ULTRASONIC
LEAKAGE DETECTOR
RS Stock No : 123-8775
Your purchase of this
ULTRASONIC LEAKAGE
DETECTOR marks a step
forward for you into the
field of precision
measurement. Although
this ULTRASONIC
LEAKAGE DETECTOR is a
complex and delicate
instrument, its durable
structure will allow many
years of use if proper
operating techniques are
developed. Please read
the following instructions
carefully and always keep
this manual within easy
reach.
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 123-8775 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RS PRO 123-8775

  • Page 1 ULTRASONIC LEAKAGE DETECTOR RS Stock No : 123-8775 Your purchase of this ULTRASONIC LEAKAGE DETECTOR marks a step forward for you into the field of precision measurement. Although this ULTRASONIC LEAKAGE DETECTOR is a complex and delicate instrument, its durable...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. THEORY OF ULTRASONIC LEAKAGE DETECTION......................2. FEATURES......................3. SPECIFICATIONS....................4 FRONT PANEL DESCRIPTION................4-1 Sensor Horn....................4-2 Bar LED Display Panel.................. 4-3 Battery Condition Indicator................4-4 Power Button....................4-5 Battery Test Button..................4-6 Sensitivity Setting Dial................... 4-7 Earphone Jack....................
  • Page 3: Theory Of Ultrasonic Leakage Detection

    1. THEORY OF ULTRASONIC GAS LEAKAGE DETECTION Human ear can hear sound frequency up to 18 KHz. The sound frequency above 20 KHz is categorized as ultrasonic sound which is not audible. Ultrasonic sound is very directional in nature. We can utilize this nature to pinpoint the exact origin of the sound source where the leak is located.
  • Page 4: Features

    2. FEATURES This ULTRASONIC GAS LEAKAGE DETECTOR is designed to locate the source of the ultrasonic emissions generated by gas or air leaks. The leakage level is displayed by "Bar LED Display Panel", and is covered to audible sound by either internal buzzer or to external optional earphone).
  • Page 5: Front Panel Description

    Accessories Operational manual..........1 PC Included Rubber bottle plug with plastic tubing..................1 PC 1/2 inch PVC pipe..........1 PC Hard carrying case..........1 PC Accessory Earphone, model : EA-100 (Optional) Ultrasonic transmitter, model : GS-400 4. FRONT PANEL DESCRIPTION Fig.
  • Page 6: Miscellaneous Accessories

    5. MISCELLANEOUS ACCESSORIES (accessories included) (1) Rubber bottle plug with plastic tubing. This accessory can be used to extend the sensor horn, carrying the sound from places too tight, too dangerous for human contact, to eliminate the background noise. Refer to fIG. 2. Fig.
  • Page 7: Measuring Procedure

    6. MEASURING PROCEDURE (1) Plug in the optional earphone into the "Earphone Jack"(4-7, Fig. 1) if so desired. (2) Press the "Battery Test Button"(4-5, Fig. 1) to check the battery level. The LED display panel will lit in "BAT. OK" position if it is adequately powered, otherwise, the battery should be replaced.
  • Page 8: Importance Of The Measuring Warning

    7. IMPORTANCE of THE MEASURING WARNING (1) If there is quite a bit of background noise, you may muffle the leak detector to hear the actual leaks. This can be accomplished with the "rubber plug with plastic tubing" & "PVC pipe" MISCELLANEOUS ACCESSORIES).
  • Page 9: Battery Replacement

    (7) Electrical arcing. Electrical arcing can be detected with the ultrasonic leakage detector. Arcing produces a rich ultrasonic spectrum that is quite noisy. Used the PVC pipe accessory to extend the sensor horn of the dector for safety purpose. (8) To check the bearing problems. (9) Bake system.
  • Page 10: Minimum Flow Rate Graph

    10. MINIMUM FLOW RATE GRAPH Fig. 4...
