Viking Designer DDFF136SS Installation Manual
Freestanding bottom-mount/ french door bottom-mount refrigerator/freezer
Hide thumbs
Also See for Designer DDFF136SS:
- Use & care manual (18 pages) ,
- Installation manual (8 pages) ,
- Specifications (5 pages)
Advertisement
Quick Links
Download this manual
See also:
Use and Care Manual
Viking Installation Guide
Freestanding Bottom-Mount/
French Door Bottom-Mount
Refrigerator/Freezer
U L
U L
C
(
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Viking Designer DDFF136SS
Summary of Contents for Viking Designer DDFF136SS
- Page 1 Viking Installation Guide Freestanding Bottom-Mount/ French Door Bottom-Mount Refrigerator/Freezer...
- Page 2 Please Read and Follow!
- Page 3 Please Read and Follow! WARNING WARNING DANGER WARNING shall be used if required by NFP -70 (National Electric Code), federal/state/local laws, or local ordinances. If the use of a GFI is required Please Read and Follow! WARNING WARNING WARNING...
- Page 4 - 7 / s i d ( 9 1 8 ” e l s s s o - 1 / ( 1 0 8 ” 4 . 5 - 1 / ( 1 7 8 ” 8 . 1 - 7 / ( 1 8 8 ”...
- Page 5 - 7 / s i d ( 9 1 8 ” e l s s s o - 1 / ( 1 0 8 ” 4 . 5 - 1 / ( 1 7 8 ” 8 . 1 - 7 / ( 1 8 8 ”...
- Page 6 36” (91.4 cm) 20” (50.8 cm) 26” (66.0 cm) 36” (91.4 cm) 42” 70-1/2” (106.7 cm) (179.1 cm) (50.8 cm) cutout without addition of tops/grilles 72” (182.9 cm) cutout with Water line addition of location tops/grilles 26” (66.0 cm) Recommended receptacle location 14”...
- Page 7 WARNING WARNING WARNING...
- Page 8 WARNING...
- Page 9 WARNING Some installations require door/drawer removal to transport the refrigerator to its final location. Make sure power cord is disconnected from power source. WARNING Some installations require door/drawer removal to transport the refrigerator to its final location. Make sure power cord is disconnected from power source.
- Page 10 NOTE: Loosen screws three to four turns. Keep the screws in the drawer front.
- Page 12 NOTE: Use copper tubing only for installation. Plastic is less durable and can cause damage. dd 8 feet to tubing length needed to reach water supply for creation of service loop. i a . i a . i n . i n .
- Page 13 NOTE: Complete any required panel installation and/or water supply connection before leveling. Refrigerator should be in permanent location prior to leveling. NOTE: Having someone push against the top of the refrigerator takes some weight off the leveler foot screws. NOTE: It may take several turns of the...
- Page 14 WARNING Bottom-Mount NOTE: Allow 1-2 minute delay in water dispersal to allow internal water tank to fill.
