- Page 1 User Manual EXT-H101L2-RX-HDBT Compact 18Gbps HDMI 2.0 over HDBT Receiver All Rights Reserved Version: EXT-H101L2-RX-HDBT_2021V1.0...
- Page 2 Compact 18Gbps HDMI 2.0 over HDBT Receiver Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 Compact 18Gbps HDMI 2.0 over HDBT Receiver SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material ⚫...
-
Page 4: Table Of Contents
Compact 18Gbps HDMI 2.0 over HDBT Receiver Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Packing List ....................... 2 1.3 Customer Service ....................2 2. Specification ....................... 3 3. Panel Description ......................4 4. Video Resolution Downscaling ................... 5 5. -
Page 5: Product Introduction
Compact 18Gbps HDMI 2.0 over HDBT Receiver 1. Product Introduction This product is an HDMI 2.0 HDBT extender receiver. Supports HDMI 2.0, 4K@60 4:4:4, HDR, HDCP 2.2 It extends 1080p/4K HDMI signal over CAT6a cable up to 70m/40m(PoC) and enables IR and RS232 pass-through to control source or display device remotely. -
Page 6: Packing List
Compact 18Gbps HDMI 2.0 over HDBT Receiver 1.2 Packing List 1x EXT-H101L2-RX-HDBT ⚫ 2x Mounting Ears with 2x Screws ⚫ 1x DC power adapter with EU plug (24v1.25A) ⚫ 4x Plastic Cushions ⚫ 1x 3-Pin terminal block ⚫ 1x User Manual ⚫... -
Page 7: Specification
Compact 18Gbps HDMI 2.0 over HDBT Receiver 2. Specification Model Receiver Spec Input HDBT IN Output HDMI OUT Control Ports IR IN, IR OUT, RS232 General Transmission Mode & HDBaseT；1080p ≦ 70m; 4Kx2K ≦ 40m Distance Resolution Up to 4K@60Hz 4:4:4 Bandwidth 18Gbps HDMI Standard... -
Page 8: Panel Description
Compact 18Gbps HDMI 2.0 over HDBT Receiver 3. Panel Description ① Power LED: 1x Green LED. The LED illuminates green when it is powered on and light off when power off. ② MODE Switcher: CTRL: RS232 pass-through control mode. ⚫ ⚫... -
Page 9: Video Resolution Downscaling
3840x2160 4:2:2 Supported 1080p@30Hz 4:4:4 3840x2160 4:2:2 Supported 1080p@24Hz 4:4:4 5. System Connection The following diagram illustrates a typical input and output connections that can be utilized with the HDMI 2.0 over HDBT Transmitter and Receiver (EXT-H101L2-TX- HDBT and EXT-H101L2-RX-HDBT):... -
Page 10: Panel Drawing
Compact 18Gbps HDMI 2.0 over HDBT Receiver 6. Panel Drawing...
