TMG -PJ55 Product Manual

5500-lb hydraulic pallet jack
Hide thumbs

Advertisement

Quick Links

Download this manual
V2021.05.13
PRODUCT MANUAL
5500-lb Hydraulic Pallet Jack
Model:TMG-PJ55
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your
requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-PJ55 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-PJ55

Summary of Contents for TMG TMG-PJ55

  • Page 1 V2021.05.13 PRODUCT MANUAL 5500-lb Hydraulic Pallet Jack Model:TMG-PJ55 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...
  • Page 2 ATTENTION: 1. The waste packages should be sorted and put into solid dustbins according to the materials and be collected disposal by local special environment protection bureau. To avoid pollution, it’s forbidden to throw away the wastes randomly. 2. To avoid leaking during the use of the products, the user should prepare some absorbable materials (scraps of wooden or dry duster cloth) to absorb the leaking oil in time.

  • Page 3: General Specifications

    Thank you for using our pallet trucks. Your pallet truck is made of high quality steel and is designed for the horizontal lifting and transport of loads on a pallet or standardized containers on a level, fixed base. For your safety and correct operation, please carefully read this instruction before using it.
  • Page 4 Fig. 1 1. Draw-bar 2. Pin 3. Axle with hole 4. Elastic pin 5. Fork frame When attaching the handle, you had better squat just behind the pallet truck. Then you: 2.1 Insert the draw-bar onto the pump piston (303), then use a hammer to insert the axle with hole (105) into the hydraulic pump and draw-bar from the right to left.
  • Page 5 Fig. 3 2.3 Press the draw-bar (110, 110B or 111G) down, take away the pin(#2) (See Fig. 1). 2.4 Let the control handle (117 or 120G) on ‘RAISE’ position, then raise the lever plate (319) with the pin (#2) and insert the adjusting bolt(103) into the front slot of lever plate (319), note to keep the adjusting nut (104) on the under side of the lever plate.

  • Page 6: Maintenance

    If however they have been changed, you can adjust according to following step: 3.1 If the forks elevate while pumping in the DRIVE position, turn the adjusting nut (104) on the adjusting bolt(103) or screw(318) clockwise until pumping action does not raise the forks and the DRIVE position functions properly.
  • Page 7 4.4 LUBRICATION All bearings and shafts are provided with long-life grease at the factory. You only need provide with long-life grease at monthly intervals or after each time the truck is cleaned thoroughly to the lubrication points. 5. GUIDE TO SAFETY OPERATION 5.1 Operator should read all warning signs and instructions here and on the pallet truck before using this truck.

  • Page 8: Troubles Shooting

    6. TROUBLES SHOOTING Trouble Clause Fixing Methods The forks can not The hydraulic oil is not enough. Pour in the oil. be lifted up the maximum height. The forks can not Without hydraulic oil. Fill in the oil. be lifted up. The oil has impurities.
  • Page 9 WWW.TMGINDUSTRIAL.COM P9/14 Toll Free:1-877-761-2819...
  • Page 10 LIST of DRAW-BAR Description Qty. Description Qty. Release Rod Stop Rubber Chain Elastic Pin Adjusting Bolt Blade Spring Adjusting Nut Spring Axle with Hole Elastic Pin Elastic Pin Elastic Pin Bushing Control Handle Roller Pin Roller Pressure Roller Elastic Pin 109A Bushing Draw-bar(For Type A)
  • Page 11 WWW.TMGINDUSTRIAL.COM P11/14 Toll Free:1-877-761-2819...
  • Page 12 LIST OF FORK FRAME Description Qty. Description Qty. Fork Frame Elastic Pin 202G Bolt Elastic Pin Rock - Arm Shaft Bushing Frame of Roller Shaft 223D Shaft for Roller Bushing 224D Linking Plate Bushing Washer Retaining Ring Bearing Joint Loading Roller 230D Elastic Pin(For Type D) 8 or 2...
  • Page 13 Hydraulic Pump WWW.TMGINDUSTRIAL.COM P13/14 Toll Free:1-877-761-2819...
  • Page 14 Hydraulic Pump Description Qty. Description Qty. Spring Cap Dust Ring Spring Piston Rod Pump Piston Steel Ball Dust Ring 330A Screw Plug Seal 331A O - Ring Dust Cover 332A Bolt Locking Ring 333A Spring Washer 334A Spindle of Safety Valve Bearing Grease Cup Loading Wheel...
