Related Manuals for Frossvt EM3105
Summary of Contents for Frossvt EM3105
- Page 1 Frossvt Espresso Coffee Machine User Manual Item EM3105 Voltage 120V Frequency 60 Hz Power 1350 W Water tank 1.4 L Pump Pressure 20 Bar Made in China...
- Page 3 Before the First Use（Important） 1. Move the coffee maker from the package, and check the accessories according to the list. 2. Clean all the detachable components. Remove the red silicone from the water tank before using the coffee maker （Note: If the red silicone piece is not removed, the machine will be unable to pump water）...
-
Page 4: How To Make A Good Cup Of Coffee
How to Make a Good Cup of Coffee Grinding coffee bean and grinding quality largely determines the quality of coffee, if the powder is too coarse, coffee extract inadequate, the taste is light, and color is lighter, the cream also will be very thin, and color is white; if the powder is too fine, coffee over extraction, it will be too dark, and no cream. - Page 5 Distance to the surface of pressed coffee powder should be about away from the edge of the filter cup (important indicator). Too high or too low will affect the extraction pressure and effect of coffee, please reduce or increase the amount of coffee powder; 4.
- Page 6 Accessories： 1.W ater tank cover 2.Water tank 3.Steam control knob 4.Main body 5.Steam pipe and nozzle 6.Base 7.ON/OFF switch 8.Warm cup board 9.Single-cup coffee switch/ Steam indicator lamp 10.Double-cup coffee switch/ indicator lamp preheating switch/indicator light pressure meter 13.Funnel holder 14.Buoy 15.Drip tray cover 16.Drip tray...
- Page 7 Operation Manual the machine is powered on ”: ON/OFF switch, Press the switch, , the “ ” and “ indicator lamp ” flashing on, the machine starts “ ” 、 “ when the all indicator lamp s stop blinking and turns normal on, to preheat.
- Page 8 Double cup of coffee switch,touch it to start extracting coffee “ ”: after preheated , the indicator lamp " " breath flashes。Automatically extract until the machine stops working or touch the button again to stop working during the extraction process， the indicator lamp “...
- Page 9 Note: when the power is turned on, the steam preheating indicator keeps flashing fast, it means that the steam knob is not closed, and you can turn the steam knob to the closed position .
- Page 10 Make Espresso Coffee（Double-Cup Coffee For Example） . Open the lid, take out water tank, and pour appropriate water into tank. Do not exceed the MAX capacity; 2. Put back the water tank and close the lid; 3. Plug in and press the ON/OFF switch“ ”, all indicator lamps re flashing, machine start preheating, preheating will be finished after 1min, coffee and steam indicator lamp will always light on ;...
- Page 11 " " to position " " (must be tightened); 6. Put cup(s) under coffee outlet; 7. Touch the double-cup coffee switch “ ” , the machine starts pumping water, and coffee flows out of the coffee nozzle; 8. The coffee machine automatically stops working (the light from Breathing light on to a constant light), and the coffee is made at this time, then remove the coffee cup;...
- Page 12 Make Cappuccino 1. Prepare espresso first with a large enough cup according to part “B; 2. Use whole, fresh cold milk out of the fridge(8℃-10℃), and pour 1/3 milk in cup; Note: Use a stainless steel cup, and cup diameter should not less than 70 ± 5mm, due to the volume of milk will increase after frothing.
- Page 13 Making Hot Water 1. Put a container under hot water outlet; 2. When all indicator lamp always keep on, Open steam knob, rotate it to the maximum position, hot water will be come out from hot water pipe immediately; In the process of making hot water, the single-cup coffee indicator“...
- Page 14 Indicator Tips Single-cu Double-c Steam p Coffee up Coffee Cause Solution Indicator Indicator Indicator Lights Coffee and hot water Flashing Flashing is pre-heating Lights Coffee and hot water Lights on Lights on pre-heating finished Breathing Lights Lights Making single cup light on coffee or water Lights...
-
Page 15: Troulbe Shooting
Lights Lights Flashing Standby for more Touch display quickly than 30 minutes switch Troulbe Shooting Problem Cause/Result Solution Water tank is empty Pour water in water tank The input voltage or Make sure the voltage and No water frequency is inconsistent frequency is consistent with the comes out with nameplate... - Page 16 Used skimmed milk Use whole milk *If you have not been able to solve the problem, contact customer support: frossvt@dg-sunrise.com Content of hazardous substances in the product Hazardous Substances Accessory (Pb) (Hg)
-
Page 17: Clean And Maintenance
Clean and Maintenance 1. The machine has to be switched off and cooled down; 2. Use a clean damp cloth to clean the stainless steel surface; Note: Do not use abrasive sponges and alcohol or solvents. 3. Clean the outlet and the seal sing under the group head with professional brush;... -
Page 18: Cleaning Mineral Deposits
Cleaning Mineral Deposits 1. The machine builds up lime scale deposits over time, and you need descale the machine 2-3 months; 2. Pour water and descale in water tank up to MAX capacity (water and descale ratio is 4:1, follow the instruction of descale. Please use “household descale”, or you can use the citric acid replace descale (water and citric acid ratio is 100:3);... -
Page 19: Environment Friendly Disposal
There are no user serviceable parts. Follow these steps if the unit fails to operate: 1. Check the instructions have been followed correctly. 2. Check that the mains supply is functional. 3. If the appliance will still not operate, please contact us： Customer Service: frossvt@dg-sunrise.com... - Page 20 Manufacture: FROSSVT Brands Inc Customer Service: frossvt@dg-sunrise.com...
