- Page 1 BATTERY BOX AP12BB-AC USERMANUAL PLEASE READ AND UNDERSTAND THIS MANUAL THOROUGHLY BEFORE OPERATION V1.2...
- Page 2 ABOUT US ATEM POWER, born in June 2017, as a synonym for exciting outdoor experience, is an Australian company with dedication and passion for the R&D of high quality products in the field of renewable energy products, batteries and related accessories. Since the company was founded, we have committed to innovation that aims to make your life infinitely more convenient.
-
Page 3: Warnings And Safety Information
WARNINGS & SAFETY INFORMATION • Before installing a battery in the battery box, ensure that you have read through all relevant product and safety information for that battery. Do not strike, throw the battery box. • To connect with the terminals of the battery box, pull up the terminal lids gently. Excessive force may •... - Page 4 CONTENTS: Battery Box Red Anderson Plug User Manual Grey Anderson Plugs DIMENSION: External Dimensions: 20.43"L (51.9cm) x 10.16"W (25.8cm) x 14.29"H (36.3cm) Internal Dimensions: 17.52"L (44.5cm) x 7.68"W (19.5cm) x 9.84"H (25.0cm) measured in millimeter(mm)
-
Page 5: Assembly Drawing
ASSEMBLY DRAWING: 1. Positive and Negative Terminals x2 2. Buckle x1 3. ON/OFF Switch(DC) x1 4. ON/OFF Switch(AC) x1 5. Volt Meter x1 6. Cigarette Lighter Socket Outputs(12V,10A) x3 7. USB Type-C Port x1 8. USB Type-A Ports x2 Max 18W Max 18W (Shared Between Both Ports) 10. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS: Step 1: Pull the buckle and open the lid of the battery box. Step 2: Place the battery in the battery box. Step 3: Attach the eyelets from the battery box lid to the corresponding positive and negative terminals on the battery. -
Page 7: Maintenance
MAINTENANCE: Please keep the inner of the box clean and dry. Please cover USB ports and cigarette lighter sockets with rubber plugs to prevent potential damage. Always keep the external terminals clean. PROTECTION FEATURES: When the voltage has dropped to 10.5V, there will be repetitive 2 Low Voltage Alarm consecutive beeps in 30s. -
Page 8: Warranty
WARRANTY MONTH WARRANTY PERIOD: ATEM POWER warrants that each of our battery box that is purchased while this Warranty is in effect will be free from defective workmanship and materials for a period of 2 years. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: Any defect in design or manufacture which results in its failure to perform correctly as described.
