lion do not come in contact with each other. Use isolated equipment and do not place and/or leave metal objects close to the product. -
Page 4: Introduction
Once the engine is turned off, the 3Lion service battery is able, via the BMS manager ( 3Link ), to deliver current for all on board electrical equipment: lights, heating, coffee machines, etc ... The LiFePO4 technology used for the 3Lion , unlike the traditional Li-Ion or LiPO, is extremely safe and reliable over time due to its special features. -
Page 5: Installation
(lights, conditioner, etc.) and when the services battery is disconnected from the system. Prepare an area for housing the 3Link box , as close as possible to the 3Lion , and to the engine battery, but never in the engine compartment or in compartments that are not protected from atmospheric agents . - Page 6 Below there is a representation: The installation of the 3Lion + 3Link is very simple, just intercept in the original system of the vehicle, the cable that goes from the service battery to the control unit or to the battery combining relay which in the figure "...
- Page 7 signal to the 3Link, for an optimal operation of the device.
- Page 8 All the loads in the camper (battery chargers, inverters, solar panel regulators, lights, etc.) must be connected on the pin 2 of the 3Link, the positive terminal of the 3Lion battery must have only one connection ending on the pin 3 of the 3Link.
-
Page 9: Display Installation
DISPLAY INSTALLATION Front View: Rear view: NUMBER FUNCTION Touch screen display Hole for passage of communication cable 4 Holes for fixing the cover to the wall System to fix the display frame to the cover Remove the display frame. C) Slide the display frame A) Slide the display frame upwards B) Lift the lower part downwards with respect to the... -
Page 10: Operation
5. OPERATION The 3Lion + 3Link system allows the automatic management and display the battery status. Through the display, it is possible to interact with the system and to see all the information... - Page 11 The charge by alternator is NOT active, if the vehicle is EURO6 with "Smart Alternator". In this case it is necessary to follow the installation scheme "System with 3Lion+3link with Smart Alternator (EURO6)" and select the checkbox on "Smart Alternator" from the "Settings"...
- Page 12 the date . Click on the keys until the desired value Setting is reached, taking into account that the first number to the left indicates the day, the central number indicates the month, and the number on the right indicates the last two digits of the year.
- Page 13 When it is fully charged, the display will show 100% on the battery state of charge (SOC) display. In the lower left part of the screen, it is possible to see all information about the 3Lion battery. Specifically, the battery state of charge is reported in 2 modes: textual, as percent value of the SOC, and graphically with coloured notches inside the battery symbol.
- Page 14 10.5V and does not exceed 15V. If the 3Lion voltage is less than 11.5V, charge the battery immediately. If the display shows the 0V value of the 3Lion battery, it is probable that the internal protection system (BMS)
-
Page 15: Charge
This can be done by connecting an external battery charger, or by pressing on the screen at the green button inside the 3Lion battery icon. In this case, the system connects the 3Lion battery to the motor for a few seconds. -
Page 16: Discharge
1) With the engine switched off, and with all the equipment powered off, check that the voltage shown on the display relative to the 3Lion battery, is equal to the voltage measured with the tester positioned on the 3lion poles (tolerance of ± 0.15V). -
Page 17: Verifiable Problems
5. 5) If the 3Lion battery is not fully charged, and if the check in step 4 has been successful, check the display for a positive current, and check that the arrow pointing to the engine battery turns red. -
Page 18: Technical Characteristics
8 8 . . TECHNICAL CHARACTERISTICS Technical characteristics of the 3Lion Model 3L-100 3L-100B 3L-100-P 3L-150-P Rated tension 12.8Vdc 12.8Vdc 12.8Vdc 12.8Vdc Nominal capacity 25 °C 100Ah 100Ah 100Ah 150Ah Nominal energy 25 °C 1280Wh 1280Wh 1280Wh 1920Wh Cell number... - Page 19 Working temperatures –20 °C/+65°C Maximum current, 30mA AUX output Current range -200A/+ 200A ± 10% Battery tolerance ± 5% voltage Engine battery 3Lion Dimensions 125x123x47mm Weight 480g 3link box + display 175x135h67mm dimensions Box weight including 785g display and accessories...
-
Page 20: Warranty
The warranty certificate must be kept and filed for each dispute. Failure to submit the certificate and absence of or tampering on the 3Lion and/or the 3Link non detachable coupon with the serial number shall invalidate the warranty. - Page 22 June 30, 2003 N° 196 ---------------------------------------------- (customer's signature) To be returned in enclosed envelope to: NDS Energy s.r.l. - Via G. Pascoli, 169 - 65010 Cappelle sul Tavo (Pe) Italy, or send via email to: commer@ndsenergy.it NDS ENERGY S.r.l. Via G. Pascoli, 169 – 65010 Cappelle sul Tavo (PE) Italy Phone: +39 085 4470396 –...
