- Page 2 Page intentionally left blank...
- Page 3 December 17, 2019 Changed cover page Updated title name to reflect the type of drive New document format Updated Construction section with more detailed information Updated Accucoder encoder wiring December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page i...
- Page 4 Drive Startup Manual M1000-Induction Page intentionally left blank Page ii © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
-
Page 5: Table Of Contents
Brake ............................ 3 Motor/Encoder ........................3 Construction ........................... 3 Powering Up ......................5 Final Setup ......................5 Auto Tuning ......................7 Motor Alignment ........................7 Operation ........................ 8 December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page iii... - Page 6 Figure 8: MISC Menu – Bypass Term Limits ........................6 Figure 9: Bypass Term Limits Menu – NO ........................6 Figure 10: Bypass Term Limits Menu – YES ........................7 Figure 11: U9 Autotune ..............................7 Page iv © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
- Page 7 Drive Startup Manual M1000-Induction List of Tables Table 1: Wiring References for Common Encoders ....................... 3 December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page v...
- Page 8 Drive Startup Manual M1000-Induction Page intentionally left blank Page vi © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019...
-
Page 9: M1000 Drive
Figure 2: Example of Parameter Table Scroll through the motor parameters and verify that they are set to the motor nameplate values prior to performing the Motor Learn procedure. December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 1... -
Page 10: Grounding Requirements
Perform the following to connect power. See V2 Controller sheet 03 Machine Room for job specific information. Connect main line power to terminal blocks L1/L2/L3. Connect the ground wire to the yellow/green terminal block next to L1-L3. Page 2 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019... -
Page 11: Brake
CLOCK+ /CLOCK- Shield SHIELD Shield Shield Shield Shield Construction Perform the following to wire the construction box. See V2 Controller sheet 01 Getting Started- for job specific information. December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 3... -
Page 12: Figure 4: Example Of Construction Wiring
If there is a rope gripper or single sheave brakes, the process ends. Install a jumper between EB and SOUT. Figure 4: Example of Construction Wiring Page 4 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019... -
Page 13: Powering Up
Perform the following to power up the drive. Apply external power by closing the main line disconnect. Close the two-pole breaker and all the pushbutton breakers. Verify the LCD on the Smartrise board and the Magnetek M1000 Drive powers up. Figure 5: Breakers Final Setup A checklist must be completed during final process. -
Page 14: Figure 6: Main Menu - Setup
Figure 8: MISC Menu – Bypass Term Limits From the BYPASS TERM LIMITS menu, set the bypass term limits from NO to YES. Figure 9: Bypass Term Limits Menu – NO Page 6 © 2019 Smartrise Engineering, Inc. All Rights Reserved December 17, 2019... -
Page 15: Auto Tuning
Press the DOWN button to enter the following motor data that was written down into the drive. a. Enter the motor nameplate horsepower, then press the down button. b. Enter the motor nameplate voltage, then press the down button. December 17, 2019 ©2019 Smartrise Engineering, Inc. All Rights Reserved Page 7... -
Page 16: Operation
Run the car complete the checklist during the verification process. Make sure the car is moving without triggering a fault either on the Smartrise SRU board or the drive. If the SRU board is faulted, see the Smartrise Equipment Installation Manual.
