- Page 1 UNIVERSAL Hydroponic & Aquaponic Premium Auto Shut-off Water Pump 80-160 Please visit www.penningtonaquagarden.com for helpful hints, tips, how-to videos and spares www.penningtonaquagarden.com PenningtonAquagarden...
- Page 2 UNIVERSAL Hydroponic & Aquaponic Premium Auto Shut-off Water Pump Congratulations on buying your Pennington Aquagarden Hydroponic ® and Aquaponic Water Pump. This pump is designed with advanced technology, to run a wide variety of Hydroponic and Aquaponic set-ups and is suitable for submersible or inline use.
-
Page 3: Table Of Contents
CONTENTS Getting to know your water pump ..........Parts Description/Spare Codes ..............4 Pump Performance Flow Chart ..............5 Technical Specifications ................5 Auto Shut-off Feature ...................5 Features/Dimensions ...................6 Accessories Supplied ..................6 Installation ................... Electrical Installation ................7-8 Locating your Pump ..................8 Maintenance and cleaning 9-11 ............ - Page 4 FOR INDOOR AND OUTDOOR USE IMPORTANT SAFETY INSTRUCTIONS WARNING - TO REDUCE THE RISK OF ELECTRIC SHOCK, USE ONLY ON PORTABLE SELF-CONTAINED FOUNTAINS NO LARGER THAN 5 FEET IN ANY DIMENSION. WARNING - RISK OF ELECTRIC SHOCK - THIS PUMP IS SUPPLIED WITH A GROUNDING CONDUCTOR AND GROUNDING TYPE ATTACHMENT PLUG.
- Page 5 SUBMERSIBLE PUMP WARNING • ACCEPTABLE FOR HOUSEHOLD INDOOR AND OUTDOOR USE. • THIS PUMP HAS BEEN EVALUATED FOR USE WITH WATER ONLY. • USE UNDER WATER ONLY, DO NOT RUN DRY. WARNING • TO REDUCE RISK OF ELECTRIC SHOCK, PULL PLUG BEFORE SERVICING THIS PUMP. •...
-
Page 6: Getting To Know Your Water Pump
GETTING TO KNOW YOUR WATER PUMP AUTO SHUT-OFF 80-160 PUMP 8 10 11 No. ASO 80 -160 Part Description Spare Code Pump motor Pump outlet Impellor complete 8908 Impellor cover Front pump cage Back pump cage Flow adjuster 1 / 2 "... -
Page 7: Pump Performance Flow Chart
GETTING TO KNOW YOUR WATER PUMP Auto shut-off feature FLOW CHART (prevents burnout) 3’ 60 gal l hr 2’ 108 gal l hr Sensors automatically turn off the pump when the water level is low 1’ 143 gal l hr 0’... -
Page 8: Features/Dimensions
GETTING TO KNOW YOUR WATER PUMP FEATURES Economical, 3” 4¾” compact motor Reduced cleaning - high surface area inlet pre-filter cage minimizes blocking 3” Adjustable flow control valve Auto shut-off sensors turns off the pump when the water is low, preventing burnout UNIVERSAL FITTING SET INCLUDED 3 / 8... -
Page 9: Installation
INSTALLATION ELECTRICAL SAFETY INFORMATION: Caution: Household indoor and outdoor use. WARNING - Risk of Electric Shock. Mount the unit at a height greater than 1 foot from the ground surface. Install only to covered Class A GFCI receptacle that has a weatherproof enclosure with the attachment plug cap inserted or removed. -
Page 10: Locating Your Pump
INSTALLATION GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. The appliance is equipped with a cord having an appliance grounding conductor and a grounding plug. -
Page 11: Maintenance And Cleaning
MAINTENANCE & CLEANING WARNING - Failure to carry out routine maintenance will result in a shorter pump life and may invalidate the guarantee. CLEANING The use of a descaler product will give improved performance and pump life by removing built-up lime scale and waste. ROUTINE MAINTENANCE Carry out routine maintenance when pump flow is visibly reduced. - Page 12 MAINTENANCE & CLEANING STEP 2 Remove yellow impellor cover by turning anti-clockwise to release lock. Then pull firmly away from pump motor. STEP 3 Remove impellor from the pump motor. Wash parts with fresh water carefully. Note that the impellor head is coloured yellow; this is to help identify a moving and potential dangerous part.
- Page 13 MAINTENANCE & CLEANING ANNUAL MAINTENANCE Once a year you should service your pump by using a descaler product found in most retail outlets, this may need to be done more frequently in hard water areas. Use before dismantling for easier and cleaner handling and always follow the instructions carefully. Dismantle the pump and examine all parts for wear or damage, replacing any parts that show obvious wear and/or damage.
-
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM Low flow from the pump Ensure that the feature pump is fully submersed and not sucking air due to lack of water in your feature. Follow routine maintenance. Ensure pipe work is not blocked, leaking or is laid so that it gets crushed or kinked. Keep the height that water is to be pumped from the water surface (known as head) to a minimum. -
Page 15: Faults And Problems Procedure
You may need proof of purchase. Please visit www.penningtonaquagarden.com for helpful hints, tips, how-to videos and spares. www.penningtonaquagarden.com PenningtonAquagarden CONSUMER ADVICE CONTACT DETAILS Pennington, 1280 Atlanta Hwy., Madison, GA 30650 Tel: www.PenningtonAquagarden.com 1-800-285-7333 Environment friendly disposal You can help protect the environment. Please remember to respect the local regulations by handing in non-working electrical equipment to an appropriate waste disposal centre. -
Page 16: Guarantee
Excludes the pump impellor which may require replacing annually. If any parts need replacing, spares are available from your retailer. 3130158 PUMP Pennington and Pennington Aquagarden Beautifully Simple Water Gardening are registered trademarks of Pennington Seed, Inc. Leaflet Code: 05 I 10 I 2022...
