Enertech YT Series Installation & Operation Manual

Field-installed electric heater

Advertisement

Installation & Operation Manual
FIELD-INSTALLED ELECTRIC HEATER
YT SERIES VERTICAL PACKAGED UNITS

Table of Contents:

Section 1: Model Nomenclature
Model Nomenclature ...........................................................................2
Warnings, Cautions, and Notes ............................................................2
Introduction, Inspection, Definition, Unit Protection ...........................3
Overview, Considerations, Installation Steps ...................................4 - 6
AHTR Electric Heat Electrical Data ........................................................6
AHTR051D / 5kW, AHTR101D / 10kW ..................................................7
AHTR151D / 15kW, AHTR201D / 20kW ................................................8
AHTR051D / 5kW, AHTR101D / 10kW,
AHTR151D / 15kW, AHTR201D / 20kW ................................................9
20D207-01NN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enertech YT Series

  • Page 1: Table Of Contents

    Installation & Operation Manual FIELD-INSTALLED ELECTRIC HEATER YT SERIES VERTICAL PACKAGED UNITS Table of Contents: Section 1: Model Nomenclature Model Nomenclature ................2 Section 2: Safety Labeling and Signal Words Warnings, Cautions, and Notes ............2 Section 3: Introduction Introduction, Inspection, Definition, Unit Protection ......3 Section 4: Installation Overview, Considerations, Installation Steps ........4 - 6...
  • Page 2: Model Nomenclature

    WILL result in death or serious EDGES OR BURRS. USE CARE AND WEAR injury. PROTECTIVE CLOTHING AND GLOVES WHEN HANDLING PARTS. “Note:” Used to highlight suggestions which will result in enhanced installation, reliability, or operation. Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 3: Section 3: Introduction

    UNIT PROTECTION The AHTR Revision D electric heaters are designed Protect units from damage and contamination due specifically for the Enertech YT Series Geothermal Heat to plastering (spraying), painting and all other foreign Pump Units. Good performance depends on proper materials that may be used at the job site.
  • Page 4: Section 4: Installation

    180 degrees. the mounting holes in the back of the heater. However, they must be replaced once the heater has been properly mounted. Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 5 See Figure 6. 13. Airflow requirements are different between models. Please refer to the unit Installation Instructions for airflow set-up information. Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 6: Section 5: Electrical Data

    45.1 AHTR201D L3/L4 7.50 41.7 36.1 52.1 45.1 Note: Supply voltage, amperage, fuse, and disconnect switch sizes MUST conform to all technical specifications in this manual and on the unit rating plate. Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 7: Section 6: Wiring Diagrams

    Section 6: Wiring Diagrams - AHTR051D / 5kW Section 6: Wiring Diagrams - AHTR101D / 10kW Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 8 Section 6: Wiring Diagrams - AHTR151D / 15kW Section 6: Wiring Diagrams - AHTR201D / 20kW Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 9: Section 7: Service Parts Lists And Drawings

    RELAY, DPST, 24VAC 43P026−01NN RELAY, DPST, 24VAC 43P028−01NN SINGLE POINT JUMPER BAR ASM 41P103−02NN WIRING HARNESS, LOW VOLTAGE CONTROL, 3 41P103−02NN WIRING HARNESS, LOW VOLTAGE CONTROL, 3 COND. (NOT SHOWN) COND. (NOT SHOWN) Enertech Global, LLC. YT Series Electric Heater IOM...
  • Page 10: 20D207-01Nn

    MEMBER Enertech Global is continually working to improve its products. As a result, the price, design and specifications of each product may change without notice and may not be as described herein. For the most up-to-date information, please visit our website, or contact our Customer Service department at info@enertechgeo.com.
