Summary of Contents for silentgliss 5190
- Page 2 Wiring Diagram March 2019 Motors ® Silent Gliss 5190 ® Silent Gliss 5192 ® Silent Gliss 5193...
- Page 3 Wiring Diagram Motor ® Silent Gliss 5190...
- Page 4 Wiring Diagram for Silent Gliss Motors│Dry Contact Switching Motor SG 5190 Configuration One motor One switch open/close via dry contact switch connections Plug A + B = RJ 12 Remarks Always connect protective earth Always read safety instructions in installation and user manual first...
- Page 5 Wiring Diagram for Silent Gliss Motors│Dry Contact Switching Multiple Motors SG 5190 Switch Configuration Multiple motors Multiple switches (non Latching) Open/close via dry contact switch connections Plug A + B = RJ 12 Remarks Always connect protective earth Always read safety instructions in...
- Page 6 Motors ® Silent Gliss 5192 24 VDC...
- Page 7 Wiring Diagram for Silent Gliss Motors│24VDC Power with Dry Contact Switching Motor SG 5192 Configuration One motor with external Power Supply “24V DC” Only Motor SG 5192 One switch open/close via dry contact switch connections Plug A + B = RJ 12 Power Supply Input: 100-250 VAC Output: regulated 24 VDC...
- Page 8 Wiring Diagram for Silent Gliss Motors│24VDC Power with Dry Contact Switching Multiple Motor SG 5192 Configuration Multiple motors with external Power Switch Supply “24V DC” Only Motor SG 5192 Multiple switches (non latching) Open/close via dry contact switch connections Plug A + B = RJ 12 Power Supply Power Supply Input: 100-250 VAC...
- Page 9 Wiring Diagram Motor ® Silent Gliss 5193...
- Page 10 Wiring Diagram for Silent Gliss Motors│Main Voltage Switching Motor SG5193 Configuration One motor One switch open/close via main voltage switch connections L1 (Brown) L2 (Black) Remarks Always connect protective earth Always read safety instructions in installation and user manual first Notes: Low Voltage connectors have no functionality 110 ~220V AC...
- Page 11 Wiring Diagram for Silent Gliss Motors│Main Switching Multiple Motors Configuration Multiple motors Motor Motor Up to 3 motors One switch open/close via mains L2 (Black) L1 (Brown) Remarks Always connect protective earth Always read safety instructions in installation and user manual first Calculation 2.5 Ampere per Motor All motor currency together has to be 110 ~220V AC...
