System assembly instructions
Letterbox A-625
BURG-WÄCHTER KG
Altenhofer Weg 15
58300 Wetter
Germany
www.burg.biz
Language
en
English
Contents index
Step 1: Determination of the type of system required ......................................... 2
Step 2: Selection of the appropriate crossbar ......................................................... 2
in the system combination ............................................................................................. 3
system being assembled ................................................................................................. 4
Step 5: System assembly ................................................................................................ 5
Step 5.1 Assembly of the system with Terzo posts ....................................... 6
Step 5.1.1 Pre-assembly of the system ...................................................... 6
Step 5.1.2 Drilling the Terzo post ................................................................. 6
and optional crossbar ................................................................................... 10
on a concrete foundation ............................................................................ 10
cast in concrete ................................................................................................ 11
Step 5.2 / 5.3 Floor mounting of the system ................................................. 11
Overview of assembly sets ........................................................................................... 11
2
Advertisement
Table of Contents
Summary of Contents for Burg Wächter eBoxx A-625
-
Page 1: Table Of Contents
Language English System assembly instructions Contents index Step 1: Determination of the type of system required ......... 2 Letterbox A-625 Step 2: Selection of the appropriate crossbar ............2 Step 3: Planning the slot height of the letterboxes in the system combination ..................... 3 Step 4: Drilling the boreholes specifically for the system being assembled .................... -
Page 2: Step 1: Determination Of The Type Of System Required
Assembly instructions Dear Customer, Step 2: Selection of the appropriate crossbar The eBoxx A-letterbox modular system facilitates a modular assembly. The assembly is carried out using the Optional crossbars are available for assembly with several A-letterboxes mounted next to each other. These complement BURG-WÄCHTER Terzo posts. -
Page 3: Step 3: Planning The Slot Height Of The Letterboxes In The System Combination
Step 3: Planning the slot height of the letterboxes in the system combination System assembly: 8-unit system BK-A-625 (8 rows, 1 column) • According to DIN EN 13724, it is recommended that at least 30 % of letterbox locks should be installed at a height of between 900 mm and 1300 mm for ergonomic and barrier-free design. - Page 4 Table 5: Overview of 3-column systems in stand constructions System assembly: 14-unit system BK-A-625 (7 rows, 2 columns) System assembly: 18-unit system BK-A-625 (6 rows, 3 columns) Terzo base V11-F Cast in concrete Terzo base V11-F Cast in concrete System assembly: 16-unit system BK-A-625 (8 rows, 2 columns) System assembly: 21-unit system BK-A-625 (7 rows, 3 columns) variant 1 Terzo base V11-F Cast in concrete...
-
Page 5: Step 4: Drilling The Boreholes Specifically For The System Being Assembled
Step 4: Drilling the boreholes specifically for the system being assembled System assembly: 21-unit system BK-A-625 (7 rows, 3 columns) variant 2 Pre-drilling the system elements is required for all types of system assembly. Depending on the system combination intended, the next step is to drill the boreholes in the A-letterboxes. The following tools are required for drilling the boreholes. -
Page 6: Step 5.1 Assembly Of The System With Terzo Posts
Step 5: System assembly Step 5.1: Assembly of the system with Terzo posts The system can be assembled once the individual system elements have been pre-drilled. Step 5.1.1: Pre-assembly of the system The assembly set supplied with the A-letterbox is required to assemble the system (see Table 8 and Appendix A) The entire system must be pre-assembled for the installation of the system with Terzo posts, cast in concrete or screwed Table 8 illustrates the assembly set and the tools required. - Page 7 Table 11: Spacing of the factory drilled boreholes Table 12: Overview of the connection points between the intended system and the Terzo posts Borehole row Dimension (mm) System variant Terzo boreholes System boreholes 6-unit system (6 x 1) (Terzo base &...
- Page 8 System variant Terzo boreholes System boreholes System variant Terzo boreholes System boreholes 12-unit system (6 x 2) 14-unit system (7 x 2) (Terzo base (cast in concrete) & set in concrete) Ø 6.0 mm Ø 6.0 mm R1 & R10 R1 &...
- Page 9 System variant Terzo boreholes System boreholes System variant Terzo boreholes System boreholes 18-unit system (6 x 3) 21-unit system variant 2 (7 x 3) (Terzo base & set in concrete) (Terzo base & set in concrete) Ø 6.0 mm Ø 6.0 mm R1 &...
-
Page 10: Step 5.1.3 Assembly Of The System With The Terzo Posts And Optional Crossbar
Step 5.1.3: Assembly of the system with the Terzo posts and optional crossbar Step 5.1.4: Assembly of the system with Terzo bases on a concrete foundation The assembly set shown in Table 13 and the corresponding tools are required to assemble the system with the The following steps refer to the assembly of the system using the optionally available Terzo bases, which connect the Terzo posts. -
Page 11: Step 5.1.5 Assembly Of The System With Terzo Posts Cast In Concrete
Step 5.1.5: Assembly of the system with Terzo posts - cast in concrete Appendix A: Overview of assembly sets Plan an area of at least 500 x 500 mm for the concrete foundation with a depth of at least 800 mm for each Terzo post, Assembly set Figure Intended use... - Page 12 System assembly instructions | Letterbox A-625 BURG-WÄCHTER KG Altenhofer Weg 15 58300 Wetter Germany www.burg.biz www.burg.biz...
