Page 2
• VQ5020 Name of Parts The following illustrations show the names of each component, button, and switch on the camera. 1. Shutter Button 2. Power (ON/OFF) Button 3. Flash 4. Indicator Lamp 5. Lens 6. Microphone 7. Focus Switch 8. USB Port Terminal & TV Out Terminal 9.
Page 3
Indicators 1. Indicator Lamp 2. Self-Timer Lamp 3. Power Lamp 4. Flash Digital Interface: USB 1.1 Video Output: TV out in NTSC / PAL DIGITAL ZOOM During shooting, push the joystick left or right to zoom in and zoom out. Display Button Press the joystick and the current information on the TFT will be displayed.
Page 5
• Getting Ready 1. Slide open the battery compartment cover. 2. Load the batteries into the VQ5020. 3. Slide close the battery compartment cover. 4. Load the SD card (Optional) into the VQ5020. • To insert an SD card: 1. Turn the VQ5020 off.
[DeleteOne] on the screen. Press the joystick button to confirm. The VistaQuest Corporation is proud that you have chosen its product and hopes you will enjoy sharing “a clearer vision” of your memories and special moments...
