Viking Designer DETU200-4B Specifications
Touch control electric 30”/36”w. cooktop
Hide thumbs
Also See for Designer DETU200-4B:
- User manual (28 pages) ,
- Use & care manual (28 pages) ,
- Install manual (20 pages)
Advertisement
Quick Links
Standard Features & Accessories
Both models include
• QuickCook™ surface elements utilize
ribbon element technology to reach
full power in about 3 seconds
• Bridge element between left front and
rear elements, creates a continuous
heated surface
• Dimensioned to fit the majority of
similarly sized cooktop cutouts
• Strong, wear-resistant glass ceramic
top offers excellent cleanability
Model Options
30"W. Four-Element Cooktop
FINISH DETAILS FOR BOTH MODELS
• Black (BK)
o Black glass top
ORDERING INSTRUCTIONS
First specify model number, and then color code (DETU200-4BBK).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
Touch Control Electric 30"/36"W. Cooktop
4B model includes
• Four elements
o Left front— 7" 1,800 watts,
400 watts bridge
o Left rear—7" 1,800 watts
o Center—6" 1,500 watts
o Right rear—9"/7"/5" triple element
2,500/1,600/800 watts
DETU200-4B
•
1 - 8 8 8 - V I K I N G 1
COOKING
5B model includes
• Five elements
o Left front— 7" 1,800 watts,
400 watts bridge
o Left rear—7" 1,800 watts
o Center—9"/7"/5" triple element
2,500/1,600/800 watts
o Right front—6" 1,500 watts
o Right rear—8" 2,100 watts
DETU260-5B
36"W. Five-Element Cooktop
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
R E L E A S E D 0 2 / 0 5 / 1 0
