- Page 1 User Manual EXT-H211L2-SRX-HDBT 18G HDMI 2.0 over HDBaseT Scaling Receiver All Rights Reserved Version: EXT-H211L2-SRX-HDBT _2023V1.1...
- Page 2 18G HDMI Scaling Receiver over HDBaseT Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 18G HDMI Scaling Receiver over HDBaseT SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ...
-
Page 4: Table Of Contents
18G HDMI Scaling Receiver over HDBaseT Table of Contents 1. Product Introduction ....................1 1.1 Key Features ..................... 1 1.2 Package List ...................... 2 1.3 Customer Service ....................2 2. Technical Specification ....................3 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ...................... -
Page 5: Product Introduction
4K@40m) between remote endpoints using TiGHT AV transmitter EXT-H101L2-TX-HDBT. It can be powered locally or remotely through compatible TiGHT AV transmitter or matrix switcher, or supply power for the transmitter when it is powered locally with included power adaptor. The scaling receiver also features EDID and HDCP management. -
Page 6: Package List
Note: Please contact your distributor immediately if any damage or defect in the components is found. 1.3 Customer Service TiGHT AV provide a limited warranty for the product within five years counting from date of purchase (The purchase invoice shall prevail). For more information see TiGHT AV general Warranty Statement at https://tightav.com/warranty-statement... -
Page 7: Technical Specification
Selectable from 1024x768 to 4096x2160 Control Control (1) RS232 (1) Button (1) DIP Switch Control Connector (1) 3-pin terminal block (1) 4-pin dip switch General Model Name EXT-H211L2-SRX-HDBT Power DC24V 1.25A Operation Temperature -10℃ ~ +55℃ Storage Temperature -25℃ ~ +70℃ Relative Humility... -
Page 8: Panel Description
18G HDMI Scaling Receiver over HDBaseT 3. Panel Description 3.1 Front Panel LED: Power Indicator: The LED illuminates green when power is applied. HDBT Indicator: The LED illuminates blue when the unit switches to HDBT input. HDMI Indicator: The LED illuminates blue when the unit switches to HDMI ... -
Page 9: Rear Panel
18G HDMI Scaling Receiver over HDBaseT 3.2 Rear Panel HDBT IN: 1x RJ45 connector. Connects to the TiGHT AV matrix or transmitter over CAT6A cables. The LINK LED illuminates yellow when there is a valid HDBaseT link between the transmitter device and the receiver. The LED illuminates green when video transmits encrypted with HDCP. -
Page 10: System Connection
All the power switches, plugs, sockets, and power cords should be insulated and safe. All devices should be connected before system powers on. 4.2 System Diagram The following diagram illustrates an example of connections that can be utilized using the EXT-H211L2-SRX-HDBT and transmitter EXT-H101L2-TX-HDBT. -
Page 11: Video-Switching
18G HDMI Scaling Receiver over HDBaseT 5. Video-switching 5.1 Manual Switching Press the button on the front panel to select HDBT IN or HDMI IN. 5.2 Auto Switching Press and hold the button more than 3 seconds to enter or exit auto mode. The auto- switching mode abides by the following principles: 1. -
Page 12: Device Control
18G HDMI Scaling Receiver over HDBaseT 0011 1280x800@60Hz 0100 1440x900@60Hz 0101 1600x1200@60Hz 0110 1680x1050@60Hz 0111 1920x1080@60Hz 1000 1920x1200@60Hz 1001 3840x2160@24Hz 1010 3840x2160@30Hz 1011 3840x2160@50Hz 1100 3840x2160@60Hz 1101 4096x2160@24Hz 1110 4096x2160@60Hz 1111 Set the output’s resolution by RS232 commands 7. Device Control 7.1 RS232 Connect the RS232 port to control device (e.g. - Page 13 18G HDMI Scaling Receiver over HDBaseT Set the output resolution xx: 00 - 24 (out format) 00: Sink EDID 01 - 1024x768@60Hz 02 - 1280x720@50Hz 03 - 1280x720@60Hz 04 - 1280x800@60Hz 05 - 1366x768@60Hz 06 - 1440x900@60Hz 07 - 1600x1200@60Hz 08 - 1680x1050@60Hz 09 - 1920x1080@30Hz 10 - 1920x1080@50Hz...
- Page 14 18G HDMI Scaling Receiver over HDBaseT cecin or cecout is the commands to cecin,1,04,44:42 send CEC to an input or output port cecout,04,44:41 x: input port 1 - HDBT 2 - HDMI bb、cc、dd are all hexadecimal data cecin,x,[bb],[cc]:[dd] >bb:Represents device type cecout,[bb],[cc]:[dd] cecin,1,04,44:42 ok/error >cc: Represents CEC function...
- Page 15 18G HDMI Scaling Receiver over HDBaseT 10 - User-defined EDID 2 11 - User-defined EDID 3 12 - User-defined EDID 4 Query EDID of input [x] getedidin,0 x = 0 - 2 getedidin,x 0 - all inputs edid,1:03 internal! 1 - HDBT input port edid,2:06 internal! 2 - HDMI input port Upload user-defined EDID for input...
- Page 16 1 - HDBT input port 2 - HDMI input port reset reset factory data reset reset ok getstatus ext-h211l2-srx-hdbt! firmware:1.0.0a! set,1,2! hdcp,off! getstatus Query system status and port status fplock:off! hdbtpower:off! dial-up:1111! setbaudrate:3! edid,1:3 internal!
-
Page 17: Cec Table
18G HDMI Scaling Receiver over HDBaseT edid,2:6 internal! setaspectmode:1! setoutfrmt:1! setdetectmode:1! autoswitchon! videounmute! fplockon fplockon Turn on the front panel lock fplock:on ok fplockoff fplockoff Turn off the front panel lock fplock:off ok getfplock getfplock Query the front panel lock status fplock:on! 7.3 CEC Table CEC Function... - Page 18 18G HDMI Scaling Receiver over HDBaseT CEC_RC_2 CEC_RC_3 CEC_RC_4 CEC_RC_5 CEC_RC_6 CEC_RC_7 CEC_RC_8 CEC_RC_9 CEC_RC_DOT CEC_RC_ENTER CEC_RC_CLEAR 2D - 2F Reserved CEC_RC_CHANNEL_UP CEC_RC_CHANNEL_DOWN CEC_RC_PREVIOUS_CHANNEL CEC_RC_SOUND_SELECT CEC_RC_INPUT_SELECT CEC_RC_DISPLAY_INFORMATION CEC_RC_HELP CEC_RC_PAGE_UP CEC_RC_PAGE_DOWN 39 - 3F Reserved CEC_RC_POWER CEC_RC_VOLUME_UP CEC_RC_VOLUME_DOWN CEC_RC_MUTE CEC_RC_PLAY CEC_RC_STOP CEC_RC_PAUSE CEC_RC_RECORD CEC_RC_REWIND...
- Page 19 18G HDMI Scaling Receiver over HDBaseT CEC_RC_FAST_FORWARD CEC_RC_EJECT CEC_RC_FORWARD CEC_RC_BACKWARD CEC_RC_STOP_RECORD CEC_RC_PAUSE_RECORD 4F Reserved CEC_RC_ANGLE CEC_RC_SUB_PICTURE CEC_RC_VIDEO_ON_DEMAND CEC_RC_ELECTRONIC_PROGRAM_GUIDE CEC_RC_TIMER_PGRMING CEC_RC_INITIAL_CONFIGURATION CEC_RC_SELECT_BROADCAST_TYPE CEC_RC_SELECT_SOUND_PRESENTATION 58 - 5F Reserved CEC_RC_PLAY_FUNCTION CEC_RC_PAUSE_PLAY_FUNCTION CEC_RC_RECORD_FUNCTION CEC_RC_PAUSE_RECORD_FUNCTION CEC_RC_STOP_FUNCTION CEC_RC_MUTE_FUNCTION CEC_RC_RESTORE_VOLUME_FUNCTION CEC_RC_TUNE_FUNCTION CEC_RC_SELECT_DISK_FUNCTION CEC_RC_SELECT_AV_INPUT_FUNCTION CEC_RC_SELECT_AUDIO_INPUT_FUNCTION CEC_RC_POWER_TOGGLE_FUNCTION CEC_RC_POWER_OFF_FUNCTION...
-
Page 20: Drawings And Dimensions
18G HDMI Scaling Receiver over HDBaseT 8. Drawings and Dimensions 9. Environment and recycling information 9.1 Disposal of electric and electronic devices EC Directive 2012/19/EU This product is not to be treated as regular household waste but must be returned to a collection point for recycling electric and electronic devices. -
Page 21: Packaging Recycling Information
18G HDMI Scaling Receiver over HDBaseT 9.2 Packaging recycling information Note: This manual is recycled as paper (mixed paper and card).
