Henco CU-6ZONE-CON Quick Installation Manual

EXTENSION MODULE 6 ZONES + CONTROL UNIT (H)
2
1
Quick Installation Guide
The descriptions and photographs
contained in this document are supplied
by way of example and illustration only.
Henco Industries reserves the right
to carry out any technical and design
improvements to its products without
prior notice. Henco hereby objects to
any term, different from or additional
to Henco terms, contained in any buyer
communication in any form, unless
agreed to in a writing signed by an officer
of Henco.
2012/19/EU: Products marked with
this symbol cannot be disposed of
as unsorted municipal waste in the
European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new
equipment, or dispose of it at designated
collection points. For more information
see:
https://www.henco.be/
en/henco-logic
HENCOLOGIC
6+6 zones, Heating only, Wired - CU-6ZONEB-H + CU-6ZONE-CON
3
EN
Safety warnings and operating instructions
This product should be installed preferably by a qualified
professional. All instructions in this Installation & Operation
manual should be observed when working with the
controller. Failures due to improper installation, improper
use or poor maintenance are voiding manufacturer liability.
Pump running = Green
Powered Product = Red
Overheating = Blinking red
OFF= Zone1/Zone2 OFF= Zone3/Zone4
ON=Zone1+Zone2 ON=Zone3+Zone4
FR
Avertissements de sécurité et consignes d'utilisation
Ce produit doit être installé de préférence par un technicien
agréé. Toutes les instructions reportées dans ce manuel
d'installation et d'utilisation doivent être respectées lorsque
les travaux portent sur le contrôleur. Toute installation,
utilisation ou entretien incorrect annule la responsabilité du
fabricant.
1 LED/zone
Demand= RED
OFF= Zone7/Zone8 OFF= Zone9/Zone10
ON=Zone7+Zone8 ON=Zone9+Zone10
NL
Veiligheidswaarschuwingen en
gebruiksaanwijzingen
Dit product dient bij voorkeur door een erkend vakman te
worden geïnstalleerd. Alle instructies in deze installatie- en
bedieningshandleiding dienen te worden opgevolgd bij het
werken op de regelaar. Bij storingen als gevolg van verkeerde
installatie, onjuist gebruik of slecht onderhoud komt de
aansprakelijkheid van de fabrikant te vervallen.
