Authorized Technical Service Only
CAUTION /
These servicing instructions are for use by qualified personnel only.
To reduce the risk of electric shock do not perform any servicing
other than that contained in the operating instructions unless you are
qualified to do so. Refer all servicing to qualified service personnel.
ここに記載したサービスに関する指示事項は、サービスに関する資格を
有する者のみが使用するものです。感電防止の観点から、サービス資格
を有していない方は、取扱指示事項以外のサービスは絶対に行わないよ
うにして下さい。
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
回 路 図
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Accuphase E-308
Summary of Contents for Accuphase E-308
- Page 1 Authorized Technical Service Only 回 路 図 CAUTION / These servicing instructions are for use by qualified personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
- Page 2 EXPLANATION OF SURFACE PARTS Knob for VOLUME ﾂﾏﾐ Front Glass ★ Decoration Screw (381-4501-14) ﾌﾛﾝﾄｶﾞﾗｽ Meter 飾りﾈｼﾞ/2pcs. (172-0129-03) ﾒｰﾀ (630-0304-14) (178-2038-10) Washer ﾜｯｼｬ/2pcs. Side Panel (637-9045-04) ｻｲﾄﾞﾊﾟﾈﾙ (139-0034-22） Knob for INPUT ﾂﾏﾐ (381-4503-04) ★ Push-button for POWER ﾌﾟｯｼｭﾎﾞﾀﾝ (388-5044-03) ★ Power Push Switch Push-button for ATT (354-1023-00)
-
Page 3: Front View
FRONT VIEW Knob for INPUT Knob for VOLUME ﾂﾏﾐ ﾂﾏﾐ (381-4503-04) (381-4501-14) Head Phone Jack ﾍｯﾄﾞﾎﾝｼﾞｬｯｸ (302-1204-00) Knob for TONE,BAL 10 9 ﾂﾏﾐ (384-1405-04) 1pce. 8 Push-button=389-5080-03 1 Front Panel=131-0177-11 1pce. ﾌﾟｯｼｭﾎﾞﾀﾝ /TONE,COMP,MODE,METER ﾌﾛﾝﾄﾊﾟﾈﾙ EXTPRE 2 Sub-panel =134-0145-02 1pce. 1pce. 9 Push-button=389-5077-13 ｻﾌﾞﾊﾟﾈﾙ... - Page 4 Power Transformer ﾊﾟﾜｰﾄﾗﾝｽ (510-3026-00) IO Relay Assembly Protection Assembly IOﾘﾚｨ Ass'y ﾌﾟﾛﾃｸｼｮﾝ Ass'y (716-0674-00) (720-0068-00) Power Amp Assembly Power Amp Assembly ﾊﾟﾜｰｱﾝﾌﾟ Ass'y ﾊﾟﾜｰｱﾝﾌﾟ Ass'y (717-0079-00) (717-0079-00) Connector Board Assembly Electrolytic Capacitor ｺﾈｸﾀﾎﾞｰﾄﾞ Ass'y ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ (716-0673-00) C004,005:22,000μF/63V Line Amp Assembly (CE621WG1J223EAQ) ﾗｲﾝ...
- Page 5 Pilot Lamp 1 ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ/PL1,2,3 (176-3501-00) Receiver Assembly Power Meter Rotary Switch 受光器Ass'y ﾊﾟﾜｰﾒｰﾀ ﾛｰﾀﾘｽｲｯﾁ / S1 (721-0076-00) (178-2038-10) (339-0002-00) Indicator Input Selector Assembly ｲﾝﾃﾞｨｹｰﾀ ｲﾝﾌﾟｯﾄｾﾚｸﾀ Ass'y (173-9077-03) (716-0677-00) Variable Resistor 可変抵抗器/VR1:50kΩ-A Selector LED Assembly (575-2021-00) ｾﾚｸﾀLED Ass'y Volume Assembly (723-0094-00) ﾎﾞﾘｭｰﾑ...
- Page 6 MISCELLANEOUS 本体その他使用部品 Description(部品 名) Description(部品 名) Parts No.(部 品No.) Remarks(備 考) Parts No.(部品No.) Remarks(備考) Screws for Front Panel / ﾌﾛﾝﾄﾊﾟﾈﾙ用 PC Board for ﾈｼﾞ類 Binding Screw/ ﾊﾞｲﾝﾄﾞﾂﾒﾂｷ Balance Inpnt Assembly 115-1514-10 631-0047-00 3×8mm 6pcs. Tone Amp Assembly 115-1523-10 Panel End Cap /ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ Switch Assembly 115-1522-30 600-0306-02...
- Page 7 Balance Input Amp Assembly (712-0092-00) Ass'y Relay RELAY1,2 362-1212-00 ﾘﾚｨ IC1,2 UPC4570C Ceramic Capacitor C1,2,7,8 CC14CH1H200JS 20pF /50V 磁器ｺﾝﾃﾞﾝｻ C3,4,9,10 CC14CH1H100JS 10pF /50V Electrolytic Capacitor C5,6,11,12 CE04W1E101VK 100uF/25V ｱﾙﾐ電 解ｺﾝﾃﾞﾝｻ C13,14,15,16 CE04W1H220VK 22uF/50V Polyester Capacitor C17～20 CQ922M1H223J-B 0.022uF/50V ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ RELAY1 K1 K2 RELAY2 Diode...
- Page 8 Tone Amp Assembly (712-0094-00) Ass'y RE1LA1 Connector Plug K1,6 308-0306-00 Electorlytic Capacitor C1,3,5,7,21,22 CE04W1H100VK 10uF /50V ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0206-00 ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C2,6 CE04W0J561KZEE 560uF/6.3V 308-0214-00 C4,8 CE04W1H220VK 22uF /50V 308-1206-00 308-0508-00 Polyester Capacitor C9,11 CQ922M1H222J-B 2,200pF/50V 308-0805-00 ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ C10,13 CQ922M1H473J-B 0.047uF/50V C19,20 CQ922M1H152J-B 1,500pF/50V Connector Jack 307-0515-00...
- Page 9 IO Relay Assembly (716-0674-00) Ass'y RELAY6 RELAY12 RELAY1 RELAY9 RELAY7 RELAY5 RELAY3 RELAY11 RELAY10 RELAY8 RELAY4 RELAY2 Relay RELAY1～12 362-1212-00 Pin Jack JK1,2,3,4,5 302-0411-00 ﾘﾚｨ ﾋﾟﾝｼﾞｬｯｸ Diode D1 ～12 MA165 308-1301-00 ﾀﾞｲｵｰﾄﾞ 308-0606-00 Connector Plug 308-0407-00 Carbon Film Resistor R1～10 RD142EA101J 100Ω...
-
Page 10: Switch Assembly
Switch Assembly (716-0678-00) ｽｲｯﾁ Ass'y Flat Cable 673-0505-10 ﾌﾗｯﾄｹｰﾌﾞﾙ Push Switch S1,2,3,4,5 354-1111-00 ﾌﾟｯｼｭｽｲｯﾁ Volume Assembly (716-0679-00) ﾎﾞﾘｭｰﾑ Ass'y Connector Plug K1,3 308-0407-00 ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0417-00 K1 K2 Relay RELAY1 362-1202-00 ﾘﾚｨ Variable Resistor VR1:50kΩ 575-2021-00 可変抵抗器 Polyester Capacitor C1,2 CF922N1H104JMTFF 0.1uF/ 50V ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ... - Page 11 Power Amp Assembly (717-0079-00) Ass'y K1 I C 1 Q2,6 Q1,5 Q4,8 Q3,7 (T.P.1) Test Point Electorlytic CE04W1H100PWE 10uF /50V PC Board 115-1511-10 Capacitor C5,6 CE04W1E470VRE 47uF /50V PCﾎﾞｰﾄﾞ ｱﾙﾐ電 解ｺﾝﾃﾞﾝｻ C8,9 CE04W2A331R20E 330uF /100V C16,17 CE04W2A100VRE 10uF /100V Heat Sink 240-0082-03 C18,19,20,21 CE04W2A471VRE 470uF /100V...
-
Page 12: Receiver Assembly
Protection Assembly (720-0068-00) ﾌﾟﾛﾃｸｼｮﾝ Ass'y Potentiometer VR1,2 583-0524-00 半 固 定抵 抗 器 VR1 VR2 Zener Diode HZ9A2L ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ Diode D2,3,5 ～7 MA167 ﾀﾞｲｵｰﾄﾞ TA7318P-2 UPC1237HA Transistor Q1,2 2SC2458-GR ﾄﾗﾝｼﾞｽﾀ Electorlytic Capacitor C3 CE04W0J221VRE 220uF /6.3V ｱﾙﾐ電 解ｺﾝﾃﾞﾝｻ CE04W1V4R7VRE 4.7uF / 35V CE04W0J101VRE 100uF /6.3V Polyester Film Capacitor C1,2... - Page 13 Logic Assembly (721-0075-00) Ass'y K1 K3 RELAY1 XTAL1 Connector Plug 308-0206-00 Digital Transistor X1,2,3 RN1206 ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0213-00 ﾃﾞｼﾞﾀﾙﾄﾗﾝｼﾞｽﾀ K5,10 308-0407-00 308-0508-00 Transistor 2SC3902-S/T 308-1207-00 ﾄﾗﾝｼﾞｽﾀ 308-0707-00 308-1303-00 C1,3 CE04W1E102VK 1,000uF/ 25V 308-0311-00 CE04W1H2R2VK 2.2uF/ 50V Electorlytic Capacitor CE04W1E471VK 470uF/ 50V Connector Jack 307-0911-00 ｱﾙﾐ電...
-
Page 14: Display Assembly
Display Assembly (723-0092-00) ﾃﾞｨｽﾌﾟﾚｲ Ass'y PC Board 115-1515-00 PCﾎﾞｰﾄﾞ Connector Plug 308-0721-00 ｺﾈｸﾀﾌﾟﾗｸﾞ D1～6 BR1111R-B/C/D/E Lamp Assembly (723-0093-00) ﾗﾝﾌﾟ Ass'y PC Board 115-01518-00 PC ﾎﾞｰﾄﾞ Pilot Lamp PL1,2 176-4501-10 ﾊﾟｲﾛｯﾄﾗﾝﾌﾟ Connector Plug 308-0209-00 ｺﾈｸﾀﾌﾟﾗｸﾞ Selector LED Assembly (723-0094-00) ｾﾚｸﾀ LED Ass'y Flat Cable 673-0910-10 ﾌﾗｯﾄｹｰﾌﾞﾙ... - Page 15 Notes. ※1. Internal input resistance of volt-ohm meter should be higher than 10k-ohms. テスターは、入力抵抗 10kΩ以上のものをお使い下さい。 ※2. Adjustments should be made in case of the PC Board or Transistors being changed. 調整は PCボードあるいはトランジスタを交換した場合に行って下さい。 ※3. Afer feeding 1～10watts output for about 15 minutes,check bias adjustments again. 出力1～10ﾜｯﾄ前後で通電動作させた後、ﾊﾞｲｱｽ電流を再ﾁｪｯｸする。...
- Page 16 The unit can be used with differnt voltage of 100V,120V,230V. (Use the Japanese domestic model at 100V only, and never change the voltage in Japan.) Refer the photo and illustration for the wiring on the junction terminal as shown below, and have to select the correct fuse and power supply cord.
- Page 17 Cover 保護ｶﾊﾞ (810-4545-04) Top Board 天地 当板 (803-0033-14) Accessories Case 付属品ｹｰｽ (801-0250-10) Cover for AC Cord and RC-20 保護ｶﾊﾞ/電源ｺｰﾄﾞ (810-2030-04) Top Pad(R) ﾄｯﾌﾟﾊﾟｯﾄﾞ(R) Battery :R6/UM-3 (803-0345-00) 電池 / 単3型 (569-0004-00) Top Pad(F) ﾄｯﾌﾟﾊﾟｯﾄﾞ(F) (803-0344-00) Poly Bag for Owner's Manual Cover ﾋﾞﾆｰﾙ袋...
- Page 26 - 25 -...
-
Page 27: Specifications
225 watts in accordance with IEC-65 Width 475.0 mm (18-11/16") Height 170.6 mm (6-3/4") Depth 423.0 mm (16-5/8") 21.6 kg (47.6 lbs) net 26.0 kg (57.3 lbs) in shipping carton ACCUPHASE LABORATORY INC. 20041115 861-3142-00 Printed in Japan 2-14-10 SHIN-ISHIKAWA, AOBA-KU, YOKOHAMA, JAPAN...
