- Page 1 Shelf F70 UNITED STATES • CANADA...
-
Page 3: Table Of Contents
Index Technical information page 5 Part number composition and packaging page 7 Locking devices page 8 Adjustments page 9 Shelf F70 Push G7E6Q Concealed runner - full-extension page 14 Shelf F70 Smove G7E6R Concealed runner - full-extension page 18 Accessories... - Page 4 Shelf F70 - Runner for pull-out shelves The Shelf F70 runners are for pull out shelves that are attached to the bottom of the cabinet and can be used in various market segments such as: kitchen cabinets, store fixtures, office furniture and living room furniture.
-
Page 5: Technical Information
Technical information Plan view - Full-extension 350 : X = 305 400 : X = 305 450 : X = 320 500 : X = 382.5 Dimensions Y2 = Min. 40 Y1 = Min. 50 Y1 = Min. 50 With larger shelves, it is possible to increase the number of runners, in order to improve the load capacity and the stability of the shelf. - Page 6 Shelf - Rear hook - Technical information Assembly on the pull-out shelf with a 12-mm minimum thickness Rear hook bracket (Y1-A)+17 Y1 = Min. 50 mm Assembly on the pull-out shelf with a 16-mm minimum thickness (Y1-A)+17 (Y1-A)+8 Y1 = Min. 50 mm...
-
Page 7: Part Number Composition And Packaging
Packaging PUSH LENGTH PALLET G7E6Q350XXF6 350 mm 6 prs 192 prs G7E6Q400XXF6 400 mm 6 prs 192 prs G7E6Q450XXF6 450 mm 6 prs 192 prs G7E6Q500XXF6 500 mm 6 prs 192 prs SMOVE LENGTH PALLET G7E6R350XXF6 350 mm 6 prs 192 prs G7E6R400XXF6 400 mm... -
Page 8: Locking Devices
Shelf F70 - Locking devices - Dual metal/plastic construction - For all F70 runner versions - Integrated tool-free side and depth adjustments - Pre-drilling recommended ø 2.5 mm (3/32'') - Assembly to the bottom or to the drawer front Dimension of the clip and drilling position... - Page 9 Side adjustment +/- 1.5 mm Rotate the white wheel (see drawing) towards the front of the drawer to adjust left. This operation is tool free. 1.5 mm Rotate the white wheel (see drawing) towards the back of the drawer to adjust right. This operation is tool free.
- Page 10 Depth adjustment +/- 3 mm Rotate the white wheel (see drawing) towards the outside of the drawer to increase the gap between the front and the side. This operation is tool free. + 3 mm Rotate the white wheel (see drawing) towards the inside of the drawer to reduce the gap between the front and the side.
- Page 11 Height adjustment + 2.5 mm Press the lever towards the back of the drawer to achieve the height adjustment. This operation is tool free. 2.5 mm...
- Page 12 Shelf removal Position hands under the front of the shelf and press on the orange levers, as indicated in the drawing, sliding the shelf out of the cabinet.
-
Page 13: Shelf F70 Push
Shelf F70 Push... -
Page 14: G7E6Q Concealed Runner - Full-Extension
Shelf F70 Push G7E6Q - Concealed runner Full-extension runner attached to the shelf by clips. Push: the opening system for handle-less drawers is fully integrated in the runner. A slight pressure of the drawer front is enough for the drawer to open. Product features - 170 Lbs Static load capacity / 154 Lbs Dynamic load capacity - Full extension with a synchronized mechanism... - Page 15 Ordering information BASIC PART NUMBER RUNNER LENGTH MIN. CABINET DEPTH PACKAGING (LN) (PM) G7E6Q350XXF6 6 pairs G7E6Q400XXF6 6 pairs G7E6Q450XXF6 6 pairs G7E6Q500XXF6 6 pairs To be screw fixed Screw TSP ø 3.5 mm Locking device AFCGXX3B Tool free height adjustments + 2.5 mm, depth adjustments +/- 3 mm, side adjustments +/- 1.5 mm Packaging:...
-
Page 17: Shelf F70 Smove
Shelf F70 Smove... -
Page 18: G7E6R Concealed Runner - Full-Extension
Shelf F70 Smove G7E6R - Concealed runner Full-extension runner attached to the shelf by clips. Smove: soft closing mechanism, fully integrated into the drawer runner. Product features - 170 Lbs Static load capacity / 154 Lbs Dynamic load capacity - Full extension with a synchronized mechanism - Available in 14'' to 20'' length - Enhanced smooth soft closing action - Safety system that prevents the shelves from turning over... - Page 19 Ordering information BASIC PART NUMBER RUNNER LENGTH MIN. CABINET DEPTH PACKAGING (LN) (PM) G7E6R350XXF6 6 pairs G7E6R400XXF6 6 pairs G7E6R450XXF6 6 pairs G7E6R500XXF6 6 pairs To be screw fixed Screw TSP ø 3.5 mm Locking device AFCGXX3B Tool free height adjustments + 2.5 mm, depth adjustments +/- 3 mm, side adjustments +/- 1.5 mm Packaging:...
- Page 21 Accessories...
-
Page 22: Lock-Open Function For Runners And Drawers
Shelf F70 - Lock-open function for runners and drawers AROSXXY The shelf is held at the maximum opening position by means of a rear-fixed bracket and a magnet. PACKAGING 1 box = 20 magnets, 20 brackets. Screws included. Assembly instructions 1 A) Fix the bracket, aligned with the back of the shelf. -
Page 23: Rear Hook Bracket
Rear hook bracket AGAPXXYI For shelves that are less than 12 mm thick, the runner can be used together with the rear hook bracket, thus eliminating the need for the rear hole in the shelf. PACKAGING: 1 box = 100 pcs. - Page 24 SALICE AMERICA INC. SALICE CANADA INC. 2123 CROWN CENTRE DRIVE 3500 RIDGEWAY DRIVE, UNIT#1 CHARLOTTE NC. 28227 MISSISSAUGA, ONTARIO, L5L 0B4 TEL. 704 841 7810 TEL. 905 820 8787 FAX. 704 841 7808 FAX. 905 820 7226 info.salice@saliceamerica.com info.salice@salicecanada.com www.saliceamerica.com www.salicecanada.com...
