- Page 1 User Manual Utente 1099/809 Access Control Camera Series Thermal & Optical Handheld Camera www.urmet.com IF YOU LOVE YOUR BUILDING...
- Page 2 1099/809 Thermal & Optical (Bi-Spectrum) Handheld Camera USER MANUAL DS1099-068...
-
Page 3: Table Of Contents
User Manual ACCESS CONTROL CAMERA SERIES Table of contents Table of contents 1 Introduction 2 Safety instructions 3 Device, operating features 3.1 Display 3.2 Power ON/OFF 3.3 Menu Measurements Palette Point Temperature Image mode 4 Operating Instructions 4.1 Image capture 4.2 Image viewing 4.3 Temperature compensation 4.4 FlashLight/Warning Light... -
Page 4: Introduction
1 Introduction Thank you for purchasing 1099/809, Thermal & Optical (Bi-Spectrum) Handheld Camera. To use the device correctly and safely, we recommend that you carefully read this manual, in particular the paragraph referring instructions and safe use. After reading this manual, we recommend that you keep it with your device for future reference. -
Page 5: Safety Instructions
Plug the power supply unit included into the DC. Check that the voltage of the mains to which the power supply unit is connected corresponds to the ratings indicated on the power supply unit itself. Disconnect the battery charger from the electric socket and the device when not in use. Do not leave the fully charged battery connected to the battery charger because excessive charge may limit duration. -
Page 6: Device, Operating Features
15. The presence of glasses or reflective surfaces causes incorrect temperature measurements. 16. When being charged, the internal temperature of the product rises, which will lead to inaccurate temperature measurement. So, it is not recommended to take measurements during or right after charging the product. Dispositivo, comandi e regolazioni 3 Device, operating features Item Description... -
Page 7: Display
3.1 DISPLAY Display size: 2.8" Display resolution: 320 (vertical) x 240 (horizontal) pixels Description Description Center point temperature High temperature Alert sign Maximum temperature Maximum temperature point (Red) Auto-calibration Temperature bar Minimum temperature point Battery status (Green) Main menu Date and time 3.2 POWER ON/OFF Press and hold the power button for 3 seconds to turn on/off the product. -
Page 8: Palette
Press the SET button to open the main menu. Press the left/right button to select the option Press the SET button to enter the Measurement menu. Press the up/down button to select Center Spot (center point measurement) or HiLo Spot (maximum and minimum temperature measurement). -
Page 9: Point Temperature
Point Temperature Press the SET button to open the main menu. Press the left/right button to select the option. Press the SET button to enter the Point Temperature menu. Press the up/down button to select the desired point. Press the SET button to turn on the point and enter the thermal imaging page. Press the left/right/up/down button to move the point. - Page 10 Press the SET button to enter the Image Mode menu. Press the up/down button to select the desired mode from Thermal (infrared image), Digital (visual light image), and Fusion (image blending). Press the SET button to apply the current mode. Press the back button to exit.
- Page 11 To set date and time: Press the up/down button to select the Date and Time option in the settings menu. Press the SET button to enter the Date and Time submenu. Press the left/right button to select the parameter to be adjusted. Press the SET button to enter the parameter adjustment state.
- Page 12 Press the up/down button to select the Measurements option in the Settings menu. Press the SET button to enter the Measurements submenu. Press the up/down button to select Emissivity or Temperature Comp (temperature compensation). Press the SET button to enter the parameter adjustment state. Press the up/down button to increase or decrease the value.
- Page 13 To set USB mode: Press the up/down button to select the USB Mode option in the Settings menu. Press the SET button to enter the USB Mode submenu. Press the up/down button to select USB Disk or USB Camera. Press the SET button to confirm. Press the back button to exit.
-
Page 14: Operating Instructions
Press the SET button to view the detail information of the device. Press the back button to exit. Note: Capacity is the storage capacity of the SD card in use currently. Factory reset To restore factory settings: Press the up/down button to select the Factory Reset option in the System submenu Press the SET button to enter. -
Page 15: Image Viewing
In the manual save mode, press the left/right button to discard or save the image, and press the SET button to confirm or the back button to return. In the auto save mode, the image will be saved automatically. Note: Images can only be saved if an SD card is installed. 4.2 IMAGE VIEWING Press the replay button to enter the gallery interface. -
Page 16: Sd Card
Set the USB mode to USB Disk to browse pictures and analyze data through the PC software; set the USB mode to USB Camera to realize real-time image projection through the PC software. Regarding the usage of the PC software, retrieve the Software User Manual from the Help option of the operation interface. - Page 17 Video mode (Usb camera) Interfaces and Basic functions Zone Description Real-time video or alarm history Real-time video Alarm setting Alarm information Alarm history list Full screen mode Double click zone 2 to enter full-screen mode Double click zone 2 or press ESC button to exit full-screen mode.
- Page 18 Alarm History Review Zone Description Alarm history list Alarm information Alarm photos Alarm photo list (F/L represents pre/post-alarm photos) Alarm Function When the maximum temperature exceeds or equals to the alarm threshold: Maximum temperature will be displayed in color of warning if the alarm is allowed. Sound alarm will be enabled if sound alarm is allowed.
- Page 19 USB disk mode Interfaces and Basic function Zone Description Menu Photo list or photo information Removable disk list Preview Photo list Photo Review foto Double click any photo file in zone 4 to open it...
- Page 20 The information of photo will be displayed on the right. DS1099-068...
- Page 21 Photo Analysis Menù per analisi foto • This is to select existing graphics, which will be displayed by dotted lines.. • This is to select the shape of graphics between point, line, rectangle and circle, and the data of drawing graphics will be recorded on the right.
-
Page 22: Specifications
• This is to select the colors of graphics. • This is to cancel selected graphics • This is to delete all the graphics. This is to export images files. ▪ Others The temperature of cursor’s pixels will be displayed on the lower right corner This is to set the unit of temperature. -
Page 23: Maintenance
Image blending ratio 0% (pure visual light image), 25%, 50%, 75%, and 100% (pure infrared image) PC software Real-time image transmission Yes (real-time image projection through) Data transmission Type-C USB interface Product size (L x W x H) 236mm x 75.5mm x 86mm Display type 2.8”... - Page 24 Customer Care Italia: 011 23 39 810 Export Dept.: +39 011 24 00 250/256 MADE IN CHINA URMET S.p.A. Via Bologna, 188/C | 10154 Torino (ITALY) www.urmet.com | info@urmet.com IF YOU LOVE YOUR BUILDING...
