- Page 1 Operating Instructions Container Heaters (0-90°C) WOCP, WODPX WODPK Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Rev.1.2 12/2023 Page 1 of 18...
-
Page 2: Safety Introductions
Please ensure good ventilation. A heating mantle that is not in operation must be disconnected from the power supply. Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 2 of 18... -
Page 3: Table Of Contents
Intended use and application .......................... 10 Technical Data ..............................10 Aufbau ................................11 Assemblage ..............................12 Commissioning ..............................13 Troubleshooting and problem solving .......................13 Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 3 of 18... -
Page 4: Introduction
With their high-quality materials and workmanship, the heaters provide a safe, efficient and durable solution for heating of drums and containers in industrial applications when operated as intended. Winkler, the Winkler Logo and the Winkler Red Dot Logo are registered trademarks of Winkler AG. All rights reserved. Applicable standards The container heaters are designed for use in industrial applications. -
Page 5: Intended Operation
Protection type: IP 54 Ambient storage temperature: -20 ... 50°C Length connection cable: 0,3 m with 7-pole round plug Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 5 of 18... -
Page 6: Structure
Depending on the version, the drum Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 6 of 18... -
Page 7: Assemblage
(indicated by the inner pockets) must NOT over- lap. The tightest possible fit will ensure efficient operation and uniform heating. Figure 5.4.1 Figure 5.4.2 Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 7 of 18... -
Page 8: Ibc-Heater
Appliance class I 1 zone 1.850 W WOCP1001-230ZPH9#-WIN9 1.000 l 90 °C 230 V 2 zones 2.000 W WOCP1001-230VP09#-WIN9 Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 8 of 18... -
Page 9: Structure
(Figure 6.4.2). The IBC heater must be smooth and wrinkle-free against the IBC. The heated areas (recognizable by the inner pockets) must NOT overlap. Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 9 of 18... -
Page 10: Canister Heater Wodpk
II (Protective insulation) [appliance class I as option] IP Code: IP 54 Ambient storage temperature: -20 ... 50°C Connecting cable: 0.3 m with round plug 6+PE Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 10 of 18... -
Page 11: Aufbau
Heating cable: fluoropolymer-insulated heating cable (appliance class II) in pockets Figure 7.3.1 (outside) Optional: Integrated viewing window made of transparent Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 11 of 18... -
Page 12: Assemblage
(during heating) and the can- ister does not expand inadmissibly. Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 12 of 18... -
Page 13: Commissioning
Use a clean cloth with household detergent to wipe off the contamination. The of the outside/inside cleaner must not contain solvents or abrasives. Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 13 of 18... -
Page 14: Service And Maintenance
11 Warranty Winkler warrants the product to the original purchaser for a period of twelve (12) months from the date of delivery (handover of the goods). In the event of justified complaints, Winkler shall, at its option, either remedy the defect or deliver a replacement. -
Page 15: Quality Management According To Iso 9001: 2015
Operating Instructions Container Heaters (0-90°C) WOCP, WODPX, WODPK 13 Quality management according to ISO 9001: 2015 Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 15 of 18... -
Page 16: Eu-Declaration Of Conformity
Operating Instructions Container Heaters (0-90°C) WOCP, WODPX, WODPK 14 EU-Declaration of Conformity Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 16 of 18... -
Page 17: Contact
Container Heaters (0-90°C) WOCP, WODPX, WODPK 15 Contact Winkler AG Phone: +49-6221-3646-0 Englerstrasse 24 Fax: +49-6221-3646-40 69126 Heidelberg sales@winkler.org Germany www.winkler.org Winkler AG ▪ Englerstrasse 24 ▪ 69126 Heidelberg ▪ Germany ▪ Phone: +49-6221-3646-0 ▪ sales@winkler.org ▪ www.winkler.org Page 17 of 18...
