- Page 2 Page intentionally left blank...
- Page 3 October 23,2018 Initial Submittal December 17, 2019 Changed cover page Updated title name to reflect the type of drive New document format Updated Construction section with more detailed information December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page i...
- Page 4 Drive Startup Manual M1000-PM Page intentionally left blank Page ii © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
-
Page 5: Table Of Contents
Motor/Encoder ........................3 Construction ........................... 4 Powering Up ......................5 Final Setup ......................5 Auto Tuning ......................7 Motor Alignment ........................7 Encoder Alignment ......................... 8 Operation ........................ 8 December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page iii... - Page 6 Figure 8: MISC Menu – Bypass Term Limits ........................6 Figure 9: Bypass Term Limits Menu – NO ........................6 Figure 10: Bypass Term Limits Menu – YES ........................7 Figure 11: U9 Autotune ..............................7 Page iv © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
- Page 7 Drive Startup Manual M1000-PM List of Tables Table 1: Wiring References for Common Encoders ....................... 3 December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page v...
- Page 8 Drive Startup Manual M1000-PM Page intentionally left blank Page vi © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
-
Page 9: M1000 Drive
Figure 2: Example of Parameter Table Scroll through the motor parameters and verify that they are set to the motor nameplate values prior to performing the Motor Learn procedure. December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 1... -
Page 10: Grounding Requirements
Perform the following to connect power. See V2 Controller sheet 03 Machine Room for job specific information. 1. Connect Main line power to terminal blocks L1/L2/L3. 2. Connect the ground wire to the yellow/green terminal block next to L1-L3. Page 2 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019... -
Page 11: Brake
CLK+ Black Gray Gray White CLK- Violet Pink Clear or Silver Brown DAT+ Gray Violet Purple Violet DAT- Pink Yellow White Black SHIELD Shield Shield Large Red Shield December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 3... -
Page 12: Construction
If there is a rope gripper or single sheave brake, the process ends. 8. Install a jumper between EB and SOUT. Figure 4: Example of Construction Wiring Page 4 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019... -
Page 13: Powering Up
1. Apply external power by closing the main line disconnect. 2. Close the two-pole breaker and all the pushbutton breakers. 3. Verify the LCD on the Smartrise board and the Magnetek M1000 Drive powers up. Figure 5: Breakers Final Setup A checklist must be completed during final setup. -
Page 14: Figure 6: Main Menu - Setup
Figure 8: MISC Menu – Bypass Term Limits 7. From the BYPASS TERM LIMITS menu, set the bypass term limits from NO to YES. Figure 9: Bypass Term Limits Menu – NO Page 6 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019... -
Page 15: Auto Tuning
1. Write down the motor data on the motor name plate. 2. Navigate to U9 AUTOTUNE, then press ENTER. Figure 11: U9 Autotune 3. Select Tune No Rotation 1 as the motor alignment method. December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 7... -
Page 16: Encoder Alignment
Run the car and complete the checklist during the verification process. 1. Make sure the car is moving without triggering a fault either on the Smartrise SRU Board or the drive. If the SRU Board is faulted, see the Smartrise Equipment Installation Manual. - Page 17 Verify the voltages are also at the brake coil(s) when commanded to pick. • Verify that the voltages match brake coil voltages according to the V2 Controller sheet 01 Getting Started for the job. December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 9...
- Page 18 Drive Startup Manual M1000-PM Page intentionally left blank Page 10 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
