Summary of Contents for Nordval DC202-2CH
-
Page 1: Table Of Contents
HELLO, Thank you for purchasing the DC202-2CH dashcam. Let’s get started! TABLE OF CONTENTS Declaration of conformity What’s in the box Installing your dashcam Installing with Nordväl Power Kit USB-C (optional) Connecting to the app App options Setting the parking mode Playback recordings on PC Voice control &... -
Page 2: Declaration Of Conformity
DC202-2CH Declaration and applicable standards Hereby, TJM Supplies B.V. declares that the type of dashcam DC202-2CH series conforms to: Directive EMC 2014/53/EU and the RoHS directive (2011/65/EU) and its amendment directives 2015/863/EU on the restriction of the use of certain hazardous substances in electronic equipment. -
Page 3: What's In The Box
WHAT’S IN THE BOX Please check the box for each of the following items before installing your dashcam: Electrostatic films Nordväl DC202-2CH front and rear camera Micro SD card 5x Cable clips + pry tool USB-C power cable (3.5m) + USB car charger... - Page 4 DC202-2CH Buttons & functions Button Function Instructions Record audio toggle Press the button once to activate or button deactivate audio recording. Function button Press and hold the function button for 10 SD card format + WiFi seconds to reset the WiFi password + password restoring format SD card.
-
Page 5: Installing Your Dashcam
INSTALLING YOUR DASHCAM • Do not install the product in a location where it may obstruct the driver’s field of vision. • Attach the camera to the windshield, behind the rear-view Caution mirror. Clean and dry the windshield before installation. Turn off... - Page 6 Remove the plastic film from the Plug the 12V power cable into the car’s cigarette lighter and plug the rear camera. Remove the protective film from the adhesive tape. cable into the dashcam. Attach the camera to the rear window in a place where the view is not obstructed. Place the rear camera in such a way that the adhesive edge is on the right side as shown in the image above.
-
Page 7: Installing With Nordväl Power Kit Usb-C (Optional)
INSTALLING WITH NORDVÄL POWER KIT USB-C (Optional) • Read this manual carefully before installation and, if in doubt, consult an authorized installer. • Nordväl is not responsible for any damage caused by Caution incorrect connection or by not following the instructions in this manual. - Page 8 Connect the black GND wire to a ground point. Attach the GND wire to a grounding point, such as a bolt located directly on a metal part of the vehicle frame. Connect the USB-C cable to the Nordväl dashcam and start the engine. Check if the dashcam turns on and keeps recording when you turn off...
-
Page 9: Connecting To The App
App Store Enable Bluetooth and GPS location, then open the WiFi settings on your smartphone and select the network: “DC202-2CH”. Use the default password: “12345678” to connect. Once connected, open the app to see live video, change the camera settings, or download recorded Google Play Store videos and photos. -
Page 10: App Options
APP OPTIONS General Capture image Recording/Stop Click on “Snapshot” Click to start or stop to capture an image recording. from the video. Dashcam Albums Audio Recording Access all saved Click to start or stop videos and images the sound recording. here. - Page 11 Show GPS location during recordings in the app Select “Normal or ”Event” recordings and From the “Live Video Preview” go to click on “Download” at the bottom of the “Dashcam Albums”. screen. Select the files you want to download and click on “Download” again. Your files are now downloaded to your You can now view your recordings with device.
- Page 12 Settings Video Resolution Set the video resolution. Loop Recording Recording time per segment. Audio Recording Turns audio recording on/off. Date & Time Displays the date & time in the video. G-sensor Set the impact sensitivity of the G-sensor for Event recordings.
- Page 13 Frequency Adjust the frequency: 50Hz / 60Hz. Use 50Hz if you drive in Europe. Date/Time Format Set how you want the time and date to be displayed. Speed Unit Set to kilometers per hour or miles per hour. Boot Ringtone Turns the tone on/off...
-
Page 14: Setting The Parking Mode
SETTING THE PARKING MODE • The parking mode option is only available after connecting the Nordväl Power Kit USB-C (see page 9). Caution Open the app and go to “DC202”. Stop recording first and then click on “settings” in the upper right corner. -
Page 15: Playback Recordings On Pc
PLAYBACK RECORDINGS ON PC Download the GPS video player software from the following link: www.nordval.eu/downloads/dashcams/ Copy the download file to a computer and install it. Open the installed GPS video player software. Remove the micro SD card from the dashcam. -
Page 16: Voice Control & Voice Guidance
VOICE CONTROL The DC202-2CH supports voice control. The commands are listed below. “Turn off recording” “Open recording” To stop recording To start recording “Take picture” “Lock the video” To lock the current video files To take a picture VOICE GUIDANCE The DC202 dashcam has voice guidance to let you know when important things take place. -
Page 17: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS The dashcam does not record or suddenly stops recording. Check the power supply and/or format the SD card in the camera or a computer. How do I format the SD card and reset the camera? To format the SD card, open the app and connect the dascham (if necessary). Go to “DC202”... - Page 18 Is your question not answered? The FAQs and associated solutions and tips are covered above. Is you question not listed, or the possible solution did not help? Then go to: www.nordval.eu/products-faq/ for more tips, or get in touch with us.
-
Page 19: Product Specifications
PRODUCT SPECIFICATIONS Product name DC202-2CH Front camera: black / 11,3 x 3,5 x 3,4cm / 157g Color / Size / Weight Rear camera: black / 5,4 x 2,9 x 2,7cm / 24g SD card Micro SD, class 10 or higher, up to 256GB...
