Start by laying an adder panel on its side, on carpet or a blanket. Be sure
1
that the area is clear of debris and hardware, to avoid scratching the panel.
Center and attach the Metal L Brackets flush with the top of the Adder
panel (with 7/8" screws). The top does not have a solid wood edge band
and is the end opposite of the levelers.
ADDER
PANEL
METAL
L BRACKET
(centered)
LEVELERS
of the adder panel (see image to
the right). After completing the first panel,
do the same thing to the other (5) adder panels.
CF-6P2992 or CF-6P2792
Six Person Sitting Computer Station
Use 7/8" screws to attach
the Metal L Brackets
Metal L Brackets will
be attached to both sides
Standing the panels upright, connect (2) back
2
panels to one of the Adder panels using 2-1/2" Ma-
chine bolts and nuts. Pass the 2-1/2" Machine Bolts
through Back Panel 1, the Adder Panel, and Back
Panel 2 and into the nut. It is recommended to
hand tighten all the bolts/nuts until all of the back
panels and adder panels have been assembled.
NUT
position metal L
brackets - flush
with the top of the
panel
2-1/2" MACHINE BOLT
NEXT PAGE
